CARATTERISTICHE TECNICHE
/ TECHNICAL FEATURES
• Lamiera elettrozincata
• Verniciatura in poliestere da esterno
• compatibile con tutte le Mensole serie GIOTTO, GALILEO, LEONARDO
GALILEO, LEONARDO
DIMENSIONI
/ DIMENSIONS
CODICE / CODE
DESCRIZIONE / DESCRIPTION
BARRA A MURO L. 1000 PER MENSOLE GIOTTO -GALILEO - LEONARDO
SCD500161
/ WALL BAR L. 1000 FOR GIOTTO - GALILEO - LEONARDO BRACKETS
MONTAGGIO
/ ASSEMBLY
Il kit è compatibile con tutte le Mensole serie GIOTTO, GALILEO, LEONARDO
2
MANUALE D'USO / USER MANUAL
KIT BARRA A MURO
/ Galvanized sheet metal
/ Exterior-grade polyester powder coating
WALL BAR KIT
DIMENSIONI / DIMENSIONS
MONTAGGIO / ASSEMBLY
Kit compatible with all Bracket series GIOTTO, GALILEO, LEONARDO
/ compatible with all Bracket series GIOTTO,
Cod. SCD500161
A
C
B
CLI00098
A [mm]
B [mm]
C [mm]
1000
960
550
Pos.
Art.
Q.tà
1
CDM02555
Pos.
Art.
2
C10005271
1
CDM02555
2
C10005271
3
C10006593
3
C10006593
4
C10005740
4
C10005740
5
C10005301
6
C10007991
5
C10005301
7
C10005339
6
C10007991
7
C10005339
1
Q.tà
1
1
1
5
5
2
2
2
3
2
3
3
3
