- Page 1 Battery charger User manual Model Part No. 1264543 Tennant Company 10400 Clean Street, Eden Prairie, MN 55344-2650 Telephone: (800) 553-8033 www.tennantco.com Internet: To view, print, download the parts manual visit: www.tennantco.com/manuals Revision: 00 (10/2022)
- Page 2 Original user manual, written in the English Language Tennant Company 10400 Clean Street, Eden Prairie, MN 55344-2650 Telephone: (800)553-8033 Internet: www.tennantco.com Model: i-charge 2 Date:26/10/2022 Product code: 1264543 Version: v.1.0...
-
Page 3: Preface
Become familiar with the correct operation and maintenance procedures. Store the manual in a safe place. The manual is an essential part of the i-charge 2 and must be handed over to the new owner upon resale or exchange. Each i-charge 2 has a unique identification number that can be found on the bottom. -
Page 4: Reading Guide
Reading guide The following symbols and terms are used throughout this manual to alert the reader to safety issues and important information: Symbol Term Explanation WARNING Indicates a hazardous situation which, if the safety instructions are not followed, can lead to injuries of the operator or bystanders, light and/or moderate damage to the product or the environment. -
Page 5: Table Of Contents
Content Preface ......................................3 Purpose of the user manual ..............................3 Target audience ..................................... 3 Operators of the i-charge 2 ..............................3 Reading guide ....................................4 Introduction ................................... 7 Intended use of the product ..........................7 Non-intended use of the product ........................7 Modifications ................................ - Page 6 Decommissioning and disposal ..........................21...
-
Page 7: Introduction
Non-intended use can have consequences for the safety of operators and bystanders and will void the warranty on the product. The i-charge 2 is not intended for use outdoors or in a wet or closed environment. Do not charge non original batteries or non-rechargeable batteries with the i-charge 2. -
Page 8: Specifications
1.4 Specifications Figure 1 Product size: 265 x 214 x 110 mm | 10.4”x 8.4 “x 4.3” Weight: 1.2 kg | 2.6 lbs Battery capacity: 2 batteries/63 Hz Power supply: 100-240 V, 50/60 Hz per side Fuse 6.3 A / 300ms Charge current: 2.5 A per side Standby power:... -
Page 9: Warranty
2 and may cause a risk to the operator. The use of alternative supplies voids manufacturer's warranty. 1.6 Identification Each i-charge 2 has a unique serial number that can be found on the bottom of the body. Your i-team partner needs this number when you order parts. Explanation type plate:... -
Page 10: Description
2 Description The compact i-charge® 2 is designed to charge 2 batteries in parallel. The i-charge 2 consists of: Figure 3 Legend The battery charge displays. The power cable. The main body. The ON/OFF switch. -
Page 11: Battery Charge Displays
2.1 Battery charge displays 1. Battery charge displays. When the batteries are charged, the amount of colored bars will go up from one bar that blinks, which indicates that the batteries are almost empty. To three bars that burn continuously, which indicates that the batteries are full and ready to use. -
Page 12: Safety
3 Safety Safety comes first, therefore please take time to read and understand these safety instructions. Improper use can cause harm or void the manufacturer’s warranty. 3.1 General Safety Instructions WARNING DO NOT operate the i-charge® 2 with wet or moist hands. 3.1.1 Batteries CAUTION During normal operation the 24 V batteries cause no safety hazard on their own. -
Page 13: Risks During Operation
2 during usage; • ensure that the main voltage is identical to that mentioned on the identification plate on the i-charge 2; • only use the i-charge 2 in an environment that is well ventilated and has a good heat dissipation. -
Page 14: Transport And Storage
4 Transport and storage CAUTION The storage environment should not contain corrosive gasses. There should be no magnetic fields. Vibrations should be avoided. -
Page 15: Assembly And Installation
5 Assembly and installation 5.1 Unboxing The i-charge® 2 is packed in 1 box. Figure 5 Legend 1x power cable 1x i-charge 2 battery charger 1x this user manual... -
Page 16: Assembly
5.2 Assembly Connect the power cable (Figure 6, pos 1) to the connector at the back side of the i- charge 9. Figure 6... -
Page 17: Operation
6 Operation 6.1 Before you start • check the i-charge® 2 for damage; • check the power cable for damage, pull it through a fiber cloth; • check the battery for damage. 6.2 Operation 1. Put the main power cable into the wall socket (Figure 7, pos 1). -
Page 18: After Operation
2 to reset. 6.3 Cleaning and storage 6.3.1 Cleaning It is recommended to clean the i-charge 2 with a damp cloth every once in a while. 6.3.2 Storage • store the i-charge 2 in a dry environment;... -
Page 19: Maintenance
7 Maintenance Maintenance and repairs should only been done by authorized personnel. -
Page 20: Trouble Shooting
8 Trouble shooting Problem Cause Solution No power Power cable not correctly inserted Check if power cable is inserted correctly. ON/OFF switch off Turn on ON/OFF switch. - Page 21 It is the responsibility of the i-charge® 2 owner to dispose of the product. At the end-of-life the i-charge 2 still contains valuable resources and needs to be disposed of according to your local laws and regulations regarding recycling of electrical equipment.
