PARTS LIST
Panel with Integrated Cable Manager
Hardware Kit
Rear Housing Assembly
Stuffer Caps
Labels
Instruction Sheet
GENERAL REQUIREMENTS
The following tools are required for installation of
the panel:
110 termination tool set on low impact
Flush cut pliers
Cable stripping tool
Phillips screwdriver
ASSEMBLY INSTRUCTIONS
1. Panel Preparation
1a. Remove cable management tray from panel.
1b. For each cable, slide rear housing on cable
in the proper direction.
REVISION:
ECR/ECN INFORMATION:
MTS2012-0032
EC No:
A
2013 / 01 / 21
DATE:
DOCUMENT NUMBER:
AS-18700-059
APPLICATION SPECIFICATION
INSTALLATION INSTRUCTIONS: PID-00231 PANEL
TITLE:
Installation Instructions PID-00231
CREATED / REVISED BY:
BJ Mahendra
MIIM Category 6A Patch Panel
CHECKED BY:
CG Raghavan
TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC
MPN NO.
SAP NO.
215-390
187000372
APPROVED BY:
Samuel Huber
SHEET No.
1
4
of
