Summary of Contents for Peugeot Motorcycles XP400 2023
- Page 1 XP400 Livret de bienvenue & d’entretien Welcome & maintenance booklet...
- Page 3 Bienvenue Welcome Herzlich willkommen Benvenuto Bienvenidos Welkom Καλώς ήρθατε Välkommen Bem-vindo Tervetuloa Velkommen...
-
Page 5: Table Of Contents
TABLE OF CONTENTS Pre-delivery inspection...........1 Information..............2 Diagnostic and Personal data........2 Manufacturer's warranty..........3 Important................5 Products to use............5 Maintenance advice.............5 Cleaning the vehicle............ 5 Environment / Recyclable..........6 Extended periods of immobilisation and storage..6 Quick-start guide............7 Starting and driving............7 Controls............... 8 Instruments.............. -
Page 7: Pre-Delivery Inspection
MEMORANDUM PRE-DELIVERY INSPECTION Name: ................VIN: VGA ..................The dealer must carry out the pre-delivery inspection and supply the preparation sheet for the delivered First name: ..............vehicle..................Address: ................Inspection on delivery ..................Customer signature Post code: ............... I have inspected the appearance of the vehicle and .................. -
Page 8: Information
INFORMATION DIAGNOSTIC AND PERSONAL DATA The following symbols mean: You have just bought a Peugeot vehicle. We would like When diagnostic tools are connected to your vehicle, You are advised to read the full version of to thank you for purchasing one of our products. they collect data. -
Page 9: Manufacturer's Warranty
MANUFACTURER'S WARRANTY This warranty starts from the first time the vehicle is Conditions of application of the commercial registered and applies to your vehicle with the exception warrenty (March 2022 edition) For optimal cover for work to be carried out on your The manufacturer of your vehicle, PEUGEOT •... - Page 10 The warranty applies on condition that: The warranty does not cover: • Repairs resulting from long storage periods under unsuitable conditions; • The first "warranty" service has been carried • Maintenance operations (such as, but not limited out and the vehicle has been regularly serviced to: oil change, lubrication, adjustment, cleaning, •...
-
Page 11: Important
IMPORTANT Maintenance advice Cleaning the vehicle Ensure that the servicing schedule for your vehicle is Products to use The bodywork is made of plastic parts that can strictly followed to maintain your contractual warranty be painted or are shiny. Do not use solvents or Fuel Exclusively: rights. -
Page 12: Environment / Recyclable
Environment / Recyclable Extended periods of immobilisation and storage Worn parts replaced during routine maintenance If the vehicle has to be immobilised for more (mechanical parts, battery, etc.) must be disposed of than 1 months, you are advised to carry out the with specialised bodies. -
Page 13: Quick-Start Guide
QUICK-START GUIDE • The driver must carry the smart key key on his/her • The anti-lock braking system (ABS) is designed to person. prevent the wheels from locking up during braking. Starting and driving • Press and hold the rotating knob for one second to •... -
Page 14: Controls
Controls Left controls Right controls 5. "EXIT" control. This control enables: 1. "SELECT" control. • access to the instrument panel personalisation This control enables: menu (Press and hold for 2 seconds). • access to the connectivity menu* (Press and hold •... -
Page 15: Instruments
INSTRUMENTS Digital display Warning lights The warning lights inform the driver of the start-up of a system or appearance of a malfunction. Refer to the online user manual for further information. 1 - Digital display (I-CONNECT). Emissions control system failure warning 2 - Analogue speedometer. -
Page 16: Equipments
EQUIPMENTS Resetting the tripmeter The driver's saddle opens automatically when the opening button is pressed. Make sure you • Reset the tripmeter by simultaneously pressing The user manual describes other equipment. remove any objects placed on top of it before the "SELECT"... -
Page 17: Accessory Socket (Usb)
Accessory socket (USB) Adjusting the brake lever position The brake levers are equipped with a position adjustment knob. To adjust the distance (A) between the lever and the handle, turn the adjustment knob and push the lever away from the handle. Ensure the position selected on the knob (m) and the marking on the lever (r) are properly aligned. -
Page 18: Advice
ADVICE • With the smart key present, press the fuel flap • To correctly measure the oil level, place the vehicle on opening button for 1 second. the centre stand on flat ground. Fuel supply • Start the engine, let it run for a few minutes and then stop it. -
Page 19: No Smart Key Recognition
PERIODIC SERVICING • If the oil level is close to the minimum mark or lower, Possible causes of non-recognition: you are advised to immediately top up the level to 3/4 • Low battery or incorrectly positioned. Special important points: in small amounts using the oil recommended by the •... -
Page 20: Service Schedule
SERVICE SCHEDULE Servicing must be performed by a PEUGEOT MOTOCYCLES registered representative. Operations to be carried out 1000km 5000km* 10000km 15000km* 20000km Annual maintenance 600mi 3100mi* 6200mi 9400mi* 12400mi or 1 months Engine Engine oil Oil filter Valve clearances I Every 40000 km / 25000 mi Spark plug Intake air filter R Every 10000 km (5000 km if harsh use servicing) - Page 21 Operations to be carried out 1000km 5000km* 10000km 15000km* 20000km Annual maintenance 600mi 3100mi* 6200mi 9400mi* 12400mi or 1 months Cycle part Steering: No sticking point / No play Wheels: Condition and runout / No play Wheels: Spoke tension Tyres: No cracks, wear and pressure Fork/Front suspension: Condition, operation and no leakage Fork oil Rear suspension: Condition, operation and no leakage...
- Page 22 Operations to be carried out 1000km 5000km* 10000km 15000km* 20000km Annual maintenance 600mi 3100mi* 6200mi 9400mi* 12400mi or 1 months Electrical equipment Lighting and signalling Headlight height adjustment Brake light switches smart key battery R Once every 2 years Battery: Charge level and no leakage Miscellaneous Processors: Reading of fault codes and update Overall operation: Road test...
- Page 23 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ - - - - - / - - - - - - / - - - - - - - - - - - - / - - - - - - / - - - - - - -...
- Page 24 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ - - - - - / - - - - - - / - - - - - - - - - - - - / - - - - - -/ - - - - - -...
- Page 25 _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi...
- Page 26 _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi _ _ _ _ _ _ _ km _ _ _ _ _ _ _ mi...
- Page 27 Peugeot Motocycles recommends Peugeot Motocycles SA Rue du 17 Novembre F-25350 Mandeure Tél. +33(0)3 81 36 80 00 Fax +33(0)3 81 36 80 80 RCS Belfort B 875 550 667 www.peugeot-motocycles.fr www.peugeot-motocycles.com ISO 9001 (Édition 2008) / N°SQ/1956 0 800 007 216 Dans un souci constant d’amélioration Peugeot Motocycles se réserve le droit de supprimer, modifier ou ajouter toutes références citées.
- Page 30 11.401150.00 02/23 v2 Guide d’utilisation en ligne i-Connect® : application Peugeot Motocycles disponible sur Online user’s guide i-Connect® : Peugeot Motocycles app available on Crédits photo : Photographe Jean-François Muguet / Agence : 87seconds...
