- Page 1 Setup Manual Heliospectra Horticulture Fixtures...
-
Page 2: Table Of Contents
Heliospectra AB shall have no liability for any error or damage of any kind resulting from the use of this document. At Heliospectra AB we aim to continuously improve our product documentation. If you have comments or ideas regarding this document, please contact us at support@heliospectra.com. -
Page 3: Product Overview
1. Product Overview sensorHUB is enabling the possiblity for the helioCORE system to be able to collect real world data. The data could then for example be used for controlling how much added light need for suppling the plants with the correct amount of light. -
Page 4: Box Installation
Place the box in such way, so it is available for service and maintenance. When mount- ing the cabinet, please use galvanized or stainless M6-M8 screw that withstand humid environments over time. 300mm 260mm The box has prefabricated mounting holes designed for M6 screw installation. Note the dimensions in the figure above. www.heliospectra.com... -
Page 5: Network Installation
2.2 Network Installation sensorHUB is supplied with power through the ethernet cable, also named POE or Power Over Ethernet. This means that no power cable has to be connected, but instead the other end of ethernet cable must be connected to a switch that supports POE+. The power consumption for the sensorHUB is a maximum of 21.5W, depending on how many sensors that is connected. -
Page 6: Sensor Installation
The sensorHUB has eight inputs for sensors, the input module expects a 4-20mA sensor sig- nal. Any sensor with this sensor signal could be connected to the system, as long as the sensor could be supplied with the 24 volts that the sensorHub supplies and that the helioCORE system has support for it. -
Page 7: Sensor Connection
3.2 Sensor Connection In the picture to the right, the customer connection terminal is showed. There is eight terminal blocks with FOR INTERNAL USE three corresponding push-in con- nectors. The row at the top is the 24 volt supply line, the row at the bottom is the ground and the row in the middle is the signal input. - Page 8 The sensor location refers to the physical placement of the sensor. Example: “Greenhouse A Bay 1” The sensor calibration factor is found in the Certificate of calibration for LI-COR sensors as the ‘Multiplier’-value under the caption “If this is an LI-190R-BL”. www.heliospectra.com...
-
Page 9: Maintenance
5. Maintenance No specific maintence would be needed for the sensorHUB, but it is important that the sen- sorHUB is handled with care, that the lid is closed at all times and that all cable glands are tigtly sealed around the cables. - Page 10 OUR OFFICES Sweden Canada United States Japan Heliospectra AB. Heliospectra Canada Inc. Heliospectra Inc. Heliospectra Japan Co., Ltd. Fiskhamnsgatan 2, 2 Bloor Street West 1658 N. Milwaukee Avenue 2-10-3 Terada Kojimachi Build. 414 58, Gothenburg Suite 2120 Suite #100-6558 Chiyoda-ku, 102-0083, Tokyo...
