LSI LASTEM SVSKA2001 User Manual

Data logger reprogramming kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Environmental monitoring solutions
SVSKA2001
Data logger reprogramming kit
User manual
LSI LASTEM SRL
Page 1 / 18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SVSKA2001 and is the answer not in the manual?

Questions and answers

Related Manuals for LSI LASTEM SVSKA2001

Summary of Contents for LSI LASTEM SVSKA2001

  • Page 1 Environmental monitoring solutions SVSKA2001 Data logger reprogramming kit User manual LSI LASTEM SRL Page 1 / 18...
  • Page 2 LSI LASTEM. LSI LASTEM reserves the right to carry out changes to this product without timely updating of this document. Copyright 2020-2022 LSI LASTEM. All rights reserved.

  • Page 3: Table Of Contents

    Connection to the data logger ......................... 12 Reprogramming data loggers ........................13 Firmware upload ..........................13 Programming bootloader ........................ 15 How to unlock LSI LASTEM data loggers in case of locking ..............17 SVSKA2001 programming kit disconnection ................... 18 LSI LASTEM SRL IST_03929...

  • Page 4: Introduction

    Data logger reprogramming kit – User manual 1 Introduction This manual explains how to install and use the SVSKA2001 kit for reprogramming the Alpha-Log and Pluvi- One data loggers. Before proceeding with the use of this kit, try the LSI.UpdateDeployer software (see IST_05055 manual).

  • Page 5: Preparing The Data Logger For The Connection

    2. Remove terminal 1÷13 and 30÷32 from the terminal board. Then on the right side of the terminal board, apply light pressure downwards and at the same time push towards the inside of the data logger until the electronic boards and the display come out completely. LSI LASTEM SRL IST_03929 Page 5 / 18...

  • Page 6: Installing The Programmer Software And Drivers On Pc

    3.1.2 Installing the STM32 Cube Programmer Follow these steps and the on-screen instructions to install the STM32 Cube Programmer (Stm32CubeProg): 1. Insert the LSI LASTEM pen drive on the PC. 2. Open the folder “STLINK-V2\en.stm32cubeprg-win64_v2-11-0”. 3. Double-click the executable SetupSTM32CubeProgrammer_win64.exe, to initiate the installation, and follow the on-screen prompts (from fig.
  • Page 7 6 - Click OK to confirm the directory fig. 5 - Click Next for the default directory fig. 7 - Click Next to continue fig. 8 – Wait the installation progress LSI LASTEM SRL IST_03929 Page 7 / 18...
  • Page 8 Data logger reprogramming kit – User manual fig. 9 - Click Next to continue fig. 10 - Click Finish fig. 12 - Click Next to continue fig. 11 - Click Next to continue fig. 13 - Click Done LSI LASTEM SRL IST_03929 Page 8 / 18...

  • Page 9: Installing St-Link, St-Link/V2, St-Link/V2-1 Usb Driver Signed For Windows7, Windows8, Windows10

    USB interfaces possibly provided by the ST-LINK: ST Debug, Virtual COM port and ST Bridge interfaces. Attention! The driver must be installed prior to connecting the device, to have a successful enumeration. Open the folder “STLINK-V2\Driver” of the LSI LASTEM pen drive and double-click the executable: • dpinst_x86.exe (for 32-bit operating system) •...

  • Page 10: Connection St-Link, St-Link/V2, St-Link/V2-1, St-Link/V3 To Usb Port

    1. Open and after few seconds will appear the main window 2. Proceed to upgrade the firmware as described from fig. 17 to fig. 20. The PC must be connected on internet. LSI LASTEM SRL IST_03929 Page 10 / 18...
  • Page 11 18 – Click Open update mode fig. 17 – Click Firmware Upgrade fig. 19 – Click Upgrade fig. 20 – Close the Window Continue with connecting the data logger to the programmer (§4). LSI LASTEM SRL IST_03929 Page 11 / 18...

  • Page 12: Connection To The Data Logger

    2. Set ST-LINK configuration parameters and do the connection as described from fig. 21 to fig. 22. fig. 21 – Click Connect fig. 22 – Wait the connection Now, you are able to reprogram the data logger (§5). LSI LASTEM SRL IST_03929 Page 12 / 18...

  • Page 13: Reprogramming Data Loggers

    2. Click on “Browse” and choose the <data logger-x.yy.zz>.bin file to upgrade the product (the first version of bin file is stored in FW\<data logger code> path of the LSI LASTEM pen drive; before pro- ceeding contact LSI LASTEM for the latest version).
  • Page 14 (as described in chapter §0), before repeating the firmware upload. ATTENTION! After loading the new firmware the data logger continue to show the previous firmware ver- sion. LSI LASTEM SRL IST_03929 Page 14 / 18...

  • Page 15: Programming Bootloader

    1. Click on of STM32 Cube Programmer. It will appear the Erasing & Programming option. 2. Click on “Browse” and choose the Bootloader.bin stored in the LSI LASTEM pen drive (path FW\<data logger code>). ATTENTION! It is important to set these parameters: ➢...
  • Page 16 Data logger reprogramming kit – User manual 3. Click Start programming and wait for the programming operation end. Now, continue with the firmware upload (see §5.1). LSI LASTEM SRL IST_03929 Page 16 / 18...

  • Page 17: How To Unlock Lsi Lastem Data Loggers In Case Of Locking

    6 How to unlock LSI LASTEM data loggers in case of locking The SVSKA2001 programming kit can be used to unlock Pluvi-One or Alpha-Log data logger. It could hap- pen, during its operation, that the data logger locks. In this situation the display is off and the Tx/Rx green LED is on.

  • Page 18: Svska2001 Programming Kit Disconnection

    Then, proceed with the programming of the bootloader (§5.2) and the firmware (§5.1). 7 SVSKA2001 programming kit disconnection Once the reprogramming procedures have been completed, disconnect the SVSKA2001 programming kit and close the data logger as described in chapter §0, proceeding backwards.
