Operating Manual
MultiBlast PRO900W
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MultiBlast PRO900W
Summary of Contents for MultiBlast PRO900W
- Page 1 Page Technical Data Important Information General Description Installation System Operation Maintenance Replacement Parts WARNING – Do not operate this equipment without reading and understanding the contents of this manual. P a g e 1 | 15 Operating Manual MultiBlast PRO900W...
-
Page 2: Section 1.0 Technical Data
Blast Nozzle Size 6mm (1/4") Air Jet Size 3mm (1/8") Cabinet Light 240V 13Watt Water Capacity 25 Litres Cabinet Extraction Fan 38Watt x 2 off Cabinet Window Size 500mm x 300mm P a g e 2 | 15 Operating Manual MultiBlast PRO900W... - Page 3 Ensure that the equipment is correctly serviced and maintained as specified in this manual, and that only genuine MultiBlast replacement parts are utilised. Failure to use genuine replacement parts may void your warranty.
- Page 4 This equipment is not designed for use in areas designated as hazardous . Contac t MultiBlast Australia prior to operating this equipment in a hazardous area. All compressed air fittings, connections and hoses must be in good condition, fit for purpose, correctly sized and fitted, and carefully inspected prior to use.
- Page 5 Section 3.0 General Description The MultiBlast PRO900W Wet Blast Cabinet is designed to mix abrasive media and water for abrasive blasting applications within a stainless steel cabinet . A pump is provided to deliver the abrasive and water mix to the blast gun, where it is mixed with the incoming compressed air supply.
- Page 6 An overflow outlet is located on the cabinet lower hopper at the rear if the cabinet. A water receptacle should be placed underneath the overflow to trap any excess water as it flows out. Water overflow outlet P a g e 6 | 15 Operating Manual MultiBlast PRO900W...
- Page 7 The switch hose simply pushes onto the panel fitting. Then place the foot switch on the floor directly in front of the cabinet. Foot switch connection point Foot switch P a g e 7 | 15 Operating Manual MultiBlast PRO900W...
- Page 8 Section 5.0 System Operation Check that the MultiBlast PRO900W cabinet has been correctly installed as per Section 4.0 of this manual. Turn on the main power supply. Turn on the compressed air supply. The input pressure gauge on the control panel will display the incoming air pressure.
- Page 9 Note – The cabinet is fitted with a safety door interlock which will prevent the system from operating with the door open. Door Safety Interlock Switch P a g e 9 | 15 Operating Manual MultiBlast PRO900W...
- Page 10 To operate the wiper manually, rotate the lever located on the wiper drive assembly through an arc left to right. Window Wiper Manual Lever Window Wiper Automatic Control Knob P a g e 10 | 15 Operating Manual MultiBlast PRO900W...
- Page 11 Cabinet Drain Valve 5.20 Once fully drain and cleaned, refill the system with water and abrasive media as per Section 5.6 and 5.7. P a g e 11 | 15 Operating Manual MultiBlast PRO900W...
- Page 12 Feel along the length of the blast hose between the blast gun and the water pump. Check for any soft spots which will indicate hose wear. Replace the hose length as necessary. P a g e 12 | 15 Operating Manual MultiBlast PRO900W...
- Page 13 Cabinet ventilation fans 6.3.2 Remove and dismantle the water pump and check for wear on the pump impeller and housing. Replace items as required. P a g e 13 | 15 Operating Manual MultiBlast PRO900W...
-
Page 14: Section 7.0 Replacement Parts
Section 7.0 Replacement Parts Suction Blast Gun Assembly Ø 'A' MULTIBLAST WET BLAST SUCTION GUN ASSY NO. A900300-1 ITEM DESCRIPTION PART NO. BODY-SUCTION GUN B900306 HOLDER-BLAST NOZZLE H900308 SCREW-HEX HEAD-6MM X 15MM LONG HOLDER-AIR TIP H900302-1 O RING-25MM OD X 2.5MM DIAMETER... - Page 15 PART NO. CABINET WINDOW - 500mm x 300mm G900520-22 AIR HOSE - 13mm AHPVC13 SUCTION BLAST HOSE-13mm 2.2m ABH13SUCT 1 PR CABINET GLOVES GLOVE27SBS-200 SUCTION BLAST GUN-COMPLETE ASSEMBLY A900300-1 P a g e 15 | 15 Operating Manual MultiBlast PRO900W...
