MANUAL
VERHÜTERLI
We congratulate you on purchasing your TUNE product. You made a good choice.
Nonetheless it is necessary to follow these instructions and maintain your product
as told in this manual. Familiarize possible other users with this manual.
Before every ride, ensure that the Verhüterli is assembled as outlined in this manual.
An incorrect installation or adjustment can lead to serious or fatal injuries.
Please read the owners manual carefully for your respective fork and stem.

Technical Data:

Material
Weight
Cap Diameter
Fitting steering tube inner diameter
Insertion depth

Compatibility:

The Verhüterli is made for steering tubes with a inner diameter from 23.50mm to 23.95mm.
The Verhüterli is only for road bikes.

Assembly:

To mount the Verhüterli first loosen the stem bolts at the steering tube. Next the Verhüterli can be pushed
on to the steering tube, afterwards the stem bolts can be tightened.
Please follow the installation instructions of your fork and stem manufacturer.

Disassembly:

Bevore removing the Verhüterli the stem bolts must be loosened completely. Afterwards the Verhüterli can
be removed with the stem. A wrong disassembly can damage the Verhüterli.
r Gabelschaftrohre
endurchmesser von
Manual
|
VERHÜTERLI
23,95 mm
As of December 2016
TUNE products are manufactured under highest quality standards.
32,5 mm
BORN IN THE B LACK FOREST
Carbon
3 g
32.5
23.50 mm - 23.95 mm
10 mm
BUILT TO ENJOY NATURE
December 2016
www.tune.de
Page 1 of 2
