Capcom CPS2 Programming Manual page 2

○ http://www.ebay.com/itm/Monoprice­8­4pin­MOLEX­Male­to­Two­15pin­SATA­II­
Female­90­degree­Power­Cable­/231406723440?hash=item35e0ea6170:g:t7gA
AOSwgQ9Vyogf
● Soldering iron and solder
CPS2 motherboard tools and supplies
● Torx security screwdriver set including at least size T20
○ http://www.ebay.com/itm/Security­Tamper­Proof­Bit­Set­33pc­Torq­Torx­Hex­Sta
r­Spanner­Tri­Wing­Screwdriv­/191348606804?hash=item2c8d440754:g:944AA
OSwrklU7yJV
● 3.6v batteries ½ AA type
○ http://www.ebay.es/sch/sis.html?_nkw=5%20Stuck%20Lithium%20Batterie%201
%202%20AA%203%206V%20Volt%20Saft%20LS14250%201200mAh&_itemId=
201036522792
● Battery case axial
○ http://www.ebay.com/itm/5x­1­2­AA­1­2AA­14250­Battery­Storage­Box­Case­Hol
der­3­6V­PCB­Pin­Solder­Lead­/291105178166?ssPageName=ADME:L:OC:ES:
3160
Software
● Computer with Arduino Software
○ https://www.arduino.cc/en/Main/Software
● ArcadeHacker_CPS2.ino Arduino program file
○ https://drive.google.com/file/d/0B6ZdYotJmj6qdjlNemFYRXJNM00/view
Assembling and preparing your Arduino programmer
1. Solder the 7 pin strip to the top right most socket of the LCD Keypad Shield
