One For All URC7115 Simple Setup Guide

BATTERIES INSTALLATION

KEY TABLE

MAGIC: Used to set up your remote

FAV: Favourite Channels

GUIDE: TV Guide, EPG

SMART: Access internet and Smart features of your TV

BACK: Back one step in the Menu of the current device

VOL: Volume Up, Down and Mute

HOME: Displays the Home Menu

LIST: Displays a list of recorded programmes

POWER: Power on/off

AV: Select the input on the current device

INFO: Displays info of current playback

EXIT: Exit from the Menu of the current device

MENU: Show the menu of the current device

PP: Previous Program, Last Channel

+/-: Channel Up and Down

NETTV: NETTV, Netflix

Red, Green, Yellow, Blue – Fastext/Quick access keys

PLAYBACK: Playback keys for the current device

HOW TO SET UP YOUR REMOTE

SIMPLESET

SimpleSet is a quick and easy way of setting up the remote to control the most popular brands of each device type with only a few key presses, typically in under a minute per device.

For each Device type, there is a list of the top brands, each with a number assigned to it, for example 6 for a Samsung TV. Locate your device and brand in the list that follows:

TV

0. Toshiba
1. Bush
2. Grundig
3. LG
4. Panasonic
5. Philips
6. Samsung
7. Sharp
8. Sony
9. TCL / Thomson

To set up your device

1. Turn on your device (not on standby) and point the OFA remote towards it.
2. Hold down MAGIC until the LED blinks twice.
3.
   Hold down the digit for your brand and device as listed above (e.g. 6 for Samsung TV).
4. The remote will send Power every 3 seconds until your device switches off.
5. As soon as your device switches off, release the digit.
6. The LED will blink twice and go out. The remote should now operate your device.

• If you find one or more keys do not work as you expect, start again at step 1 – the remote will start with the next code in the memory.

SET UP BY CODE

If your brand is not listed in section A, you can set up your device by trying codes individually. To do this:

1. Turn your device on (not on standby).
2.
   Locate the brand of your device in the code list. Codes are listed by Device Type.
3. Hold down MAGIC until the LED blinks twice.
4.
   Enter the first 4 digit code listed for your brand (e.g. 4542 for a Aiwa TV).
5. The LED will blink twice and go out.
6. Now aim the remote towards your device and press the POWER key.
7. If the device turns off, your remote is ready to use. If not, repeat steps 3-6 with the next code in the list.

• Some codes are quite similar. If you find that one or more keys do not operate as you expect, try again from step 3 with the next code in the list.

LEARNING

Your One For All remote control can learn any function from any other working remote control. This can be useful if you are missing one or more functions from your original remote control and would like to add them to the ONE FOR ALL.

You can also learn a complete device if you can't find a code.

To learn, firstly make sure you have all your original remote controls to hand, and that they have working batteries in. To learn functions, the original remote should be approximately 3cm from the OFA remote, pointing towards it as shown below:

1. Hold down MAGIC until the LED blinks twice.
2.
   Press 975 – the LED will blink twice.
3.
   Press and release the key you want to learn a function onto (for example the HOME key) – The red LED will blink continuously.
4.
   Press and release the key on the original remote.
5. The LED will blink twice to indicate the key has been learned correctly.
6. Repeat steps 3 and 4 for each key you want to learn – remember you can learn from multiple remotes, but only one function per key.
7. When you learned all the functions you require, press and hold the MAGIC key until the LED blinks twice and turns off.

HINTS

• If the LED shows one long blink at step 5, the function was not learned correctly, please try again from step 3.
• If you find one or more keys don't work properly after set up, you can re-enter the learning mode at any time by repeating the procedure from step 1.

TO DELETE A LEARNED FUNCTION, THE PROCEDURE IS:

1. Hold down MAGIC until the LED blinks twice.
2. Press 976 – the LED will blink twice
3. Press the key to delete twice – the LED will blink twice.

Repeat the above procedure for each key you want to delete.

THE NETTV FEATURE

The Evolve features a "NETTV" key for viewing digital TV, streamed over the internet. If your original remote control already had a key for this - for example many newer TVs have a Netflix key - then this key will perform exactly the same as the key on your original remote. However if you did not have a key like this, but still had the ability to watch a streaming service, you can use this key as a shortcut by programming a macro on it. Most AV devices which are connected to the internet, such as Smart TVs or streaming Set Top Boxes have one or more applications they can run to access TV viewing via the internet.

Examples of these would be Netflix, YouTube, Amazon Prime, BBC iPlayer or similar.

To program the macro, you first need to know the device you use to access the service, and then the sequence of keys you need to press to always bring up the service you prefer, For example, some Panasonic TVs will start Netflix by pressing the Apps key, then Menu Down Twice, and finally the OK key.

Once you have determined the sequence for your device, follow these steps:

1. Sit in front of your device with It switched on (not on standby)
2. Hold down the NETTV key until the LED blinks twice and stays lit
3. Now perform the sequence of keys exactly as would normally. The remote will operate your device and the macro is recorded in real time - so if it normally takes a few seconds for your device to react don't worry.
4. One you have finished the sequence - and the Streaming Service has started on your device - hold down the NETTV key until the LED blinks twice and goes out. The macro is now stored.

Tips

• Make sure the Evolve Is operating the device in question before programming
• If you find the Macro doesn't work as expected, you can just repeat the same sequence to reprogram
• When programming, wait for your device to respond first, the remote will remember the timing

PRODUCT DISPOSAL

This product bears the selective sorting symbol for waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19 / EU in order to be recycled or dismantled to minimize its impact on the environment.

User has the choice to give this product to a competent recycling organization or to the retailer when user buys a new electrical or electronic equipment.

BATTERY DISPOSAL

(EUROPEAN DIRECTIVE 2006/66/EC)

Please do not dispose your batteries with your normal household waste but inform yourself about the local separate collection for empty batteries to dispose them correctly. This will help preventing potential negative effects on the environment and/or human health.

WARRANTY

UNIVERSAL ELECTRONICS INC/ONE FOR ALL warrants to the original purchaser that this product will be free from defects in materials and workmanship under normal and correct use for a period of one (1) year from the date of original purchase. This product will be replaced free of charge if it has been proven to be defective within the one (1) year warranty period. This warranty does not cover cartons, carrying cases, batteries, broken or marred cabinets or any other item used in connection with the product.

www.oneforall.com

Universal Electronics BV
Europe & International
Colosseum 2, 7521 PT Enschede
The Netherlands

URC7115
711727
RDN-1010519
