Peavey PZS 140 Specifications

S P E
PZS ª 140
Multi-Zone
Mixer/Amplifier

SPECIFICATIONS

FEATURES:
¥ Five input channels
¥ Four zones
¥ 35 watt output per zone
¥ Two XLR low-Z mic inputs (balanced)
¥ Detachable input connector for Low-Z
mic and High-Z line on each channel
¥ Signal LED indicator for each channel
¥ Channel level control
¥ Low and high active EQ each channel
¥ Four zone assignment switches each
channel
¥ Front panel adjustable threshold and
paging hold on channels 1 and 2
¥ Four master output level controls with
signal and clipping LED indicators
¥ Detachable preamp output/power amp
input connector for each zone
¥ Each zone output provides a 4-ohm
direct output and transformer isolated
8-ohm, 25- and 70-volt outputs
¥ Each zone has 600-ohm line level
balanced output
¥ 19" standard rack-mount package
¥ Three rack spaces
¥ Externally accessible main fuse
POWER OUTPUT:
35 W RMS per zone @ less than 1%
(60 Hz to 20 kHz with all four channels
operating)
C I F
OUTPUTS:
Speaker: 4 ½ (direct), 8 ½, 25 V and
70 V (isolated)
Line: 600 ½ balanced, 1V RMS
CHANNEL 1 and 2 INPUTS:
Mic: 2k ½, -54 dBu
(1.5 mV, balanced)
Line: >50k ½, -18 dBu
(100 mV, balanced)
XLR Mic: 2k ½, -54 dBu
(1.5 mV, balanced)
CHANNELS 3 - 5 INPUTS:
Mic: 2k ½, -54 dBu
(1.5 mV, unbalanced)
Line: >50k ½, -18 dBu
(100 mV, balanced)
RCA: >50k ½, -18 dBu
(100 mV, unbalanced)
INSERTS:
Send: 1k ½, 2.21 dBu
(1 volt, unbalanced)
Return: 10k ½, 2.21 dBu
(1 volt, unbalanced)
FREQUENCY RESPONSE:
50 Hz to 20 kHz, +0/-2 dB (transformer)
SIGNAL-TO-NOISE RATIO:
Residual: 90 dB below rated power
(channel down, master full up)
Line Inputs:
I C A
90 dB below rated
power (controls nominal,
2k ½ terminated)
T I O
Mic Inputs: 82 dB below rated
power (controls nominal,
150 ½ terminated)
TONE CONTROLS:
Low EQ: +10/-10 dB @ 100 Hz
High EQ: +10/-10 dB @ 10 kHz
CONTROLS:
Channels 1 and 2:
Level, low EQ, high EQ, four assign
switches, signal presence, LED muting
threshold and adjustable release time.
Channels 3 - 5:
Level, low EQ, high EQ, four assign
switches and signal presence LED
Masters 1 - 4:
Level, signal presence and clipping LEDs
POWER SUPPLY:
Internal, 120 V AC @ 60 Hz
375 watts all channel at full power
175 watts all channel at 1/8 power
Five-amp fuse
DIMENSIONS: (H x W x D)
5.25" x 19" x 15"
(13.3 cm x 48.3 cm x 38.1 cm)
WEIGHT:
(15.4 kg)
34 pounds
