- Page 1 Latch locks User Manual ND-M Series M560, M565, M660 A non-key door lock may be partially broken to open the door when it malfunctions. Retain this user manual for future reference after reading it thoroughly.
-
Page 2: Table Of Contents
CONTENTS Safety Precautions Products Specifications / Components Parts Name PIN-codes Activation / Deactivation Card keys Activation / Deactivation Remote Controllers Activation / Deactivation Fingerprints Activation / Deactivation Double Authorization Mode Pre Authentication Mode Opening Door / Locking Door Opening the Door from Outside Locking the Door from Outside Opening the Door from Inside Locking the Door from Inside... -
Page 3: Safety Precautions
Safety Precautions ㆍRead this manual carefully and use the product accordingly. ㆍThis product was designated for the residential door, if it is used for other purpose, the performance cannot be warranted for its original purpose. ㆍLong-term exposure to direct sunlight, to moisture or to salinity may cause deformation of the product. -
Page 4: Products Specifications/Components
Products Specifications/Components ● Products Specifications Authentication Method Model PIN-code Card key Fingerprint Emergency Remote controller (up to 10) (up to 30) (up to 100) Key (2ea) (Optional Features) M560 up to 5 M565 M660 ※ Remote Controller is optional. Description Specification Door Thickness 40~50mm... -
Page 5: Parts Name
(only for applied models) Numeric Touch Plate Numeric Touch Plate Emergency Emergency Power Supply Terminal Power Supply Terminal Handle Handle ND-M660 ND-M560 ND-M565 ● Inner body Latch Battery cover button Latch bolt [OPEN/CLOSE] button Handle ※ All images shown are for illustration purposes only. -
Page 6: Pin-Codes Activation/Deactivation
PIN-codes Activation/Deactivation ● PIN-codes Activation Open the battery cover, press the only applied M560 model Open the battery cover, button shortly. When the numeric press the button shortly. When the Numeric touch touch plate is on, enter the registered plate is on, enter the registered PIN-code with the PIN-code with the [ ] button. -
Page 7: Card Keys Activation/Deactivation
Card keys Activation/Deactivation only applied model with an Card key ● Card keys Activation Open the battery cover, press the button shortly. When the numeric touch plate is on, enter the registered PIN-code with the [ ] button. Beep Place all Card keys to the Card key touch plate. The sound beeps when registration of each card has been done. -
Page 8: Remote Controllers Activation/Deactivation
Remote Controllers Activation/Deactivation ● Remote Controllers Activation ㆍRemote controllers are not provided with a standard package. only applied M560 model Open the battery cover, press the Open the battery cover, button shortly. When the numeric press the button shortly. When the Numeric touch touch plate is on, enter the registered plate is on, enter the registered PIN-code with the PIN-code with the [ ] button. -
Page 9: Fingerprints Activation/Deactivation
Fingerprints Activation/Deactivation only applied model with an Fingerprints (ND-M565) ● Fingerprint Activation ㆍFingerprint recognition may not be possible if the fingerprint is damaged. ㆍFingerprint recognition may not be possible if sweat or moisture is on the fingerprint or the fingerprint reading panel. ㆍTo raise the recognition rate, we highly recommend you to add same fingerprints in different conditions. -
Page 10: Double Authorization Mode
_ 10 Double Authorization Mode Only for models with more than one authorization ● Double Authorization Mode Activation ㆍDouble Authorization Mode requires two different authentications registered to activate. ( e.g. [PIN-code] + [Fingerprint], [PIN-code] + [Card Key] ) Touch the numeric touch plate gently, then the touch plate turns on. -
Page 11: Pre Authentication Mode
_ 11 Pre Authentication Mode ● Pre Authentication Mode Activation ㆍPre Authentication mode is default mode. Please enter the PIN-code first to enter the setting mode. Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code. Press the [#] button twice then press number [8]. -
Page 12: Opening Door / Locking Door
_ 12 Opening Door / Locking Door ● Opening the door from outside Using PIN-codes Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code and then [ ] button. The door will open with a verification sound. -
Page 13: Opening The Door From Inside
_ 13 Opening Door / Locking Door ● Opening the door from inside Using Handle ▶ Pull down the handle of the inner body when the door is locked, then the door will open. Using [OPEN/CLOSE] button ▶ Press the [OPEN/CLOSE] button when the door is locked, the door will open. -
Page 14: Safety Lock Mode [Indoors]
_ 14 Safety Lock Mode [Indoors] ● Safety Lock Mode [Indoors] ㆍDoor will not be opened by using authentication method from outdoors. Activating Safety Lock Mode ▶ When the door is locked, press the [OPEN/CLOSE] button of the inner body for 3 seconds to activate. Press for 3 seconds Deactivating Safety Lock Mode... -
Page 15: Automatic / Manual Lock Mode
_ 15 Automatic / Manual Lock Mode ● Automatic Lock Mode ㆍAutomatic Lock Mode is the default mode. The door is automatically locked when it closes. However, make sure that the door is completely closed when going outside. Press the [OPEN/CLOSE] button to make the latch bolt come out when the door is open. -
Page 16: Volume Setting
_ 16 Volume Setting ● Silent Mode ㆍThis is a temporary function not to disturb the neighborhood. Touch the numeric touch plate gently, then the touch plate turns on. Press the [#] button. No sound Enter the registered PIN-code with the [ ] button to open doors. ●... -
Page 17: Warning Alarms
_ 17 Warning Alarms ● Fire Detection Alarm When the sensor detects high temperature (60℃±5℃), the door will be automatically unlocked with a loud alarm. Fire Detection Alarm Off To deactivate the alarm, remove the battery, enter the registered PIN-codes, place the Card keys to the Card Key touch plate or put the registered Fingerprint. -
Page 18: Low Battery
_ 18 Warning Alarms ● Low Battery If the red battery icon is ON with an alarm, please replace all batteries. Please do not mix old and new batteries. Make sure batteries are placed in correct poles. Emergency Power Use The product will not operate if the batteries are fully discharged, please follow the steps bellow. -
Page 19: Trouble Shooting
_ 19 Trouble Shooting ● Trouble Shooting When the product is not working properly, check the items below. If you can’t solve the problem, please contact the service center for further assistance. Problem Trouble Shooting ㆍ Make sure the batteries are placed in correct poles(+/-). Door Lock not ㆍ... - Page 20 Neurosys Co., Ltd. made in Korea NE v.2.2...
