Toshiba dynadock PA5238U-1PRP Quick Start

Wi-ac wireless docking station

Download this manual

dynadock

Docking Station

Quick Start

PA5238U-1PRP

Check the components:

• dynadock WiAC wireless

docking station

• USB 3.0 cable

• AC adapter and power cord

Getting started

Keep this guide in a convenient place to access important

information. It is strongly recommended that you read the

User's Guide to learn about the dynadock wireless docking

station's features including how to optimize your video and

audio settings. The User's Guide can be downloaded at

support.toshiba.com under "Manuals and Specs".

Quick Tour

Front

Security lock slot

Wi-AC Wireless

Wi-Fi Protected Setup™/Undock button

USB 3.0 port

• Wall mount hardware

• Quick Start

(this document)

• Standard Limited Warranty

Power indicator

USB Upstream indicator

Wireless communication

indicator

Headphone /Microphone combo jack

Page 1 It is strongly recommended that you read the User’s Guide to learn about the dynadock wireless docking station’s features including how to optimize your video and audio settings. The User’s Guide can be downloaded at support.toshiba.com under “Manuals and Specs”. Quick Tour Power indicator Front Wi-Fi Protected Setup™/Undock button...
Page 2 Back LAN jack Power switch USB Upstream DisplayPort connector* DC In jack HDMI out port ® USB 3.0 ports *To PC for USB docking station feature Underside SSID/password label Wall mount hole Wall mount hole Reset button Connect the dynadock wireless docking station 1.
Page 3 Wireless connection with your computer 1. Verify that your Windows computer is powered on. ® 2. Right-click on the Windows Wireless Connection Manager ( in the system tray and choose the “dynadockWiAC_XXXXX”. 3. When prompted for a password, press the WPS (Wi-Fi Protective Setup) button on the top of the unit to populate the password.
Page 4 Need Help? Contacting Toshiba For technical support, software and hardware options, and other product information, be sure to check the Toshiba Web site at support.toshiba.com. dynadock is a registered trademark of Toshiba Corporation. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI licensing LLC in the United States and other countries.
