OSD and Power Lock Settings ... 7 Adjusting the Screen Image ... 8 Main Menu Controls ... 10 Other Information Specifications ... 13 Troubleshooting... 14 Customer Support ... 15 Cleaning the LCD Display ... 16 Limited Warranty ... 17 ViewSonic VE910/VE910b...
The length of time to reactivate the system unit shall be reasonable for the user. Labelled products must meet strict environmental demands, for example, in respect of the reduction of electrical and magnetical fields as well as work load and visual ergonomics. ViewSonic VE910/VE910b...
Page 4
TCO Development aims at restricting the use of lead. * Bio-accumulative is defined as substances which accumulate in living organisms. **Lead, Cadmium and Mercury are heavy metals which are bio-accumulative. ViewSonic VE910/VE910b...
92/31/EEC and 93/68/EEC Art.5 with regard to “Electromagnetic compatibility,” and 73/23/EEC as amended by 93/68/EEC Art.13 with regard to “Safety.” User Information for all Countries Notice: Use the cables which are included with the unit or specified. ViewSonic VE910/VE910b...
15. The apparatus shall only be used between 5° tilted forward and 20° tilted backward as normal operation position. If the tilt angle exceeds 20°, it shall be used for wall mounting or packaging only. ViewSonic VE910/VE910b...
® NERGY Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.
NOTE: The CD includes the User Guide PDF files and INF/ICM display optimization files. The INF file ensures compatibility with Windows operating systems, and the ICM file (Image Color Matching) ensures accurate on-screen colors. ViewSonic recommends that you install both the INF and ICM files.
NOTE: Windows users may receive a message asking them to install the INF file. This is on the CD. 4. Insert the ViewSonic Wizard CD into the computer’s CD drive. Follow the on-screen instructions. If your computer does not have a CD-ROM drive, see “Customer Support”...
Wall Mounting (Optional) To obtain a wall-mounting kit, contact ViewSonic instructions that come with the base mounting kit. To convert your LCD display from a desk- mounted to a wall-mounted display, do the following: ViewSonic VE910/VE910b or your local dealer. Refer to the ®...
LCD display’s power will automatically turn ON when power is restored. • Power Button Unlock: Press and hold [1] and the down arrow ViewSonic VE910/VE910b for 10 seconds. If any buttons are again for 10 seconds.
Also a shortcut to Auto Image Adjust. Displays the Main Menu or exits the control screen and saves adjustments. ViewSonic VE910/VE910b Main Menu with OSD controls Front Control Panel shown below in detail Power light Green = ON Orange = Power Saving...
Page 13
(The black border around the edge of the screen should barely touch the illuminated “active area” of the LCD display.) ViewSonic VE910/VE910b The line at the bottom of the screen shows the current functions of buttons 1 and 2:...
9300K - Adds blue to the screen image for cooler white (used in most office settings with fluorescent lighting). 6500K - Adds red to the screen image for warmer white and richer red. 5400K - Adds green to the screen image for a darker color. ViewSonic VE910/VE910b...
Page 15
H. Size (Horizontal Size) adjusts the width of the screen image. Fine Tune sharpens the focus by aligning text and/or graphics with pixel boundaries. NOTE: Try the Auto Adjust function before using the Fine Tune control. Sharpness adjusts the clarity and focus of the screen image. ViewSonic VE910/VE910b...
Page 16
OSD Background allows the user to turn the OSD background On or Off. Memory Recall returns the adjustments back to factory settings if the display is operating in a factory Preset Timing Mode listed in the Specifications of this manual. ViewSonic VE910/VE910b...
Preset Timing Mode (pre-adjusted to VESA Warning: Do not set the graphics card in your computer to exceed these refresh rates; doing so may result in permanent damage to the LCD display. Macintosh computers older than G3 require a ViewSonic ViewSonic. ViewSonic VE910/VE910b 19”...
Loose or broken pins in the cable connector could cause an improper connection. • Connect the LCD display to another computer. • If you have an older graphics card, contact ViewSonic Control buttons do not work • Press only one button at a time.
Zealand Singapore, Southeast www.viewsonic.com.sg/support/ Asia, and India South Africa and other www.viewsonic.com countries Hong Kong www.hk.viewsonic.com/support/ T= +852 3102 2900 Macau www.hk.viewsonic.com/support/ T= +853 700 303 Korean www.viewsonic.com ViewSonic VE910/VE910b T = Telephone Email F = FAX T= (800) 688 6688 service.us@viewsonic.com...
LCD display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the LCD display. • ViewSonic will not be liable for damage resulting from use of any ammonia or alcohol- based cleaners. ViewSonic VE910/VE910b...
ViewSonic warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components.
