- Page 1 INSTRUCTION MANUAL TRUE DAY/NIGHT VARI-FOCAL COLOR DOME CAMERA MODEL HDC211 Copyright © 2009 Clover Electronics U.S.A. All Rights Reserved.
-
Page 2: Installation
PRECAUTIONS • To avoid electrical shock, do not open the case of this product. • Do not stamp fingerprints on the lens. • Operate this product using only the recommended AC Power supply. • Do not overload electrical outlets or extension cords; this can result in fire or electric shock. - Page 3 4. If necessary, change the settings to get the best images depending on your application by using the buttons in the camera (refer to the instruction manual for OSD control). 5. Assemble the transparent dome③ by turning the locking ring② clockwise. The locking ring②...
- Page 5 HOW TO ADJUST ANGLE OF VIEW 1. Vari-focal lens① Easily changeable angle of view: 2.8 to 12mm 2. T↔W (Tele ↔ Wide)③ Turn this adjustment knob③ clockwise or counter-clockwise to set the focal length. 3. ∞↔N② Turn this adjustment knob② clockwise or counter-clockwise to set the focus. 4.
-
Page 6: Troubleshooting
Note: ▪ Apply DC12V 1 A regulated power supply (not included). ▪ To avoid fire or shock hazard, use a UL listed power supply. TROUBLE SHOOTING If the camera does not function properly, check the following points before contacting the service center. -
Page 7: Specifications
SPECIFICATIONS • Image sensor 1/3” SONY Super HAD CCD • Total pixels 811(H) x 508(V) • Effective Pixels 768(H) x 494(V) • Scanning system 2:1 Interlace • O.S.D Available • Backlight Off / HSBLC / BLC selectable • Resolution 550TV Lines(color),600TV Lines(B/W) •... -
Page 8: How To Obtain Factory Service
HOW TO OBTAIN FACTORY SERVICE 1. Original purchaser must fill out a warranty card and mail it to the factory with model number, serial number and the date of purchase. 2. We will repair or replace, and return to the owner the system under this limited warranty.
