Makerfire Armor 65 Lite Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

3/18/2019
Makerfire Armor 65 Lite
Contents
1 Specification
2 Control Instructions(Mode2)
Specification
Wheelbase： 65mm
Flight controller: Tiny Lite Silverware FC
Remote： Tiny lite RC
Motor ： 7×16mm 17600KV（65000rpm@3.7V）
Propeller： 4-Blade 31mm
VTX ： 5.8G/40CH/25mW
Camera ： 800TVL/120°
Battery： 300mAh /3.8V/1S/30C/Li-HV
Flight time: 4min20second
Remote Distance: 100 meters
Control Instructions(Mode2)
http://120.78.50.96/index.php/Makerfire_Armor_65_Lite
Makerfire Armor 65 Lite - Makerfire
1/9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Armor 65 Lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Makerfire Armor 65 Lite

Summary of Contents for Makerfire Armor 65 Lite

  • Page 1: Table Of Contents

    3/18/2019 Makerfire Armor 65 Lite - Makerfire Makerfire Armor 65 Lite Contents 1 Specification 2 Control Instructions(Mode2) 3 RC Gestures Setting (Mode2) 4 Armor65 Lite radio transmitter 5 Remote control configuration 6 Charging instructions 7 PACKAGE 8 How to Flash Firmware for Lite FC...
  • Page 2 3/18/2019 Makerfire Armor 65 Lite - Makerfire http://120.78.50.96/index.php/Makerfire_Armor_65_Lite...

  • Page 3: Rc Gestures Setting (Mode2)

    3/18/2019 Makerfire Armor 65 Lite - Makerfire RC Gestures Setting (Mode2) Left - Left - Down: acro mode Right - Right - Down : level mode Up - Down - Up: Cycle pid term to the next ( P - I - D )
  • Page 4 3/18/2019 Makerfire Armor 65 Lite - Makerfire Down - Down - Down: Accelerometer calibration / Save pids if changed VTX Introduction: The 25mW/40CH AIO camera in Armor65 lite is characterized by wide dynamic, high-definition, wide angle and no delay.The light and mini AIO camera supports button and frequency choice as well as NTSC/PAL TV system.

  • Page 5: Armor65 Lite Radio Transmitter

    Other 4in1 multiprotocol module that support the Bayang protocol. If not sure whether your radio transmitter could support this FC board, please email us (Support@makerfire.com) for help. For example, if you have a Frsky Tanaris QX7 / X9D radio transmitter and want to try this FC board, just plug in a MTX90 multiprotocol module.
  • Page 6 3/18/2019 Makerfire Armor 65 Lite - Makerfire Power up the Armor65 Lite, the FC indicator LED flashes slowly for 6 times and then turnes into fast flash mode. The fast flash mode shows the beginning of the binding mode. Step2 There is the "di"...
  • Page 7 3/18/2019 Makerfire Armor 65 Lite - Makerfire MAXER Setting CH1-->Thr CH2-->Ail CH3-->Ele CH4-->Rud Step4 Turn off the radio transmitter. Power up the Armor65 lite RTF and wait for the binding mode. When the The indicator LED flashes fast,turn on the radio transmitter and push the right-Throttle to top-right direction.

  • Page 8: Charging Instructions

    3/18/2019 Makerfire Armor 65 Lite - Makerfire 4)Other radio transmitter CH1：AIL（ROLL） CH2: ELE (PITCH) CH3: THR (THROTTLE) CH4：RUD (YAW) CH5：ARM/DISARM（1000:DISARM,2000:ARM） CH6：ANGLE/ACRO（1000:ANGLE,2000:ACRO） Charging instructions Notes: 1 . Charge the battery in time when low voltage. 2 . Turn the USB charger into 4.35v before charging.

  • Page 9: How To Flash Firmware For Lite Fc

    About how to flash the firmware, please check on Silverware offical website or RCG. https://www.rcgroups.com/forums/showthread.php?2876797-Boldclash-bwhoop-B-03-opensource-firmware The firmware for Makerfire TinyLite FC board is available in the attached file. If You want to compile the files by yourself, please download the files here: https://github.com/NotFastEnuf/NFE_Silverware...
