OPOP spol. s r.o. Zašovská 750, 757 01 Valašské Meziříčí Tel.: 571 675 589, Fax: 571 611 225 CENTRAL HEATING BOILER H 412,H 418, H 424, H 430 Content 1. Introduction 2 . Boiler Properties 3. Technical Description 4. Main Dimensions 5. -
Page 2: Introduction
May our products bring you heat and comfort OPOP s.r.o. 2. BOILER PROPERTIES Courtesy of their design and surface treatment, the H4 series hot water steel boilers are intended for level and central heating of detached houses with the maximum hydrostatic height of 20 m. -
Page 3: Technical Description
Heat and Comfort Obr. – spalování uhlí – coal combustion; spalování dřeva – wood combustion 3. Technical Description The upper part of the boiler consists of a stoking door fitted on hinges and a cleaning door attached to the weldment by means of fly nuts. The door is sealed tightly to the boiler body by a heat insulation rope. - Page 4 Heat and Comfort upper part of the space, there is a movable heating flap, which allows direct flue gas removal from above to the bell. The boiler fireplace is fitted with a movable cascade grate controlled by a lever on the side of the boiler.
-
Page 5: Main Dimensions
Heat and Comfort able relating to Fig. 2 4. Main Dimensions H 412 H 418 H 424 H 430 A – Total Boiler Height 1005 B – Total Boiler Depth C – Boiler Width D – Location of the Gas Flue E –... - Page 6 Heat and Comfort Fig. 1 - H412 Boilers...
- Page 7 Heat and Comfort Fig. 2: H418 Boilers...
- Page 8 Heat and Comfort Explanatory Notes: 1 – H418 Boiler Body 2 – Grating Mechanism 4 – Heat-up Flap 5 – Cleaning Stopper 9 – Grating Mechanism Lever 10 – Ash Pan Drawer 15 – Stoking Door 16 – Cleaning Door 17 –...
- Page 9 Heat and Comfort Fig. 3: H424 Boilers...
-
Page 10: Technical Parameters
Heat and Comfort 5. Technical parameters for Coal table 2 H 412 H 418 H 424 H 430 Operating Flue (mbar) 0.18 0.18 0.22 0.27 Water Volume ( l ) 22.7 Bell Diameter (mm) (mbar) 0,1/0,37 0,19/0,7 0,28/1,1 0,38/1,4 Boiler Hydraulic Loss at ∆T 20°/10°... -
Page 11: List Of Replaceable Spare Parts
Heat and Comfort Type of Fuel and Fuel Water Content Fuel Wood, H O max. 20% Fuel Size 25 cm 25 cm 30 cm 30 cm Note Fuel consumption directly depends on the quality and type of fuel used as well on the operator’s keeping the internal heat exchange boiler surfaces clean. - Page 12 Heat and Comfort Obr. Vybrané náhradní díly Název dílu Číslo ND Pro kotel Šikmý rošt H418030 H412V, H418V Šikmý rošt H424030 H424V, H430V Posuvný rošt H418031 H412V, H418V Posuvný rošt H424031 H424V, H430V Čistící klapka H412001 H412V Čistící klapka H418001 H418V Čistící...
- Page 13 Heat and Comfort Obr. Vybrané náhradní díly Název dílu Číslo ND Pro kotel Zatápěcí klapka H418002 H418V H424002 H424V, H430V Roštovací H418023 H412V, H418V mechanismus Roštovací H424030 H424V, H430V mechanismus Podpěra roštu H424022 H424V, H430V Šamotová deska H418040 H412V, H418V Šamotová...
-
Page 14: List Of Accessories Supplied
Heat and Comfort Part Name Spare Part No. Boiler No. Inclining Grate H418022 H412,H418 Movable Grate H418021 H412, H418 Movable Grate H424026 H424, H430 Cleaning Flap H412001 H412 Cleaning Flap H418001 H418 Cleaning Flap H424001 H424, H430 Heat-up Flap H412002 H412 Heat-up Flap H418002... -
Page 15: Servicing The Boiler
Heat and Comfort Flange (2 items) Fibrous sealing (2 items) 10) M10 Screw (8 items) 11) M10 Nut (8 items) 10.5 Washer (8 items) Operating Manual plus warranty sheet Cleaning flap 8. Operating the Boiler Prior to initial heat-up: Check whether the boiler or the entire heating system is filled with water or other heat bearing medium and duly de-aired. - Page 16 Heat and Comfort In order to prevent any smoke leakage when opening the stoking door and stoking fuel, take the following procedure: - prior to stoking, close the air supply using the choker in the ash pan door and slightly open the stoking door by roughly 1 to 1.5 cm in the frontal part of the stoking door Wait for about 10 seconds until the smoke gases are sucked away and then open the stoking door fully.
-
Page 17: Boiler And Heating Equipment Maintenance
Heat and Comfort Follow the below cleaning procedure: Slip the ash pan drawer to the ash pan compartment; Remove the cleaning door (16) and the heating flap (4). Use the hook provided to remove the cleaning flap (5) located in the rear boiler part on the bottom of the rear venting hole. -
Page 18: Safety Instructions For Boiler Assembly And Servicing
Heat and Comfort replenished with water. If needed, the water system may be filled with non-freezing liquid, Friterm (www.velvana.cz), or a non-corroding product, Inhikor II. The user shall trust the commissioning, regular servicing and removal of any defects to a specialised service only. - Page 19 Heat and Comfort Chimney Diameter in mm Boiler Capacity Chimney Height 8m Chimney Height 12m Chimney Height 15m 15 x 15 15 x 20 Ø 180 mm Ø 180 mm Ø 200 mm Ø 200 mm 49,5 The boiler may only be installed to the chimney to ČSN 73 4201:1989 (Design of Chimneys and Smoke Flues).
- Page 20 Heat and Comfort non-flammable hardly flammable flammable with difficulty medium flammable easily flammable stone, granite, sand stone, concrete mixes, porous A) non-flammable: concrete, foam concrete, bricks, fireclay, mortars, plastering, metals, glass and other mineral melts, asbestos- cement plates B) hardly flammable: Acumine, Izomine, plasterboard plates, Heraclites, Lignos, Rayolite, Velox, novodur, Durufol B, Duroplast...
- Page 21 Heat and Comfort expansion vessel must be positioned in such a way as to prevent it from getting heated up due to exposure to radiant heat. 2) Each heating system must be executed to ČSN 06 0830 (Safety Equipment for Central Heating and Heating of Utility Water), fitted with at least a single reliable safety valve located on the outgoing line or on the boiler and a manometer (pressure gauge).
- Page 22 Heat and Comfort C. The pressure differential may be tested during a heating test where the water in the system is heated up from cold state. If the resultant pressure differential exceeds 60 kPa, the pressure expansion vessel is inappropriate and a risk of pressure body damage is imminent.
- Page 23 Heat and Comfort The connection chart for the two valves is identical. Operating Principle: a sensor in the ½” catchment located in the upper part of the boiler takes boiler water temperature measurements; whenever the water temperature in the boiler grows to 95°C (TS 130) or 97°C (STS 20), the fixture starts to automatically open and supply water into the in-built safety exchanger in order to remove the heat and prevent the boiler from overheating.
- Page 24 Heat and Comfort 10.7 BOILER OPERATION SAFETY INSTRUCTIONS From the viewpoint of safety and economy, the appliance may only be serviced to instructions given in the present manual. The boiler may only be left unsupervised if the performance is adjusted in such a way that the system cannot get overheated (subdued operation), or if it is fitted with an appropriately adjusted and functioning capacity controller, yet even under such conditions, it must be checked by the operator from time to time.
-
Page 25: Waste Disposal
Heat and Comfort Clean boiler (drafts and venting holes) • • Tight boiler – duly fitted and sealed cleaning, stoking and ash pan door Appropriately chosen boiler capacity with regard to the given heated site • Note: The manufacturer recommends including an appropriate mixing facility in the heating circuit, primarily when using a circulation pump, in order to prevent the supply temperature of the heated water in the boiler from dropping below 65 o C. -
Page 26: Determination Of Storage Tank Size
300l. WARRANTY SHEET For the following hot water boilers: H412, H418, H424, H430 Fabrication No. Manufacturer: OPOP spol. s r.o., Valašské Meziříčí Tel.: 571 675 589, Fax.: 571 611 225 Shipped from Plant: ___________________________________________________ Warranty Conditions: The present Warranty Sheet contains a certificate of quality and completeness. - Page 27 Heat and Comfort • has not been mechanically damaged trough the use of force (no unauthorised intervention has been performed save for those permitted by the operating manual) • chimney draft to ČSN must correspond to the value given in Table 2 depending on the boiler type •...
- Page 28 10% off the price of spare parts. In order to be able to make use of the above discount, you need to fill in the registration card and send it to our address: OPOP spol s r.o. Obchodní oddělení Zašovská 750 757 01 Valašské...
-
Page 29: Registration Card
Heat and Comfort manufacturer. When ordering spare parts, you need to present the Customer Card No. indicated therein. Thank you for your trust. Cut here and send to our address .......................... 14. REGISTRAČNÍ KARTA Jméno………………………….. výrobní číslo výrobku……………………. Příjmení………………………… prodejce………………………………….. Ulice a č.p.
