Odor Removal Filter
SFC□40-FP2 Series
INSTRUCTION MANUAL
SM-P00159-A
• Read this Instruction Manual before using the product.
• Read the safety notes carefully.
• Keep this Instruction Manual in a safe and convenient place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFC 40-FP2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for CKD SFC 40-FP2 Series

Summary of Contents for CKD SFC 40-FP2 Series

  • Page 1 Odor Removal Filter SFC□40-FP2 Series INSTRUCTION MANUAL SM-P00159-A • Read this Instruction Manual before using the product. • Read the safety notes carefully. • Keep this Instruction Manual in a safe and convenient place for future reference.

  • Page 2: Preface

    • Since there are a wide variety of customer applications, it is impossible for CKD to be aware of all of them. Depending on the application or usage, the product may not be able to exercise its full performance or an accident may occur due to fluid, piping, or other conditions.

  • Page 3: Safety Information

    SM-P00159 SAFETY INFORMATION SAFETY INFORMATION When designing and manufacturing any device incorporating the product, the manufacturer has an obligation to ensure that the device is safe. To that end, make sure that the safety of the machine mechanism of the device, the pneumatic or water control circuit, and the electric system that controls such mechanism is ensured.

  • Page 4: Precautions On Product Use

    • For applications where life or properties may be adversely affected and special safety measures are required. (Exception is made if the customer consults with CKD prior to use and understands the specifications of the product. However, even in that case, safety measures must be taken to avoid danger in case of a possible failure.)

  • Page 5: Table Of Contents

    SM-P00159 CONTENTS CONTENTS PREFACE ........................... i SAFETY INFORMATION ....................ii Precautions on Product Use ..................iii CONTENTS ........................iv INSTALLATION ......................1 Environment ......................1 Unpacking ......................3 Mounting ......................3 Piping ........................3 USAGE ........................5 MAINTENANCE AND INSPECTION ................. 6 Daily Inspection ....................

  • Page 6: Installation

    SM-P00159 1. INSTALLATION 1. INSTALLATION 1.1 Environment WARNING Do not use the product in an atmosphere where sodium hypochlorite, synthetic oil, organic solvent, chemicals, cutting oil, screw lock agent, leak detection agent, hot water, or other hazardous factors are present or in a place where they may adhere to the product. Deterioration may occur since the plastic bowl is made of polyamide.
  • Page 7 SM-P00159 1. INSTALLATION Do not use the product in an environment where: • Ambient temperature is outside the range of 5°C to 45°C • Air can freeze • Water drop or cutting oil can splash onto the product • Condensation may occur due to high humidity and temperature change •...

  • Page 8: Unpacking

    SM-P00159 1. INSTALLATION 1.2 Unpacking CAUTION Do not open the packing of the product until just before piping to prevent foreign matters from entering the product. • Check that the model number ordered and the model number indicated on the product are the same. •...
  • Page 9 SM-P00159 1. INSTALLATION  Pipe cleaning Before piping, blow air into the pipes to clean the interior and to remove cutting chips and foreign matters.  Seal material Apply a seal tape or seal material to the screw threads leaving two or more threads at the pipe end uncovered or uncoated.

  • Page 10: Usage

    SM-P00159 2. USAGE 2. USAGE WARNING Use the product within the specifications. Ventilate sufficiently when using the product with nitrogen gas (N2) or carbon dioxide (CO2). Do not use the product for medical purposes or in any equipment or circuit that concerns human life.

  • Page 11: Maintenance And Inspection

    SM-P00159 3. MAINTENANCE AND INSPECTION 3. MAINTENANCE AND INSPECTION WARNING Stop supplying the pressure and make sure that there is no residual pressure before maintenance. Perform periodic inspections at least once every six months to detect cracks, scratches, and other deteriorations on the plastic bowl. Cracks, scratches, or other deteriorations may cause damage.

  • Page 12: How To Perform Maintenance

    SM-P00159 3. MAINTENANCE AND INSPECTION 3.3 How to Perform Maintenance 3.3.1 Plastic bowl  Removing the plastic bowl Latch (Push and turn.) Bowl guard 2018-12-25...

  • Page 13: Element

    SM-P00159 3. MAINTENANCE AND INSPECTION 3.3.2 Element Affix the maintenance label to the product to serve as a reminder of when to replace the element. Replace the element with a new one after one year of use (6,000 hours) or when the pressure drop reaches 0.1 MPa.

  • Page 14: Troubleshooting

    Air leaks from where bowl is mounted. Stop supplying the compressed air, remove the Bowl is damaged. bowl assembly, and replace the bowl assembly. If you have any other questions or concerns, contact your nearest CKD sales office or distributor. 2018-12-25...

  • Page 15: Warranty Provisions

    If the product specified herein fails for reasons attributable to CKD within the warranty period specified below, CKD will promptly provide a replacement for the faulty product or a part thereof or repair the faulty product at one of CKD’s facilities free of charge.
