molex 1808282000 Installation Instructions Manual

Coresync multigate, 90w

Advertisement

CoreSync Multigate, 90W
RJ45 Connector for PoE input
over CAT5e / CAT6/CAT6A
Link Speed Indication – Active When
operating Speed is 100Mbps
Link Activity Indicator – Blinks when
detects an activity on the network
Power Indicator LED
Order No.
1808282000
