Whole-Home Air Purification System
Installation and
User Manual
Congratulations on selecting SecureAire's most advanced
Whole-Home Air Purification System! SecureAire's patented
design utilizes ACTIVE Particle Control technology, proven to
capture and remove airborne contaminants from your home
while INACTIVATING™ (killing) viable airborne pathogens
including bacteria, viruses, and mold.
www.secureaire.com
| Proudly made in the U.S.A. | MN900-500
Safe,
Healthy,
and Clean
Indoor Air!
Advertisement
Related Manuals for SecureAire Platinum Series
Summary of Contents for SecureAire Platinum Series
- Page 1 Healthy, User Manual and Clean Indoor Air! Congratulations on selecting SecureAire’s most advanced Whole-Home Air Purification System! SecureAire’s patented design utilizes ACTIVE Particle Control technology, proven to capture and remove airborne contaminants from your home while INACTIVATING™ (killing) viable airborne pathogens including bacteria, viruses, and mold.
- Page 2 2000 cfm. ACTIVE Particle Control™ The SecureAire Whole-Home Air Purification System is based upon ACTIVE Particle Control™ technology that is continuously working to remove airborne contaminants in the living space, including particulates, pathogens, and VOCs.
-
Page 3: Before Installation
Before installation When Installing this Product: 1. This document provides instructions for the installation and electrical wiring of SecureAire’s Whole- Home Air Purification System. 2. Read these instructions carefully as failure to comply can damage the product or cause a hazardous condition. - Page 4 (For additional information see the SecureAire Residential Air Purification System Application Guidelines Addendum) The SecureAire Air Purifier is designed to work with gas, oil, and electric forced air furnaces and central air conditioning systems. Airflow considerations are vital to the heating and cooling system’s performance, longevity, and safety, as well as the...
-
Page 5: Choosing A Mounting Position
Before Installation (continued) Choosing a Mounting Position: The SecureAire Air Purifier mounts in any position within the return air duct, usually next to the furnace blower compartment. There are directional arrows on the filter to confirm proper cabinet location. See below for proper locations for the SecureAire Air Purifier in a variety of furnace and air handler installations. - Page 6 Step One: Review the installation plan and airflow direction Temporarily place the SecureAire Air Purifier on the floor, orienting as it will be when installed. Temporarily insert and remove the SecureAire Air Purifier to make sure there is adequate clearance for easy removal if that is ever necessary.
- Page 7 Installing the SecureAire Air Purifier: Upflow Furnace Example Step Two: Remove the door and filter A. Unlatch the front door. B. Remove the main filter. Step Three: Remove the grid access panel and (3) wire grids A. Remove the front plastic panel via the four (4) Philips head screws on the top of the panel and the (4) Phillips head screws on the bottom of the panel.
- Page 8 Step Four: Pre-wire the power supply (PRE-WIRE ONLY DO NOT CONNECT TO POWER) Installation of the SecureAire Air Purifier should be performed by a licensed electrician or a certified HVAC technician. Electrical wiring must comply with applicable local codes and standards.
- Page 9 S-cleat type slip joints. If you are drilling holes, use locking pliers to help hold the cabinet in place during drilling. C. Inspect the SecureAire Air Purifier to make sure that no metal filings are lodged in the unit and free of any debris.
- Page 10 May use silicone sealant, mastic, or UL-approved sealant tape. MOUNTING Step Nine: Connect power to the power supply Installation of the SecureAire Air Purifier should be performed by a licensed electrician or a certified HVAC technician. Electrical wiring must comply with applicable local codes and standards.
- Page 11 Step Ten: System Operation Check A. Turn on the SecureAire Air Purifier with the ON/OFF switch. The switch illuminates a green light indicating that the power supply is on. An audible clicking noise (4 times loud followed by 4 times soft) indicates that the system’s self-test procedure has confirmed proper operation and the high voltage...
- Page 12 Installing the SecureAire Air Purifier: Upflow Furnace Example Please check the installation for the following: System Airflow is in the direction of the arrows on the SecureAire filter. Turning vanes and transitions, if used, are properly installed. Joints in all sheet metal connections are sealed.
- Page 13 Installing the SecureAire Air Purifier: Upflow Furnace Example The SecureAire Whole Home Air Purification System is designed to require minimal maintenance. System maintenance is limited to the replacement of the system’s filter, which is easily accomplished using the following steps.
- Page 14 Installing the SecureAire Air Purifier: Upflow Furnace Example Step Four: Insert the new replacement filter. Insert the new filter making sure that the replacement filter seats against back of the SecureAire cabinet and the airflow arrows on the filter are pointing in the direction of the airflow.
-
Page 15: Specifications, Dimensions, And Approvals
R1625-PLT 16” 25” 2” ACS2025-PLT 22” 26” 6.75” R2025-PLT 20” 25” 2” Dimensional drawings of the SecureAire Whole Home Residential System 16x25 16x20 4 ¼ 8 ¼ 8 ¼ 3 ¼ 6 ¾ 6 ¾ 20x20 20x25 3 ¼ 4 ¼... - Page 16 1400 1600 1800 2000 Airflow (CFM) Standards and Approvals The SecureAire Whole-Home Air Purification System has been tested and verified to meet or exceed the following: • UL 867 Electrical Standard • CSA C22.2 No. 187-09 Electrical Standard Safe, Healthy, and Clean Indoor Air! To Learn More Visit our website at: www.secureaire.com/residential...
