PlatinumPLUS
Air Purification System
User and
Installation Manual
Congratulations on selecting SecureAire's most advanced
Air Purification System! SecureAire's patented design utilizes
ACTIVE Particle Control technology, proven to capture and
remove airborne contaminants from your home while
INACTIVATING™ (killing) viable airborne pathogens including
bacteria, viruses, and mold.
www.secureaire.com
| Proudly made in the U.S.A. | MN900-500-Rev E
Air
Purification
for a Safe,
Healthy,
and Clean
Environment™
Advertisement
Table of Contents
Related Manuals for SecureAire PlatinumPLUS
Summary of Contents for SecureAire PlatinumPLUS
- Page 1 PlatinumPLUS Air Purification System User and Installation Manual Congratulations on selecting SecureAire’s most advanced Air Purification System! SecureAire’s patented design utilizes ACTIVE Particle Control technology, proven to capture and Purification remove airborne contaminants from your home while for a Safe, INACTIVATING™...
-
Page 2: Legal Notices
Colliding & Coagulating Zone Conditioned Colliding Coagulated Captured + Killed Particles Particles Particles Particles (”Net Neutrals”) Transport of “Net Neutrals” into the occupied space www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E... -
Page 3: Before Installation
2000 Replacement Air Purification Cartridge Part Numbers: ROC1620-NG2 Platinum Series Cartridge Part Number 16x20x2 ROC1620-NG2 20x20x2 ROC2020-NG2 16x25x2 ROC1625-NG2 20x25x2 ROC2025-NG2 www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E... -
Page 4: Application Considerations
Before installation (continued) Application Considerations: The SecureAire Air Purifier is designed to work with gas, oil, and electric forced air furnaces and central air conditioning systems. Airflow considerations are vital to the heating and cooling system’s performance, longevity, and safety, as well as the performance of the SecureAire Air Purifier. - Page 5 If the installation of the unit requires the airflow direction to be reversed, this is easily accomplished by removing the main assembly (Step 6) and rotating it into the proper flow direction. www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E...
- Page 6 Installing the SecureAire Air Purifier: Upflow Furnace Example Step 2: Remove the PlatinumPLUS Assembly A. Unlatch the front door. B. Remove the main assembly. www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E...
- Page 7 Remove the existing wiring strain relief and when the unit is installed, additional relocate it if needed. www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E...
- Page 8 S-cleat type slip joints. If you are drilling holes, use locking pliers to help hold the cabinet in place during drilling. C. Inspect the SecureAire Air Purifier to make sure that no metal filings are lodged in the unit and the cabinet is free of any debris.
- Page 9 EAC terminals, follow the equipment manufacturer’s directions on how to make that connection. SecureAire Wiring Terminal Block Line Voltage: 120V/60 Hz www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E...
- Page 10 Step 9: System Operation Check A. With the door closed, turn on the SecureAire Air Purifier with the ON/OFF switch. The switch will glow with a green light indicating that the power supply is on and operating properly.
-
Page 11: Post-Installation Checklist
Consider asking the homeowner if they would like to program the thermostat’s fan control for intermittent, circulate, or constant fan control. www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E... -
Page 12: Replacing The Filter Cartridge
Once separated, gently pull out the used air purification cartridge without disturbing the accumulated dirt on the cartridge and place the cartridge in a large plastic bag for disposal. www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E... - Page 13 Step 6: Re-attaching the front door PlatinumPLUS Assembly and turning on the power switch. The SecureAire Air Purifier cartridge replacement is now complete! www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E...
-
Page 14: Specifications, Dimensions, And Approvals
Depth Model Width Height Depth ACS1620-NG2 20” 16” 6.75” ACS2020-NG2 20” 20” 6.75” ACS1625-NG2 25” 16” 6.75” ACS2025-NG2 25” 20” 6.75” www.secureaire.com | Proudly made in the U.S.A. | PlatinumPLUS Installation Guide | June 2022 | Part Number MN900-500-Rev E... - Page 15 1200 1400 1600 1800 2000 Airflow (CFM) Standards and Approvals The SecureAire PlatinumPLUS Air Purification System has been tested and verified to meet or exceed the following: • UL 867 Electrical Standard • CSA C22.2 No. 187-09 Electrical Standard •...
