- Page 1 NT® PRESSURE TRANSDUCER 4000 Series User Guide...
-
Page 2: Table Of Contents
Model 4130 Single-port ..21 Troubleshooting ....10 Model 4230 Flow-through ..22 Maintenance ...... 10 Repair and Warranty Service ... 23 Zero and Span Adjustment ..10 ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... -
Page 3: Introduction
Signal conditioning circuit Electronic pressure sensor Solid PTFE Process connection Cut-away Example: NT Flow-through Pressure Transducer Polypropylene electrical connector option Signal conditioning circuit Electronic pressure sensor Solid PTFE Process connection Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC. -
Page 4: Nonstandard Product Configurations
NT ® transducers, Model 4210 product Pressure Transducers, Models 4100, line, are identified with a “T” 4130, 4210 and 4230. Entegris followed by a number code. also manufactures nonstandard For example, part number product to meet the needs of specific 4210-030G-F02-B06-A-T02 applications. -
Page 5: Installation
Verify that the pressure transducer and the sig- nal cable are free from mechanical stress or excessive bending from the surrounding equipment. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC. -
Page 6: Electrical Installation
These devices may produce transients that may affect the pres- sure transducer measurements when the inductive device is powered up or powered down. ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... - Page 7 – 12 V – R Load meter 20 mA where: = maximum load Load resistance (ohms) = power supply voltage (volts) = meter resistance (ohms) meter (theoretically = 0) Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC.
-
Page 8: Unit Operation
CAUTION! Any attempt to remove or tamper with the transducer cover will void the warranty and damage the unit. ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... -
Page 9: Pressure Limits
Maximum pressure limit for 1” Flaretek fitting connections at 65°C (149°F) is 372 kPa (54 PSIG). For detailed pressure limit information on Flaretek tube fitting connections, refer to the Maximum Pressure Capabilities chart in the Flaretek fittings product section on Entegris’ website at http://www.entegrisfluidhandling.com. -
Page 10: Linear Output Signal
20 mA 4 mA 0 PSIG Full scale Pressure Measurement 10 V or 5 V 0 PSIG Full scale Pressure Measurement ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... -
Page 11: Troubleshooting
5. Remove the access grommet (see Diagram A). 6. Locate the zero and span adjust- ment screws (see Diagram B). Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC. - Page 12 10. The calibration procedure is complete. Reinstall the access grommet. 11. Safely vent any applied pressure, disconnect the display and dis- connect the power. 12. Return the pressure transducer to service. ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300...
-
Page 13: Reference
ETL listed for conformance to UL Standard 2279, Class 1, Zone 0, 1 and 2, Ex ia IIA T6. Performance Specifications ference accuracy: ±1% of full scale (includes linearity, hysteresis and repeatability) at 23°C (73°F) Process temperature: 10–65°C (50–149°F) Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC. -
Page 14: Certifications
“Ex ia IIA T6” and may only be ments. The results of this testing are operated in hazardous locations with on file at Entegris and are available a 12–28 VDC power supply at upon request. The products that are ambient to 65°C (149°F) tempera-... -
Page 15: Ordering Information
* The 4–20 mA electrical output, operated with 12–28 VDC input, is ETL listed for conformance to UL Standard 2279, Class 1, Zone 0, 1 and 2, Ex ia IIA T6. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC. -
Page 16: Model 4210 Flow-Through
Kalrez 6375 UP / Kalrez 6375 UP * For detailed pressure limit information on Flaretek tube fitting connections, refer to the Maximum Pressure Capabilities chart in the Flaretek fittings product section on Entegris’ website at http://www.entegrisfluidhandling.com. ** The 4–20 mA electrical output, operated with 12–28 VDC input, is ETL listed for conformance to UL Standard 2279, Class 1, Zone 0, 1 and 2, Ex ia IIA T6. -
Page 17: Model 4130 Single-Port
0–5 VDC (12–30 VDC input) * For detailed pressure limit information on Flaretek tube fitting connections, refer to the Maximum Pressure Capabilities chart in the Flaretek fittings product section on Entegris’ website at http://www.entegrisfluidhandling.com. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... -
Page 18: Installation Drawings
25.2 mm (0.99”) ⁄ ” Flaretek 76.2 mm (3.00”) 26.9 mm (1.06”) ⁄ ” Receptacle with Flaretek 76.2 mm (3.00”) 29.0 mm (1.14”) ⁄ ” plug removed 11.4 mm (0.45”) ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... - Page 19 ” MNPT 76.2 mm (3.00”) 15.0 mm (0.59”) ⁄ ” FNPT 82.3 mm (3.24”) — ⁄ ” FNPT 88.9 mm (3.50”) — Receptacle with plug removed 11.4 mm (0.45”) Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC.
-
Page 20: Model 4210 Flow-Through
102.4 mm (4.03”) 21.6 mm (0.85”) ⁄ ” Flaretek 104.4 mm (4.11”) 108.5 mm (4.27”) 25.4 mm (1.00”) ⁄ 1” Flaretek 112.5 mm (4.43”) 120.7 mm (4.75”) 30.5 mm (1.20”) ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... - Page 21 102.4 mm (4.03”) 21.6 mm (0.85”) ⁄ ” Flaretek 104.4 mm (4.11”) 108.5 mm (4.27”) 25.4 mm (1.00”) ⁄ 1” Flaretek 112.5 mm (4.43”) 120.7 mm (4.75”) 30.5 mm (1.20”) Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC.
-
Page 22: Model 4130 Single-Port
79.2 mm (3.12”) 29.0 mm (1.14”) ⁄ ” MNPT 79.2 mm (3.12”) 15.0 mm (0.59”) ⁄ ” FNPT 87.9 mm (3.46”) — ⁄ ” FNPT 94.5 mm (3.72”) — ⁄ ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300... -
Page 23: Model 4230 Flow-Through
102.4 mm (4.03”) 21.6 mm (0.85”) ⁄ ” Flaretek 110.0 mm (4.33”) 108.5 mm (4.27”) 25.4 mm (1.00”) 1” Flaretek 118.1 mm (4.65”) 120.7 mm (4.75”) 30.5 mm (1.20”) Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300 ENTEGRIS, INC. -
Page 24: Repair And Warranty Service
Entegris is willing and able to repair or replace any such defective Entegris product or part or to refund the purchase price paid. - Page 25 Entegris promptly of any such defect. The exclusive remedy provided herein shall not be deemed to have failed of its essential purpose so long as Entegris is willing and able to repair or replace any nonconforming Entegris product or part or to refund the purchase price paid.
- Page 26 NT PRESSURE TRANSDUCER USER GUIDE ENTEGRIS, INC. Customer Service Tel. +1 763-502-0200 Customer Service Fax +1 763-502-0300...
- Page 27 Entegris, ® ® , FluoroPure ® and Flaretek ® are registered trademarks of Entegris, Inc. Kalrez ® and Viton ® are registered trademarks of DuPont Dow Elastomers, L.L.C. Teflon ® is a registered trademark of E.I. du Pont de Nemours and Company.
