Fimco HIGH-FLO HFP-12060-111 Owner's Manual

12 Volt, 1.2 GPM, 60 PSI
Diaphragm Pump
Model: HFP-12060-111
(5281370/5151086)
Installation and Service
Information
Fimco High-Flo High Performance pumps are designed to pump water and aqueous solutions of common pesticides. They are not
designed to pump petroleum products or other flammable materials. They are not designed to pump bleach solutions. Use of this
pump for petroleum products or bleach solutions will void the warranty. When pumping liquids other than water, the pump
should be flushed out with a cleaning solution, such as Fimco Tank Neutralizer & Cleaner, or clean water mixed with a good grade
dish soap after each use to prolong pump life.
This High-Flo High Performance pump is equipped with a demand switch that reacts to outlet pressure and shuts the pump motor
off at a factory set pressure limit of 60 PSI. When the pressure drops below this preset limit the switch allows the pump motor to
start again.
High-Flo High Performance pumps are self-priming. Vertical prime will depend on the viscosity of the liquid and suction line size.
Minimum recommended suction line size is 3/8 inch. Make sure all hose clamps are tight before testing or spraying for the first
time. The installation of a 50 mesh strainer is recommended to prevent debris or other foreign material from entering the pump
and causing pump failure. The pump should be mounted in a dry and adequately ventilated area. The pump can be mounted
horizontally or vertically. If mounted vertically, the pump head should be down and the motor should be up. Your pump has two
male 3/8" hose barb fittings molded into the pump head. Use flexible hose or tubing to connect to the inlet and outlet ports on the
pump. This minimizes stress on the pump head. Never use rigid pipe connections. Do not compress the feet. Overtightening will
reduce the ability to isolate vibration & noise.
Your pump is rated at 1.2 GPM @ open flow. If the discharge plumbing is very restrictive or nozzle tips are undersized, the back
pressure will cause the pump to cycle rapidly. This rapid cycling will increase the operating temperature of the motor and the
amperage draw on the power supply. Extended use with this cycling will cause premature failure of the pump.
Your pump is designed to run off of the battery of your ATV, lawn tractor, or other vehicle with a 12V system. If using a stand alone
battery, use a deep cycle RV or marine battery.
The pump should be winterized before storage, by pumping a solution of RV antifreeze through it, and the entire plumbing system.
High-Flo High Performance Pumps are warranted against manufacturer or workmanship defects for Two (2) years from date of
purchase for home owner usage and 90 days for commercial usage.
WARNING:
To reduce the risk of injury, the
user must read and understand the operator's
manual before using this product.
WARNING:
Cancer and Reproductive Harm.
www.P65Warnings.ca.gov
OWNER'S MANUAL
Retain a copy of receipt for your pump.
As it will be required to validate any warranty service.
See Page 6 for Warranty Information
www.fimcoindustries.com
1000 FIMCO Lane, P.O. Box 1700, North Sioux City, SD 57049
Toll Free Phone: 800-831-0027 : Toll Free Fax: 800-494-0440
[5194678 (01/22)]
Page 1
