Operating Instructions and Parts Manual
Please read and save these instructions. Read through this owner's manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could
result in personal injury and/or damage to product or property. Please retain instructions for future reference.
49EV14
Description
This Westward heavy-duty top tool chest has a durable coating
and finish, sturdy construction, and heavy load capacity to extend
product life. Heavy-duty full extension ball bearing slides ensuring
smooth functionality of all drawers.
Ball bearing slides have a quick release design that gives great
flexibility when reconfiguring the drawers. And auto return features
of the chest is for added safety to prevent unwanted, accidental
opening of drawers while in transit. The tool chest includes an
internal locking system for added security. The chest also has side
carrying handles that allow easy transport.
The lift struts on both sides enable the user to open the lid
conveniently and safely. This chest is ideal for professional mechanics and garage owners interested in storing and
organizing tools and parts.
Unpacking
When unpacking unit, please ensure the unit is upright. Avoid using sharp objects to open the unit.
After unpacking unit, inspect carefully for any damage that may have occurred during transit. Check for loose,
missing, or damaged parts. Shipping damage claim must be filed with carrier.
Specifications and Dimensions
Model Type
49EV14,49EV15,48ZC86 Heavy Duty
Loading Capacity of Drawers
Width of drawer Max. Load
42" (1066mm) 100lb. (45Kg)
MGC200001
Printed in Taiwan
09/12
INTERMEDIATE CHEST
49EV15
No. of
Drawers
Description
INTERMEDIATE CHEST 3
1
49EV14, 49EV15, 48ZC86
48ZC86
Dimensions (Imperial/Metric)
Width Depth
18.6"(472MM)
42"(1066MM)
Height
16"(409MM)
