- Page 1 USER MANUAL PULLEY KIT EIPUL-KIT...
- Page 2 PULLEY KIT EIPUL-KIT The KIT Included: ▪ 1 35cm Track ▪ 2 Track Leg ▪ 2 20" Rod ▪ 2 Track Rider ▪ 2 Boss Head ▪ 2 100g Slotted Mass ▪ 3 50g Slotted Mass ▪ 1 Slotted Mass Hanger ▪...
- Page 3 ▪ Rod with pulley (perpendicular) ▪ 20" rod ▪ Pulley with hook ▪ Track rider ▪ Thread (~1m) ▪ Boss head ▪ 3 m measuring tape ▪ 100 g slotted mass The items above are included in the Pulley kit, EIPUL-KIT Ver 2.15.4...
- Page 4 1.3. Experimental procedure * Experiment setup 1. Set up the experiment as shown in the picture below. 2. Attach the track legs to the track. 3. Slide the track rider to the middle of the track. 4. Insert the 20" rod in the track rider. 5.
- Page 5 14. Click on the Extra command button and then on the Push=Negative button to get positive values when hanging the cart from the force sensor's hook. 15. Click on the icon to go back to the graph. 16. Click on the Run Experiment icon and setup: Experiment duration to 10 seconds Sampling rate to 10 per second...
- Page 6 * Testing and measurements Note: The orientation of the sensor is very important. Before each measurement, hold the sensor in the same orientation you will use for the specific experiment and zero it. 17. Sensor Zeroing: hold the sensor in the proper orientation (the hook should be facing downwards for the first measurements) and press the button in the sensor’s box for about 3 seconds.
- Page 7 19. Click on the Record icon to start the measurement. 20. Your graph should be similar to the following: 21. Click on the Export Icon and then on the Save value table (.CSV) button to save your graph. 22. Click on the icon to go back to the graph.
- Page 8 Slotted mass Measured force (with mass holder and No pulley) 100 g 1.03 (sample experiment) 100 g 200 g 25. Click on the icon to go back to the graph. 26. Add another 100 g slotted mass (you will now have 200 g). 27.
- Page 9 32. In order to measure the effort force, click on the Record icon to start the measurement. 33. Your graph should be similar to the following: 34. Repeat the measurement with a 200 g slotted mass (without erasing the first graph).
- Page 10 37. Write the average force values in the following data table. Fixed pulley Slotted Effort Load force Mechanical Distance Velocity mass force (without a advantage moved by Ratio movable pulley) (Load/Effort) the effort (distance moved by load is 10cm) 100 g 1.03 1.004 (sample...
- Page 11 42. Hang a 100 g slotted mass and click on the Record icon to start the measurement. 43. Repeat the measurement with two 100 g slotted masses without erasing the first measurement. 44. Write the results in the following data table. Movable pulley Slotted Load force...
- Page 12 51. Repeat the measurement with two 100 g slotted masses without erasing the first measurement. 52. Write the results in the following data table. Compound pulley Slotted Load force Effort Mechanical Distance moved by Velocity mass force [N] the effort (with a advantage Ratio...
-
Page 13: Electronic Instrumentation
ELECTRONIC INSTRUMENTATION Add.: 12, Mahesh Nagar, Ambala Cantt, Haryana, India Tel: +91-171-2663087, 2662797...
