- Page 1 MITRA User Manual Heliospectra Horticulture Fixtures...
- Page 2 Heliospectra AB shall have no liability for any error or damage resulting from the use of this document. At Heliospectra AB we aim to continuously improve our product documentation. If you have comments or ideas regarding this document, please contact us at support@heliospectra.com.
- Page 3 Cet appareil ne peut être entretenu que par un technicien In the case of a suspected malfunction contact your expérimenté. Si vous avez un soupçon sur le mauvais distributor or Heliospectra directly. fonctionnement de celui-ci, contactez votre distributeur ou Heliospectra directement.
-
Page 4: Table Of Contents
Table of Contents PRODUCT OVERVIEW ....................MITRA SQUARE (MI65SF, MI65SV, MI65SB) ............MITRA LINEAR (MI65LF, MI65LV, MI65LB) ............MITRA SPLIT (MI65LFS, MI65LVS, MI65LBS) ........... 1.4 Technical Specifications .................. PSU OVERVIEW ......................PSU 0-10V Dimming (MIPSU01) ................ PSU Flex (MIPSU03) .................... PSU 0-10V Dimming B (MIPSU04) .............. -
Page 5: Product Overview
Top view Square configuration Square MITRA NOTE! Side mount Cable T-connector When unpacking and installing your MITRA make sure to have a sturdy surface to work on. PSU connector 0.5m 0.5m 0.5m Damage can occur to the light bar if dropped. -
Page 6: Mitra Linear (Mi65Lf, Mi65Lv, Mi65Lb)
Cable T-connector Front view 0.5m 0.5m 1.5m NOTE! When unpacking and installing your MITRA make sure to have a sturdy surface to work on. PSU connector Damage can occur to the light bar if dropped. 0.5m 0.5m LED Light Module www.heliospectra.com... -
Page 7: Mitra Split (Mi65Lfs, Mi65Lvs, Mi65Lbs)
*the width is given for one of the two lamp modules PSU connector NOTE! 1.8m LED Light Module When unpacking and installing your MITRA make sure to have a sturdy surface to work on. 0.1m Damage can occur to the light bar if dropped. MITRA User Manual V. 2.2... -
Page 8: Technical Specifications
1.4 Technical Specifications MITRA SQUARE MITRA LINEAR (MI65SF, MI65SV, MI65SB) (MI65LF, MI65LV, MI65LB) Physical 580 x 630 x 88 mm 1100 x 340 x 88 mm Size (LxWxH) (22.8 x 24.8 x 3.5 in) (43.3 x 13.4 x 3.5 in) 12 kg (26.5 lbs) - Page 9 ABS plastic and Anodized Housing Aluminum Material Diffuser : Highly transmissive acrylic glass Compliance CE, cETLus, and Damp Location *the width is given for one of the two lamp modules **Requires the Adelphi wireless connector MITRA User Manual V. 2.2...
-
Page 10: Psu Overview
70 mm / 2.8 in 426 mm / 16.8 in Plus hole Lamp Cable 180 mm 1800 mm / 7.1 in 200 mm / 7.9 in / 70.9 in 300 mm / 11.8 in Power Cable Front view Dimming Cable Side view www.heliospectra.com... -
Page 11: Psu Flex (Mipsu03)
380 mm / 15 in Lamp Cable 200 mm / 7.9 in (MIPSU04) Power Cable 500 mm / 19.7 in (MIPSU03) 1800 mm / 70.9 in Front view Dimming Cable 300 mm / 11.8 in MITRA User Manual V. 2.2... -
Page 12: Technical Specifications
0-10VDC, 10V PWM signal or WiFi* Cooling Passive - Convection cooled Passive - Convection cooled Housing ABS plastic and Anodized Anodized Aluminum Material Aluminum Compliance CE, cETLus, and Damp Location CE, cETLus, and Damp Location *Requires the Adelphi wireless connector www.heliospectra.com... - Page 13 Operating: -10-40°C (14-104 F) Temperature Storage: -20-70°C (-4-158 F) IP Rating IP67 Lifetime >218 000 hrs Controllable 0-10VDC or 10V PWM signal Cooling Passive - Convection cooled Housing Anodized Aluminum Material Compliance CE, cETLus, and Damp Location MITRA User Manual V. 2.2...
-
Page 14: Mounting Instructions
None of the power cables can be used to support the weight of the fixture. Air must be able to flow freely around the MITRA fixture and power supply, they are cooled using passive, convection cooling. -
Page 15: Mitra Linear (Mi65Lf, Mi65Lv, Mi65Lb)
(1.65 in). 3.3 MITRA Split (MI65LFS, MI65LVS, MI65LBS) Hole Profile MITRA Split fixtures are equipped with a hole profile from which the fixture can be hung with off-the-shelf chains/wires and hooks. The hole diameter is 5 mm (0.19 in). MITRA User Manual... -
Page 16: Psu 0-10V Dimming (Mipsu01)
SIGNATURE DATE TITLE: MITRA PSU DRAWN CHK'D Standard APPV'D 3.5 PSU Flex MATERIAL: MITRA manual PSU closeup DWG NO. & WEIGHT: SCALE:4.5:1 SHEET 2 OF 2 (MIPSU03) PSU Dimming B (MIPSU04) Chain Mounting Profile PSU Flex (MIPSU03) and PSU 0-10V Dimming B (MIPSU04) have backplates which are pre- pared for mounting with off-the-shelf chains. -
Page 17: Electrical Installation
All electrical installation should be done by a qualified electrician. 4.2.1 Surge Protection Heliospectra AB requires that the fixtures are installed with adequate surge protection according to the local recommended practice. In North America IEEE 1100-2005 contains the recommended practice for powering and grounding electronic equipment. In Europe the applicable standard is IEC 62305 –... - Page 18 Type-3, SPD devices. It is required that a professional engineer, experienced with surge suppression technology, be retained to design the protection system for your facility to ensure all SPDs are properly sized and coordinated. Third zone Second zone First zone www.heliospectra.com...
-
Page 19: Dimming
4.3.1 2-Wire Cable (MIPSU01, MIPSU04) The dimming cable has a black connector which is meant to be connected to your preferred dimming solution. This cable has two internal wires for dimming: Blue: DIM+ White: DIM- MITRA User Manual V. 2.2... -
Page 20: 4-Wire Cable (Mipsu03)
This cable has four internal wires, two for dimming and two for an extra supply of your dimming equipment. The supply is at a 12v and is limited to 200mA of current. Pinout of DIM connector: 1. DIM+ 2. DIM- 3. +12V AUX 4. GND AUX www.heliospectra.com... - Page 21 MITRA User Manual V. 2.2...
-
Page 22: Maintenance
To ensure optimal performance and lifespan of the lamp it is important to clean regularly. If you see a build up of dirt or residue anywhere on the MITRA lamp, this needs to be cleaned. To clean the MITRA most effectively please follow these simple steps. -
Page 23: General Warranty Terms And Conditions
Heliospectra top lights carry a warranty that the hardware components of Heliospectra Products will be free from defects in material and workmanship for a period of five (5) years for the MITRA series and three (3) years for other products, from the date of delivery. The warranty extends only to the original Buyer of the Product and may not be transferred or assigned by the original Buyer. -
Page 24: Terms And Conditions
Heliospectra. In no event does Heliospectra warrant that the software is error free or that the Buyer will be able to operate the software without problems or interruptions. Heliospectra does not give any... -
Page 25: Warranty Limitations
6.2.3 Warranty Limitations This warranty does not apply under any of the following circumstances: a. The Product has been opened or altered by anyone other than Heliospectra or an authorized representative b. The Product has not been installed (including proper electrical and WiFi equipment... -
Page 26: Warranty Claim Process
Heliospectra will arrange for retrieval of the fixture(s) from the customer location b. A failure analysis will be conducted at the Heliospectra Repair Center. If the agent at the repair center finds that the cause of the issue is attributed to one or more of the... - Page 27 5. Adequate records of operating history, maintenance, and/or testing to substantiate that the Product has failed to comply with its intended performance 6. Original or equivalent packaging to ship the unit(s) to the Heliospectra Repair Center MITRA User Manual V. 2.2...
-
Page 28: Implied Or Other Warranties
6.4 Disclaimers To the full extent permitted by law, Heliospectra will not be liable to the Buyer for any loss or damage arising from the use of the Product, or any defect in the Product, however it may arise. - Page 29 Contact Details Got questions? Or need info related to how to set your new MITRA? Visit our Support Portal for User Manauals, articels and videos. https://support.heliospectra.com/portal/en/home Or sent our dedicated support team an email at support@heliospectra.com UK Authorised Representative: Comply Express Ltd, Unit C2, Coalport House, Stafford Park 1, Telford TF3 3BD, United Kingdom...
