Operating Manual
MultiBlast PRO Pressure Sandblasting Cabinet
December 2022
CREATE A HAZARDOUS ENVIRONMENT.
FAILURE TO COMPLY WITH THIS INFORMATION MAY CAUSE SERIOUS INJURY
OR DEATH.
Capital Machinery Sales Pty Ltd
IMPORTANT – READ THIS INFORMATION CAREFULLY PRIOR TO
OPERATING THE EQUIPMENT.
ALL ABRASIVE BLASTING OPERATIONS ARE DANGEROUS AND
www.capitalmachinery.com.au
Index
Section 1.0
Important Information
Section 2.0
How The System Works
Section 3.0
Installation & Initial Set Up
Section 4.0
System Operation & Adjustments
Section 5.0
Preventative Maintenance
Section 6.0
Troubleshooting
Section 7.0
Replacement Parts Listing
Section 8.0
Specifications
Call 1800 706620

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO and is the answer not in the manual?

Questions and answers

Related Manuals for MultiBlast PRO

Summary of Contents for MultiBlast PRO

  • Page 1 Operating Manual MultiBlast PRO Pressure Sandblasting Cabinet December 2022 Index Section 1.0 Important Information Section 2.0 How The System Works Section 3.0 Installation & Initial Set Up Section 4.0 System Operation & Adjustments Section 5.0 Preventative Maintenance Section 6.0 Troubleshooting Section 7.0...
  • Page 2 This equipment is not designed for use in areas designated as hazardous. Contact your local MultiBlast Australia office/representative prior to operating this equipment in a hazardous area.
  • Page 3 How The System Works 2.1 The MultiBlast Australia pressure blast cabinets feature a cabinet to enclose and contain the blasting action , a pneumatically operated , safety interlocked blast pot system , and a dust collection system to ventilate the blast cabinet.
  • Page 4 2.2.3 In this state, even if the foot pedal is operated, the blasting system will not operate as the cabinet door(s) are open, with the door interlock valves in the closed position. 2.2.4 For the blasting system to operate, the cabinet door(s) must be closed, allowing the door striker to contact the door interlock valve plunger, which opens the air circuit.
  • Page 5 2.2.6 With the blast pot pressurised, compressed air is fed to the abrasive valve through the pusher line. As this air passes through the abrasive valve, the abrasive media within the blast pot is gravity fed into the abrasive valve, where is mixes with the compressed air. 2.2.7 The air and abrasive media are then discharged at high velocity through the blast hose, exiting at the blast nozzle attached to the end of the blast hose.
  • Page 6 The ventilation system 2.3.1 The cabinet ventilation system is provided to improve visibility within the blast cabinet for the operator, and also reduce the amount of dust within the abrasive mix. 2.3.2 Depending on the application and cabinet model selected, the ventilation dust collector may be either a drum type unit, or a reverse pulse dust collector.
  • Page 7 3.1 The MultiBlast Australia blast cabinets do not require any special foundations , but should be installed on a flat, level surface to provide a stable installation. The system will be shipped in a semi-knocked down condition, with most smaller components transported within the cabinet itself.
  • Page 8 Position the dust collector within approximately 1.5m of the rear of the blast cabinet. Then simply slide the hose over the cabinet spigot, and clamp firmly in place using the worm drive clamps provided. Repeat this process with the dust collector inlet spigot. See figures 7 – 9. Figure 7 Figure 8 PRO800, PRO1200, PRO1500 &...
  • Page 9 Figure 11 Figure 12 For models with reverse pulse (RP) dust collection, position the 10-litre dust bin directly below the dust collector hopper, and connect the spigot on the lid of the bin to the dust collector using the wire reinforced hose and worm drive clamps provided. See figure 12. Re-connect the pneumatic control line tubing as follows –...
  • Page 10 GREEN TUBING RETURN FROM INTERLOCK VALVE TO SIGNAL SIDE OF AIR CONTROL VALVE FIGURE 18 FIGURE 17 3.8.3 Black tubing – (For units with drum dust collector A201122-3) – Connect one end to the second port on the supply side of the blast pot piping (see figure 19) and the other end to the mini ball valve located on the top of the dust collector lid (see figure 20) BLACK TUBING FROM AIR MANIFOLD TO...
  • Page 11 3.9.2 Compressed air supply – All cabinet models (except PRO1000RP) require two (2) compressed air connections. One for the blast air supply and another for the dust collector cartridge cleaning system. The blasting system air connection point is located at the ball valve mounted on the air control valve assembly.
  • Page 12 3.10 Initial Set Up WARNING – Heavy lifting required. Take all necessary precautions and use appropriate lifting equipment to avoid injury. 3.10.1 Using the cabinet switch mounted on the front of the cabinet (except PRO1000RP), turn on the cabinet light assembly, and using the dust collector switch, turn on the dust collector fan.
  • Page 13 3.10.7 For initial operation, set the “on” duration time at 0.5 seconds, and the frequency “off” time at 3 minutes. Depending on the operating conditions, it will be necessary to adjust the pulse timer to suit the conditions after a period of operation. Refer to Section 5.0 Preventative Maintenance for further information.
  • Page 14 System Operation and Adjustments Check that that all cabinet and dust collector doors are in the closed position. Slowly open the blasting system isolation ball valve, which will send air supply to the foot pedal control. WARNING – The blasting system is now ready and will activate if the blast pedal is operated.
  • Page 15 The operator now stands in front of the cabinet and place their hands/arms into the left and right glove openings respectively. Take a firm hold of the nozzle holder assembly and depress the blast foot pedal with a foot. Blasting will now commence. Check closely the abrasive and air mix as it discharges from the blast nozzle.
  • Page 16 Preventative Maintenance Note: This maintenance schedule should be used as a general guide only. It does not consider any requirements which may occur on specific applications and working conditions. Daily 5.1.1 Drain any accumulated water from moisture trap bowl on the bottom of the blast pressure regulator.
  • Page 17 5.1.3 Drum dust collector – With the fan turned off, turn on the compressed air supply to the cartridge vibrator, and allow it to run for 2-3 minutes VIBRATOR CONTROL VALVE 5.1.4 Turn off the air supply, unlatch the drum lid and lift off the fan and cartridge assembly.
  • Page 18 5.2.3 Remove the blast hose coupling locking pin and disconnect the blast hose from the abrasive control valve. Carefully inspect the condition of both couplings and coupling gaskets. Replace the coupling and/or gasket if they are showing any signs of wear or grooving.
  • Page 19 WARNING – The filter cartridge will become heavy when fully dust laden. Use appropriate caution when releasing the filter cartridge from the hanger rod. WARNING – Breathing airborne dust from any abrasive media may cause lung disease or other serious injury. Always wear suitably designed respiratory protection when handling any abrasive media and/or waste dust, and when in the immediate area during any abrasive blasting operations.
  • Page 20 5.5.6 Check the condition of the urethane sleeve. The sleeve should be replaced if the sleeve ports have worn by more than 2mm. INSPECT URETHANE SLEEVE FOR WEAR 5.5.7 Carefully re-assemble Mini Micro valve, ensuring all seals and o rings are correctly seated and positioned.
  • Page 21 Section 6.0 Troubleshooting Fault Possible Cause Remedy Blast system will not Check blast isolation valve is open and No compressed air supply operate air compressor is operating Cabinet door open Close door Check interlock valve operation and Faulty door interlock replace if required Check pedal operation and replace if Faulty foot pedal...
  • Page 22 Replacement Parts Cabinet Parts – Models PRO 1000, PRO800, PRO1200RP & PRO1200 Part Number Item Description Unit PRO1000 PRO800 PRO1200RP PRO1200 Light Switch WS226 Operator Window 1C-G900520-1 Window Seal 1C-ABSW-97 VM230-02-05A Door Interlock Valve Light Assembly FBL225WCT 1C-G900520-16 Light Glass...
  • Page 23 Cabinet parts – Models PRO1500RP, PRO1500, PRO1800RP & PRO 1800 Part Number Item Description Unit PRO1500RP PRO1500 PRO1800RP PRO1800 Light Switch WS226 1C-G900520-16 1C-G900520-16 (x 2) Operator Window S210233 S210233 (x 2) Window Seal Door Interlock Valve VM230-02-05A FBL225WCT Light Assembly...
  • Page 24 Dust Collector Parts – Drum Type – 200L – Model A201122-3 Item Description Unit Part Number Filter Cartridge A460 Hanger Rod B890125-1 Vibrator A890212 Fan Impellor 788-CS160 Dust Collector Parts - Reverse Pulse Type - Model A201123 Item Description Unit Part Number A460 Filter Cartridge...
  • Page 25 Pressure Blast Parts Capital Machinery Sales Pty Ltd www.capitalmachinery.com.au Call 1800 706620...
  • Page 26 Pressure Blast Parts PART NO. PRO800 PRO1200RP PRO1500 PRO1800RP ITEM DESCRIPTION Assembly - Bare Blast Pot A201688 Seal Band - 20L Pot S210228 Clamp - Seal Band PSCLAMP Assembly - Blow Down Gun A201131 BHS1327 BHS1327 BHS1327 BHS1327 Hose - Blast Per M (4m) (5m)
  • Page 27 Blast Vessel Parts PART NO. PRO800 PRO1200 PRO1500 PRO1800 ITEM DESCRIPTION Assembly – Bare Pot Sub Assy A201726 Pop Up Valve - Small A201289 O Ring - Small O201291 Retaining Flange - Small F930035-1 Gasket-Fibre-50NB-Table E G202410 Washer-Flat-16mm Bolt-Hex Head-M16 x 35mm Wheel –...
  • Page 28 Door Interlock Parts PART NO. A201675-1 A201675-2 PRO800 PRO1200 PRO1500 PRO1800 ITEM DESCRIPTION Bracket - Interlock Valve B201654 B201654 Valve-3/2-Straight VM320-02-05A VM320-02-05A Plunger Foot Pedal-3/2-With 4F210-08G-23 4F210-08G-23 Shroud Tube-Nylon-8mm-Green T0806-G T0806-G Tube-Nylon-8mm-Red T0806-R T0806-R Elbow-1/4" BSP x 8mm KQ2L08-02NS KQ2L08-02NS Capital Machinery Sales Pty Ltd www.capitalmachinery.com.au Call 1800 706620...
  • Page 29 Blast Pot Piping Capital Machinery Sales Pty Ltd www.capitalmachinery.com.au Call 1800 706620...
  • Page 30 PART NO. A201691 PRO800 PRO1200 PRO1500 PRO1800 ITEM DESCRIPTION HOSE BARB - 1/2" BSP X 1/2" - BRASS B201857 BALL VALVE - M & F - 1/2" BSP V201460 NIPPLE - 1/2" BSP N201495 MANIFOLD - 5 WAY - 1/2" BSP M950236 BUSH - REDUCING - 1/2"...
  • Page 31 Air Control Valve Capital Machinery Sales Pty Ltd www.capitalmachinery.com.au Call 1800 706620...
  • Page 32 PRO45-20L MODEL AUTO AIR VALVE – 3/4" ASSY NO. A201082 ITEM DESCRIPTION PART NO. BODY - AIR CONTROL VALVE – ¾” B201083 COVER - AIR CONTROL VALVE C201084 CAP - AIR CONTROL VALVE C201067 DIAPHRAGM - AIR CONTROL VALVE D201085 WASHER - FLAT W201069 BUSH - INNER...
  • Page 33 7.10 Exhaust Valve PRO45-20L MODEL EXHAUST VALVE - 1" ASSY NO. A201282 ITEM DESCRIPTION PART NO. ASSY-EXHAUST VALVE-1” A201282 KIT - DIAPHRAGM A201283 7.11 Exhaust Control Line PRO45-20L MODEL ASSY NO. A201611 ITEM DESCRIPTION PART NO. AIRLINE - 1/4" (6MM) ID A201627 HOSE CLIP OTK08...
  • Page 34 7.13 Mini Micro Valve Capital Machinery Sales Pty Ltd www.capitalmachinery.com.au Call 1800 706620...
  • Page 35 PRO45-20L MODEL MINI MICRO VALVE – 3/4" ASSY NO. A201390 ITEM DESCRIPTION PART NO. CONTROL KNOB C201217 VALVE CAP - TOP V201218 PLUNGER P201219 VALVE BODY – ¾” V201391 SLEEVE S201393 VALVE CAP - BOTTOM V201392 ROLL PIN – 5mm x 50mm BOLT –...
  • Page 36 Section 8.0 Specifications Cabinets PRO1000RP PRO800 PRO1200RP PRO1200 PRO1500RP PRO1500 PRO1800RP PRO1800 Power 240V Single Phase 10amp Requirement 9l/sec 21l/sec 9l/sec 21l/sec 9l/sec 21l/sec 9l/sec 21l/sec @ 138 @ 138 @ 138 @ 138 690kPA 690kPA 690kPA 690kPA Compressed Air Requirement 45cfm 45cfm...
