KBC ENC-H-W Series User Manual

H.264 ip encoder
Hide thumbs Also See for ENC-H-W Series:
Table of Contents

Advertisement

Quick Links

Download this manual
ENC-H-W*
H.264 IP Encoder
ENC-H
ENC-H-W*
EDKT-H
EDKT-H-W*
User Manual

Advertisement

Table of Contents
loading

Related Manuals for KBC ENC-H-W Series

Summary of Contents for KBC ENC-H-W Series

  • Page 1 ENC-H-W* H.264 IP Encoder ENC-H ENC-H-W* EDKT-H EDKT-H-W* User Manual...

  • Page 2: Table Of Contents

    Video Related Problems ........................43 PTZ Control ............................39 Contact Closures ........................... 40 GUI Tools ............................... 40 Contact KBC Technical Assistance ......................41 WARRANTY ................42 Warranty Information ........................... 42 SAFETY, APPROVALS AND REGULATORY DOMAIN INFORMATION ....43 Safety Instruction ..........................43 Regulatory Certifications ........................

  • Page 3: Overview

    Ethernet format in order to connect to an existing network, fiber media converter or wireless Ethernet system such as the KBC WESII series. This manual covers all features and operations of the encoder. The operations of the KBC Decoder are found within its own operations manual.

  • Page 4: Technical Specification

    General interface Network TCP, UDP, IP, HTTP, PPPoE, DNS, DDNS, Protocol Supported DHCP, IGMP, RTP, RTSP, IPv6, FTP, SMTP, NTP, ICMP, ARP Layer 2, 3 * Denotes default configuration Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 4 of 49 www.kbcnetworks.com...
  • Page 5 1 x RJ45 Composite RS-422/485/232 4 pin terminal block DI/DO 4 pin terminal block Power 3 pin terminal block Approvals FCC Part 15 subpart C IC ID# Class B Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 5 of 49 www.kbcnetworks.com...

  • Page 6: Installation

    12V dc input Ground Not used To reset, hold during power up process Digital output Digital input DIO voltage in DIO ground Desired activity: solid amber, green rapid flash Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 6 of 49 www.kbcnetworks.com...
  • Page 7 2.2.3.2 RS-232 The reverse dip switch positions (i.e. first four ON/down and second four OFF/up) will change the encoder into RS-232 mode. 1 2 3 4 5 6 7 8 Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 7 of 49 www.kbcnetworks.com...
  • Page 8 Encoder User Manual 2.2.4 Status LED Description The KBC Encoder offers status LEDs for the power and data as well as on the LAN port for link status and activity. 2.2.4.1 Data TX/RX LEDs Power LED. Allow 30 seconds after power up to illuminate steady.
  • Page 9 Receive From encoder: to camera: Ground 2.2.6.4 Known Incompatible Protocols The following data protocols are not supported by the KBC encoder/decoder: Sensornet • Biphase & Bilinx, other Bosch proprietary protocols • Kalatel protocols using RS-422. The system is compatible in RS-485 at 9600 •...

  • Page 10: Product Deployment

    2.3.1 Product Default Configuration Settings 2.3.1.1 Operations Manual Defaults – Out of the Box Convenience Presets Prior to shipment from the KBC product warehouse KBC presets configurations for compatibility with other KBC products, these preset configurations are as follows: LAN/WAN IP Address 192.168.1.100...
  • Page 11 The green LED on the front on the ENC-H-W* will illuminate if the encoder is connected to a valid network/Ethernet device. If connected to a switch or KBC WESII / MESHII system then a straight through cable is needed for this connection.
  • Page 12 The KBC Encoder can also replace an SED series encoder and connect to an SED series decoder if applicable. If an SED series decoder is in use the easiest reconfiguration is to set the new encoder to the settings of the old SED series encoder which is no longer in use.
  • Page 13 Note: If a connection to a KBC Decoder cannot be established in the field or on a network, KBC recommends a test with the encoder directly connected to its mate decoder using a crossover cable. If the two units are connected via an unmanaged switch then the interface screen can be accessed from a web browser in order to identify if a problem in configuration exists.

  • Page 14: Graphical User Interface

    Ethernet connection such as the KBC WESII series products. The web browser GUI is accessible via a computer set to the same static subnet as the encoder. See section 3.1.1.1 below to ensure that your computer Operating System is supported.
  • Page 15 The language option chosen from the account ID / password login will remain only for the duration of the login period. The next login visit will revert to the selected language from the Host Setting configuration page. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 15 of 49 www.kbcnetworks.com...

  • Page 16: Initial Gui Access & Video Display

    Configuration Detail Click pull down menu to show streaming options. Select MPEG4 if connecting to a KBC MPEG4 Decoder. There is no need to apply or save/reboot as this selection will apply automatically and will remain the selected streaming type until changed here later.

  • Page 17: Main Menu

    This person will be able to view the entire menu of options as shown on the screen shot below. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 17 of 49 www.kbcnetworks.com...
  • Page 18 Item Configuration Detail Enter a host name for this device or keep the default “KBC”. The configured text will appear on locating software such as the “IP Utility” Selecting your desired language here will write to the device memory to keep the selected language after a logout or reboot.
  • Page 19 SNTP/NTP or manually. If your local area observes Day Light Saving, you can program the encoder to automatically change its time when Day Light Savings time begins and ends each year. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 19 of 49 www.kbcnetworks.com...
  • Page 20 “Allow” (or is listed in the “Block” list) you will be denied access from the encoder web browser GUI. An incorrect configuration may result in the need for a hard reset to factory default. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 20 of 49 www.kbcnetworks.com...
  • Page 21 The port mapping screen allows configuration of the video streaming, video multicast, HTTP and other ports. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the Port Mapping. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 21 of 49 www.kbcnetworks.com...
  • Page 22 UPnP. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the UPnP Setting. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 22 of 49 www.kbcnetworks.com...
  • Page 23 3.3.8 Network: RTP Click the RTP Item to configure RTP settings. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the RTP Setting. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 23 of 49 www.kbcnetworks.com...
  • Page 24 Click to enable 802.1x settings. Enter your user name and password. The new settings will take effect after a save/reboot. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the IEEE 802.1x Setting. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 24 of 49 www.kbcnetworks.com...
  • Page 25 The WAN Setting is where the network properties of the encoder are configured. Keep a record of changes or use the IP Utility to find the IP addresses if changed from default configurations. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 25 of 49 www.kbcnetworks.com...
  • Page 26 3.3.12.2 Static IP Address KBC recommends selecting a static IP on the network. Advise the network administrator for available static IP addresses prior to configuring the encoder on the local network. The Gateway IP must be on the same subnet as the IP address. If the subnet mask is changed from the default configuration, ensure that your computer is set within the scope of the filter (mask) configured.
  • Page 27 Password: Enter the login password you would use to access your DDNS service • account. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the DDNS Server Setting. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 27 of 49 www.kbcnetworks.com...
  • Page 28 In the image above the brightness, saturation and contrast settings are shown as default settings. When the red line marker is moved away from its default configuration toward 100 (or toward 0) the picture in the display above will change accordingly. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 28 of 49 www.kbcnetworks.com...
  • Page 29 A smaller threshold will result in the encoder responding to movement by smaller objects or even natural background noise. The default value is 10; increase to filter out smaller objects. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 29 of 49 www.kbcnetworks.com...
  • Page 30 3.3.15.3 Compression Under the Compression tab is where the bit rate and other such settings are located. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 30 of 49 www.kbcnetworks.com...
  • Page 31 Video Maximum The range of the bit rate is from 28 Kbps up to 3 Mbps, • Bitrate with “UNLIMITED” an option as well. The default setting is 1.2 Mbps Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 31 of 49 www.kbcnetworks.com...
  • Page 32 The redacted display will also be presented on the video output when connected to a KBC Decoder. When the OSD is selected, the format parameters must match the format notice. At that point whatever is written into the “pre-defined text”...
  • Page 33 Event servers are classified as FTP servers, SNTP servers, and HTTP servers. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the Event Server Setting. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 33 of 49 www.kbcnetworks.com...
  • Page 34 For most types of responses, several different preset response templates can be created. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the Event Configuration Setting. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 34 of 49 www.kbcnetworks.com...
  • Page 35 GUI web display as a method for testing the event triggers. Note: Click on “Apply” in this section of the web browser GUI to apply changes to the Manual Event Setting. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 35 of 49 www.kbcnetworks.com...
  • Page 36 Encoder User Manual 3.3.21 System: User Account In this section the root admin password can be modified and additional view only users can be identified. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 36 of 49 www.kbcnetworks.com...
  • Page 37 If the administrator account and/or password are changed, the decoder must be given that info in its “Connection Setting” configuration page. The encoder and decoder account and password settings do not have to match. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 37 of 49 www.kbcnetworks.com...
  • Page 38 Encoder User Manual 3.3.21.2 Adding View Only Users View Only users have access to the video display and system info screens only. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 38 of 49 www.kbcnetworks.com...
  • Page 39 Video Bit Rate & Mode 1.2 Mbps, Constant • Serial Port Baud Rate 9600 BPS • Serial Port Control 8, None, 1 • Video Control Port 6001 • Video Streaming Port 6002 • Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 39 of 49 www.kbcnetworks.com...
  • Page 40 You will require the images and md5 files in order to successfully upgrade firmware. These files must be obtained from KBC and saved in an accessible place to locate from the “Browse” button. Browse and locate then click “Apply”.
  • Page 41 Clicking the log out button will keep an authorized user from accessing the configurator and will require re-entering the account ID and password for either the root admin or other assigned view only users. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 41 of 49 www.kbcnetworks.com...

  • Page 42: Troubleshooting

    Always protect the cabling from sources of potential harmful voltage surges. 4.3 Video Related Problems If the encoder connects to a KBC Decoder which is not displaying a video output, the following steps can be followed to check the encoder side of the link: 4.3.1 Check Camera Output If there is a problem with the composite video output, the decoder will display the same error message as if the link between the two devices was not established.

  • Page 43: Ptz Control

    4.5 Contact Closures See section 2.2.7 for the specs of the alarm input and output parameters. 4.6 GUI Tools Go to KBC Networks’ website to download the IP Utility tool to assist in diagnostics of the encoder and decoder IP devices. Manual-H264_ENC-Rev1207A Copyright ©...

  • Page 44: Contact Kbc Technical Assistance

    This manual is comprehensive to the extent that it will answer many of your technical questions. KBC also offers technical support over the phone or by e-mail to all KBC integrators, dealers and end users of the encoder product. Our technical support hotline is available during regular business hours, Monday through Friday on all non-major holiday business days.

  • Page 45: Warranty

    KBC, to be defective in material or workmanship, KBC will repair or replace such part or portion at KBC’s option. The warranty period on the repaired or replaced part or portion of this product shall be limited to the unexpired term of the original warranty.

  • Page 46: Safety, Approvals And Regulatory Domain Information

    OBSERVE WARNINGS: All warnings in the operating instructions should be carefully followed. Do not make any modifications to the encoder unit, power supply, or any other KBC Networks electronic device, as the unit(s) will no longer comply with legal regulations and therefore void its warranty.

  • Page 47: Instruction Of Disassembly

    2. Slide out top lid 3. Remove screws from back end face of encoder. 4. Slide out printed circuit board (PCB). Notice: When a product reaches the end of its life – return to KBC. Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 47 of 49 www.kbcnetworks.com...

  • Page 48: Annex A - General Public License Statement

    Encoder User Manual Annex A - General Public License Statement You may have received from KBC Networks products that contained – in part – free software (software licensed in a way that ensures your freedom to run, copy, distribute, study, change and improve the software). Such products include the ENC- H-Wx family of products.
  • Page 49 Fax: 1-949-297-4933 KBC Networks Ltd. EMEA KBC Networks Ltd. Barham Court Teston, Maidstone Kent, ME18 5BZ United Kingdom Phone: +44(0)1622 618787 Fax: +44(0)20 7100 8147 Email: info@kbcnetworks.com Web: www.kbcnetworks.com Manual-H264_ENC-Rev1207A Copyright © KBC Networks 2012 Page 49 of 49 www.kbcnetworks.com...
