D-50 Output Connector (PL2) Pin Assignments
The pin assignments are listed with the pin number of the D-50 connector and also the pin number
when a 50-way IDC ribbon cable is connected to the D-50. The pin assignments conform to the
Arcom Signal Conditioning System (SCS) and may be connected to an external Signal
Conditioning Board.
Ribbon Cable No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
10
D-50 Pin No.
Function
1
0V
34
0V
18
Group 0 - Bit 0
2
Group 0 - Bit 1
35
Group 0 - Bit 2
19
Group 0 - Bit 3
3
Group 0 - Bit 4
36
Group 0 - Bit 5
20
Group 0 - Bit 6
4
Group 0 - Bit 7
37
0V
21
Group 4 - Bit 0
5
Group 1 - Bit 0
38
Group 1 - Bit 1
22
Group 1 - Bit 2
6
Group 1 - Bit 3
39
Group 1 - Bit 4
23
Group 1 - Bit 5
7
Group 1 - Bit 6
40
Group 1 - Bit 7
24
0V
8
Group 4 - Bit 1
41
Group 2 - Bit 0
25
Group 2 - Bit 1
9
Group 2 - Bit 2
42
Group 2 - Bit 3
26
Group 2 - Bit 4
10
Group 2 - Bit 5
43
Group 2 - Bit 6
27
Group 2 - Bit 7
11
0V
44
Group 4 - Bit 2
28
Group 3 - Bit 0
12
Group 3 - Bit 1
45
Group 3 - Bit 2
29
Group 3 - Bit 3
13
Group 3 - Bit 4
46
Group 3 - Bit 5
30
Group 3 - Bit 6
14
Group 3 - Bit 7
47
0V
31
Group 4 - Bit 3
15
Group 4 - Bit 4
48
Group 4 - Bit 5
32
Group 4 - Bit 6
16
Group 4 - Bit 7
49
-12V
33
+12V
17
+5V
50
+5V
J206 PCIB40 Technical Manual
Alternative Function
Counter 1 Output (LK4)
Counter 2 Output (LK3)
Counter 1 Gate Input
Counter 1 Clock Input
Counter 2 Gate Input
Counter 2 Clock Input
