Summary of Contents for Heliospectra MITRA X
- Page 1 MITRA User Manual Heliospectra Horticulture Fixtures...
- Page 2 Heliospectra AB shall have no liability for any error or damage resulting from the use of this document. At Heliospectra AB we aim to continuously improve our product documentation. If you have comments or ideas regarding this document, please contact us at support@heliospectra.com...
- Page 3 Si vous avez un doute sur le bon fonctionnement de person. celui-ci, contactez votre distributeur ou Heliospectra directement. The luminaire should be positioned so that prolonged staring La source de lumière contenue dans ce luminaire ne doit-être into the luminaire at a distance closer than 1 meter/ 40 inches is remplacée que par le fabricant, ses agents de services ou une...
-
Page 4: Table Of Contents
Table of Contents PRODUCT OVERVIEW ....................MITRA X (MI65XR40, MI65XR40F, MI65XR60, MI65XR60F, MI65XR80) ....Physical Overview .................... 2.2 Technical Specifications ..................Output and Spectrum ..................PSU FLEX (MIPSU05, MIPSU06, MIPSU07, MIPSU08)........... Physical Overview ....................3.2 Technical Specifications .................. MOUNTING KITS ....................... MITRA X Chain-Bracket Kit (MIKIT01) ............... - Page 5 MITRA X User Manual V.1.0...
-
Page 6: Product Overview
1. Product Overview MITRA X fixtures consists of a lamp, a power supply unit and a mounting kit. Mounting Kit Power Supply Unit Lamp MITRA X - COMPLETE FIXTURES PRODUCT CODE LAMP POWER SUPPLY UNIT MI65XR40-05 MITRA X - MI65XR40... -
Page 7: Mitra X (Mi65Xr40, Mi65Xr40F, Mi65Xr60, Mi65Xr60F, Mi65Xr80)
Maximum distance between Lamp Modules: 3.4m (11.2 ft). Front View NOTE! When unpacking and installing your MITRA X make sure to have a sturdy surface to work on. The fixture may get damaged if dropped. MITRA X User Manual V.1.0... -
Page 8: Technical Specifications
0-10VDC, 10V PWM signal 0-10VDC, 10V PWM signal 0-10VDC, 10V PWM signal 0-10VDC, 10V PWM signal Dimming or WiFi* or WiFi* or WiFi* or WiFi* * Requires the Adelphi wireless connector Data points are subject to change without notice. Tolerance +/- 10% www.heliospectra.com... -
Page 9: Output And Spectrum
Green Green Far red Far red CCT (K) 3981 65,3 CCT (K) 3736 62,5 helioSPEC R80 Blue Green Far red CCT (K) 1289 28,1 Data points are subject to change without notice. Tolerance +/- 10% MITRA X User Manual V.1.0... -
Page 10: Psu Flex (Mipsu05, Mipsu06, Mipsu07, Mipsu08)
13.0 mm / 0.51 in 380 mm / 15 in 8.5 mm / 0.33 in Chain Slot Side View Dimming Cable 210 mm / 8.3 in Power Cable 2000 mm / 78.7 in Protective Front View Lamp Cable 130 mm / 5.1 in www.heliospectra.com... -
Page 11: Technical Specifications
1.55 A²s at 220Vac input, 25°C 2.1 A²s at 220Vac input, 25°C 1.55 A²s at 220Vac input, 25°C Inrush Current cold start, duration=14.2 ms, cold start, duration=14.2 ms, cold start, duration=14.2 ms, cold start, duration=14.2 ms, 10%Ipk-10%Ipk. 10%Ipk-10%Ipk. 10%Ipk-10%Ipk. 10%Ipk-10%Ipk. MITRA X User Manual V.1.0... - Page 12 2.36 A | 647.5 W | 0.99 347 VAC 1.87 A | 644.2 W | 0.99 400 VAC 1.71 A | 643.4 W | 0.99 480 VAC 1.39 A | 642.9 W | 0.97 Data points are subject to change without notice. Tolerance +/- 10% www.heliospectra.com...
-
Page 13: Mounting Kits
Weight (1 pcs) 170 g (6 oz) Chain Slot 4.2 MITRA X C-Bracket Kit (MIKIT02) Product Code MIKIT02 4 pcs MITRA X C-bracket for mounting a Component A 4 pcs MITRA X MITRA X fixture. C-bracket The inner width of the C-bracket is 42 mm... -
Page 14: Mounting Instructions
5. Mounting Instructions The support structure needs to be sturdy enough to support the weight of the MITRA X lamp, the power supply unit and any additional equipment. None of the power cables can be used to support the weight of the fixture. -
Page 15: Mitra X
5.1 MITRA X MITRA X fixtures are compatible with the MITRA X Chain-Bracket Kit (MIKIT01) and the MITRA X C-Bracket Kit (MIKIT02). MITRA X lamps can be mounted with the C-brackets from MITRA X C-Bracket kit (MIKIT02). Use two C-brackets per lamp module to mount the fixture from Unistrut profiles or similar. -
Page 16: Psu Flex
One-point chain mounting. Two-point chain mounting. PSU Flex can be mounted with the C-hooks from MITRA X C-Bracket kit (MIKIT02). Use two C-hooks per PSU to mount the unit from Unistrut profiles or similar. The inner width of the C-hook is 42 mm (1.65 in). -
Page 17: Electrical Installation
Green/Yellow: Protective earth / ground MIPSU06, MIPSU08: • Brown: Phase 1 / L1 • Blue: Phase 2 / L2 • Green/Yellow: Protective earth / ground NOTE! All electrical installation should be done by a qualified electrician. MITRA X User Manual V.1.0... -
Page 18: Surge Protection
6.2.1 Surge Protection Heliospectra AB requires that the fixtures are installed with adequate surge protection according to the local recommended practice. In North America IEEE 1100-2005 contains the recommended practice for powering and grounding electronic equipment. In Europe the applicable standard is IEC 62305 –... -
Page 19: Dimming Connection
The power supply unit supports 0-10VDC dimming or 10V PWM signal (200-2000 Hz) dimming. The AUX supplies 12VDC, max 200 mA. The power supply is compatable with the Adelphi Wireless Connector. DIM+ DIM- AUX+ AUX- MITRA X User Manual V.1.0... -
Page 20: Dimming Using 0-10Vdc Signal
2. The dimmar can also be replaced by an active 0-10V voltage source signal or passive com- ponents like zener. 5.3.2 Dimming Using 10V PWM Signal The recommended implementation of the 10V PWM signal dimming control is provided below. NOTE! Do NOT connect DIM- to V+ or V-, or the driver will not work properly. www.heliospectra.com... -
Page 21: Maintenance
Power Supply Unit: Apply a light soap and water mix using a hand sprayer. Wipe with a clean cotton cloth or gently hose with low pressure water. NOTE! Do NOT dissamble the MITRA X fixture in order to clean it. It is not necessary and it will invali- date your warranty. MITRA X User Manual... -
Page 22: Disposal
Please contact your local authority for further details of your nearest designated collection point. Penalties may be applicable for incorrect disposal of this waste, in accordance with your national legislation. www.heliospectra.com... -
Page 23: General Warranty Terms And Conditions
Heliospectra Return Material Authorization (RMA) pro- cess. If Heliospectra chooses to replace the Product and is not able to do so because it has been discontinued or is not available, Heliospectra may refund the Buyer or replace the Product with a comparable Product. -
Page 24: Terms And Conditions
Heliospectra. In no event does Heliospectra warrant that the software is error free or that the Buyer will be able to operate the software without problems or interruptions. Heliospectra does not give any... -
Page 25: Warranty Limitations
8.2.3 Warranty Limitations This warranty does not apply under any of the following circumstances: a. The Product has been opened or altered by anyone other than Heliospectra or an authorized representative. b. The Product has not been installed (including proper electrical and WiFi equipment and installation), operated or maintained in accordance with instructions supplied by Heliospectra. -
Page 26: Warranty Claim Process
For MITRA LED components: 85% or more of the light emitting diodes illuminate. Heliospectra reserves the right to make the final decision on the validity of any warranty claim. 8.2.4 Warranty Claim Process Before returning any Product, a Return Material Authorization (“RMA”) reference number must be obtained from Heliospectra. - Page 27 Description of defect and occurrence. Adequate records of operating history, maintenance, and/or testing to substantiate that the Product has failed to comply with its intended performance. Original or equivalent packaging to ship the unit(s) to the Heliospectra Repair Center. MITRA X User Manual V.1.0...
-
Page 28: Implied Or Other Warranties
8.4 Disclaimers To the full extent permitted by law, Heliospectra will not be liable to the Buyer for any loss or damage arising from the use of the Product, or any defect in the Product, however it may arise. - Page 29 Visit our Support Portal for product information, articels and videos at https://support.heliospectra.com/knowledge Or sent our dedicated support team an email at support@heliospectra.com OUR OFFICES Sweden United States Heliospectra AB. Heliospectra Inc. Fiskhamnsgatan 2, 1658 N. Milwaukee Avenue 414 58, Gothenburg Suite #100-6558 +46 31 40 67 10...
