ESG–410
1
UNIVERSAL sockets
2
SURGISABER socket
(without function)
3
Power switch
Instrument sockets and compatible plug types
Sockets
MONOPOLAR
BIPOLAR
UNIVERSAL
7
ESG-410
UNIVERSAL 1
UNIVERSAL 2
MONOPOLAR 1
MONOPOLAR 2
SURGISABER
Instrument plugs
3-pin plug
9/5 mm coaxial plug
8 mm plug
4 mm plug
2-pin plugs
(22 or 28.6 mm pin space)
8/4 mm coaxial plug
Olympus UNIVERSAL plugs
BIPOLAR socket
BIPOLAR
NEUTRAL
Neutral electrode socket
4
ESG–410
Sockets and screens
Quick Reference Guide
6
Touchscreen
(see page 2)
5
MONOPOLAR sockets
Monopolar instruments are not
automatically recognized by the ESG-410.
WARNING
A 4 mm plug can only go
into the white ring.
Bipolar instruments are not automatically
recognized by the ESG-410.
Only for Olympus instruments which
are automatically recognized by the
ESG-410.
Page 1 of 4
