MultiBlast PRO 1200W Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Index
Section
Description
1
Technical Data
2
Important Information
3
General Description
4
Installation
5
System Operation
6
Maintenance
7
Replacement Parts
WARNING – Do not operate this equipment without
reading and understanding the contents of this manual.
Page
2
3
5
6
8
12
14
P a g e
1 | 18
Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO 1200W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MultiBlast PRO 1200W

Summary of Contents for MultiBlast PRO 1200W

  • Page 1 Important Information General Description Installation System Operation Maintenance Replacement Parts WARNING – Do not operate this equipment without reading and understanding the contents of this manual. P a g e 1 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...

  • Page 2: Section 1.0 Technical Data

    Air Jet Size 3mm (1/8") Cabinet Light 240V 13Watt Water Capacity 25 Litres Cabinet Extraction Fan 38Watt x 2 off Cabinet Window Size 500mm x 300mm P a g e 2 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...

  • Page 3: Section 2.0 Important Information

    Ensure that the equipment is correctly serviced and maintained as specified in this manual , and that only genuine MultiBlast Australia replacement parts are utilised . Failure to use genuine replacement parts may void your warranty.
  • Page 4 This equipment is not designed for use in areas designated as hazardous. Contact you MultiBlast Australia prior to operating this equipment in a hazardous area. All compressed air fittings, connections and hoses must be in good condition, fit for purpose, correctly sized and fitted, and carefully inspected prior to use.
  • Page 5 Section 3.0 General Description 3.1 The MultiBlast PRO 1200 W Wet Blast Cabinet is designed to mix abrasive media and water for abrasive blasting applications within a stainless steel cabinet . A pump is provided to deliver the abrasive and water mix to the blast gun, where it is mixed with the incoming compressed air supply.
  • Page 6 An overflow outlet is located on the cabinet lower hopper at the rear if the cabinet. A water receptacle should be placed underneath the overflow to trap any excess water as it flows out. Water overflow outlet P a g e 6 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 7 The switch hose simply pushes onto the panel fitting. Then place the foot switch on the floor directly in front of the cabinet. Foot switch connection point Foot switch P a g e 7 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...

  • Page 8: Section 5.0 System Operation

    Section 5.0 System Operation Check that the MultiBlast PRO1200W cabinet has been correctly installed as per Section 4.0 of this manual. Turn on the main power supply. Turn on the compressed air supply. The input pressure gauge on the control panel will display the incoming air pressure.
  • Page 9 Note – The cabinet is fitted with a safety door interlock which will prevent the system from operating with the door open. Door Safety Interlock Switch P a g e 9 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 10 Control Switch 5.15 The wiper arm sweeping arc is adjustable. To adjust the sweeping arc – 5.15.1 Remove the wiper arm 5.15.2 Remove the gearbox cover P a g e 10 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 11 5.15.13 Turn on the motor to the park position and refit the wiper arm. DEGREE 70° 60° 80° 90° 45° 40° 50° 55° 100° 83° 110° 120° P a g e 11 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 12 5.18 To drain the cabinet, place a suitable sized container beneath the drain valve located on the rear of the cabinet pump hopper. Open the drain valve, and allow the system to drain out. P a g e 12 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 13 Cabinet Drain Valve 5.20 Once fully drain and cleaned, refill the system with water and abrasive media as per Section 5.6 and 5.7. P a g e 13 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 14 6.2.4 Feel along the length of the blast hose between the blast gun and the water pump. Check for any soft spots which will indicate hose wear. Replace the hose length as necessary. P a g e 14 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 15 Cabinet ventilation fans 6.3.2 Remove and dismantle the water pump and check for wear on the pump impeller and housing. Replace items as required. P a g e 15 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 16 O RING-25MM OD X 2.5MM DIAMETER ADAPTOR-HOSE A900301-2 HOSE BARB-1/4" BSP X 1/2" BARB P3-0804 BOLT-HEX HEAD-6MM X 15MM WASHER-FLAT-6MM AIR TIP-1/8" T900309-4 BLAST NOZZLE-1/4" N900310-14 P a g e 16 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
  • Page 17 CABINET WINDOW - 500mm x 300mm G900520-22 AIR HOSE - 13mm AHPVC13 SUCTION BLAST HOSE-13mm 2.2m ABH13SUCT CABINET GLOVES 1 PR GLOVE27SBS-200 SUCTION BLAST GUN-COMPLETE ASSEMBLY A900300-1 P a g e 17 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...

  • Page 18: Wiper Assembly

    Wiper Assembly WIPER ASSEMBLY ASSY NO. A201695 ITEM DESCRIPTION PART NO. WIPER ARM W202658 WIPER BLADE W202657 SWITCH-3 POSITION M22-K10 MOTOR ASSEMBLY-12V/24V TMC-00902 POWER SUPPLY-24VDC S8VK-C06024 P a g e 18 | 18 Operating Manual MultiBlast PRO1200W Wet Blasting Cabinet...
