- Page 1 Operating Instructions & Parts Manual TOP CHEST Models : 4 9 N R 8 4 / 4 9 N R 8 5 4 9 N R 8 6 / 4 9 N R 8 7...
- Page 2 UNPACKING READ AND SA Steps: When unpacking, please ensure the unit is upright. READ CAREFULLY Do not use any sharp objects to open the packaging. BEFORE A ASSEMBLE, INST After unpacking unit, inspect carefully for any damage that may OPERA OR MAINTAIN THE have occurred during transit.
- Page 3 SPECFICATIONS GENERAL SAFETY INFORMATION The Westward heavy top chest has a durable grey + red (black) finish Grainger No. of and strong load capacity. The heavy top chest is equipped with full Type Description Width Depth Height Items No. Drawers...
- Page 4 Description OPERAITON FOR DRAWER To remove the drawer: To remove drawers, release the retaining clip by pushing the lever up on one side and down on the other side simultaneously Then pull the drawer out. MAINTENANCE To install the drawer: Lubricate the lock with graphite annually .
- Page 5 REPAIR PARTS ILLUSTRATION FOR 49NR84/49NR85 KEY REPLACEMENT FOR 49NR84/49NR85 49NR86/49NR87 49NR86/49NR87 To remove lock and key set: 1. Remove all drawers for easy lock removal and installation. 2. Remove spring clip (3) using hand tool, eg: pinchers. 3. Pull out the whole central lock including key (1), lock (2), and central locking bar (4).
- Page 6 REPAIR PARTS LIST Ref.No. Part No. Description Q'ty One Lock set and Two Key for(For 07-15-2 1 pair 49NR84/49NR85/49NR86/49NR87) Ball bearing slides 13-22F 1 pair (For 49NR84/49NR85/49NR86/49NR87) Gas lift (For 15-ACA-A421081 1 pair 49NR84/49NR85/49NR86/49NR87) Gas lift (For 15-AC757101 1 pair 49NR84/49NR85/49NR86/49NR87)
- Page 7 YOU WILL NEED TO PROVIDE, TO THE EXTENT AVAILABLE, THE PURCHASE DATE, THE ORIGINAL INVOICE NUMBER, THE STOCK NUMBER, A DESCRIPTION OF THE DEFECT AND ANYTHING ELSE SPECIFIED IN THIS WESTWARD ONE-YEAR LIMITED WARRANTY. YOU MAY BE REQUIRED TO SEND THE PRODUCT IN FOR INSPECTION AT YOUR COST. YOU CAN FOLLOW UP ON THE PROGRESS OF INSPECTIONS AND CORRECTIONS IN THE SAME WAYS.
