- Page 1 P/N 01-1027289 | REV. A 04 /17 NT Pressure Transducer Models 4100, 4210 User Guide...
-
Page 2: Table Of Contents
Control Drawing ......17 Pressure Reference Accuracy ......... 7 Appendix ......... 18 Linear Output Signal ....8 For More Information ....22 Troubleshooting ......9 Terms and Conditions of Sale ..22 Product Warranties ....... 22 Entegris, Inc. | User Guide... -
Page 3: Safety Alert Symbol
WARNING! Attempting to install or operate standard NT 4000 following standard NT Pressure Series Pressure Transducers Transducer 4000 Series Models without reviewing the instruc- 4100 and 4210. These instruments tions contained in this manual have been designed for use in high... -
Page 4: Installation
NOTE: For detailed tube flaring stress or excessive bending from instructions, see “Flaretek tube the surrounding equipment. fitting flare and assembly procedure” at www.entegrisfluidhandling.com (follow the Fittings>Tube Fittings> Flaretek Tube Fittings links). Entegris, Inc. | User Guide... -
Page 5: Electrical Installation
5. The power supply must provide clean power and must be used only to power similar measurement-type devices. The power supply must not be used to power inductive loads, such as motors, relays or solenoids. These devices may produce User Guide | Entegris, Inc. -
Page 6: Warnings
Load Resistance: Voltage Output (0–5, 0–10 VDC) = meter resistance (ohms) meter (theoretically = 0) The output impedance is 1 kOhm. The input impedance should be ≥ 1 megohm for ± 0.1% load impedance error. Entegris, Inc. | User Guide... -
Page 7: Unit Operation
Opening the cover shall void the product warranty. WARNING! Any attempt to remove or tamper with the transducer cover will void the warranty and damage the unit. User Guide | Entegris, Inc. -
Page 8: Pressure Limits
Maximum over pressure can be limited by the fitting. Consult the fitting specification for maximum over pressure limits. WARNING! The pressure limits for standard NT Pressure Trans- ducers (4000 Series) decrease significantly for temperatures above 65°C (149°F). Exceeding these limits may result in personal injury or equipment damage. -
Page 9: Linear Output Signal
The output signal of the pressure transducer is a linear function proportional to the applied pressure. 20 mA 4 mA Pressure 0 psig Full scale Measurement 10 V or 5 V Pressure 0 psig Full scale Measurement User Guide | Entegris, Inc. -
Page 10: Troubleshooting
NT PRESSURE TRANSDUCER MODELS 4100, 4210 Troubleshooting Troubleshooting the NT Pressure Transducers (4000 Series) may be accomplished by measuring the out put signal of the pressure transducer with a battery powered current/voltage meter. The meter may be placed in series with the... -
Page 11: Reference
Electrical connection 6', 12', 30' FEP-jacketed pigtail or polypropylene 3-pin connector Electrical enclosure IP54 Performance Specifications ± 1% of full scale (includes linearity, hysteresis and Reference accuracy repeatability) at 23°C (73°F) Process temperature 10–65°C (50–149°F) User Guide | Entegris, Inc. -
Page 12: Certifications
Class I, Division 2 Group A–D, T6 10°C ≤ Ta ≤ 65°C hazardous environments. The results of this testing are on file at Entegris and are available upon request. All spec i fications are subject to change. Please contact the factory for the latest information. -
Page 13: Ordering Information
• F02 — Inlet/outlet port connection 150G = 1034 kPa (150 psig) • D06 — Electrical connector type (Flaretek and Pillar • A — Electrical outputs port connections • P1 — Sensor interface only) • U3 — Primary/secondary seal User Guide | Entegris, Inc. -
Page 14: Model 4210 Flow-Through
• P1 — Sensor interface • U3 — Primary/secondary seal * For detailed pressure limit information on Flaretek tube fitting connections, refer to the Maximum Pressure Capabilities chart in the Flaretek fittings product section on Entegris’ website at http://www.entegrisfluidhandling.com. Entegris, Inc. | User Guide... -
Page 15: Installation Drawings
76.2 mm 11.0 mm tube fitting (3.00") (0.43") ⁄ " Super 300 Type Pillar 76.2 mm 15.0 mm tube fitting (3.00") (0.59") ⁄ " Super 300 Type Pillar 76.2 mm 17.5 mm tube fitting (3.00") (0.69") User Guide | Entegris, Inc. -
Page 16: Model 4210 Flow-Through
21.6 mm (0.85") ⁄ " Flaretek tube fitting 104.1 mm (4.10") 108.5 mm (4.27") 25.4 mm (1.00") 1" Flaretek tube fitting 112.5 mm (4.43") 120.7 mm (4.75") 30.5 mm (1.20") Note: No NPT option on Model 4210. Entegris, Inc. | User Guide... - Page 17 21.6 mm (0.85") tube fitting ⁄ " Super 300 Type Pillar 104.4 mm (4.11") 88.4mm (3.48") 25.7 mm (1.01") tube fitting 1" Super 300 Type Pillar 111.8 mm (4.40") 98.6mm (3.88") 29.7 mm (1.17") tube fitting User Guide | Entegris, Inc.
-
Page 18: Control Drawing
NT PRESSURE TRANSDUCER MODELS 4100, 4210 Control Drawing 01-1033562 Nonincendive Field Wiring Required for Disconnecting Cable Options Entegris, Inc. | User Guide... -
Page 19: Appendix
Table 3. Nonincendive field wiring apparatus vs. associated nonincendive field wiring apparatus requirements NONINCENDIVE FIELD WIRING ASSOCIATED NONINCENDIVE APPARATUS (MODEL NT4100 /4200 RELATIONSHIP FIELD WIRING APPARATUS ≥ ≥ ≥ ≤ Ci + C cable (60 pf/ft) ≤ Li + L cable (0.2 uH/ft) User Guide | Entegris, Inc. - Page 20 Table 3 with the entity parameters in Table 2. 4100-XXXX-XXX-A00-B-XX-XX 4100-XXXX-XXX-DXX-B-XX-XX 4100-XXXX-XXX-XXX-B-XX-XX-PXX 4100-XXXX-XXX-A00-C-XX-XX 4100-XXXX-XXX-DXX-C-XX-XX 4210-XXXX-XXX-A00-B-XX-XX 4210-XXXX-XXX-DXX-B-XX-XX 4210-XXXX-XXX-XXX-B-XX-XX-TXX 4210-XXXX-XXX-A00-C-XX-XX 4210-XXXX-XXX-DXX-C-XX-XX 4210-XXXX-XXX-XXX-C-XX-XX-TXX Entegris, Inc. | User Guide...
-
Page 21: For More Information
Entegris’ products are subject to the Entegris, Inc. General Limited Warranty. To view and print this information, visit entegris.com and select the Legal & Trademark Notices link in the footer. Entegris does not warranty any failure in the case of customers using unapproved foreign components.
