User Manual
ND-M Series
M700, M710, M711
H1000, H1100, H1200,
H1300, H1310, H1320
A non-key door lock may be partially broken to open the door
when it malfunctions.
If it is a key door lock, keep the key with in your reach in
case of emergency.
Retain this user manual for future reference after reading it
thoroughly.
Mortise locks
Advertisement
Table of Contents
Related Manuals for SecuLock ND-M Series
Summary of Contents for SecuLock ND-M Series
- Page 1 Mortise locks User Manual ND-M Series M700, M710, M711 H1000, H1100, H1200, H1300, H1310, H1320 A non-key door lock may be partially broken to open the door when it malfunctions. If it is a key door lock, keep the key with in your reach in case of emergency.
-
Page 2: Table Of Contents
CONTENTS Safety Precautions Products Specifications / Components Parts Name PIN-codes Activation / Deactivation Card keys Activation / Deactivation Remote Controllers Activation / Deactivation Fingerprints Activation / Deactivation Double Authorization Mode Pre Authentication Mode Opening Door ● Opening the Door from Outside ●... -
Page 3: Safety Precautions
Safety Precautions ㆍRead this manual carefully and use the product accordingly. ㆍThis product was designated for the residential fire door, if it is used for other purpose, the performance cannot be warranted for its original purpose. ㆍLong-term exposure to direct sunlight, to moisture or to salinity may cause deformation of the product. -
Page 4: Products Specifications/Components
Products Specifications/Components ● Products Specifications Authentication Method Model PIN-code Card key Fingerprint Emergency Remote controller (up to 10) (up to 30) (up to 100) Key (2ea) (Optional Features) M700 M710 M711 H1000 up to 5 H1100 H1200 H1300 H1310 H1320 Description Specification Door Thickness... -
Page 5: Parts Name
Parts Name ● Outer body General Model Fingerprint Model Fingerprint Reading Panel (only for applied models) Numeric Touch Plate Card key Touch Plate Emergency Power Supply Terminal Key Hole (only for applied models) Handle ● Inner body Mortise Battery Cover button [OPEN/CLOSE] button Dead bolt... -
Page 6: Pin-Codes Activation/Deactivation
PIN-codes Activation/Deactivation ● PIN-codes Activation H1200 / H1300 / H1310 / H1320 Open the battery cover, press the button shortly. Open the battery cover, press the button shortly. When the numeric touch plate is on, When the Numeric touch plate is on, enter the enter the registered PIN-code registered PIN-code with the [ ] button and with the [ ] button. -
Page 7: Card Keys Activation/Deactivation
Card keys Activation/Deactivation only for Card key models ● Card keys Activation H1200 / H1300 / H1310 / H1320 Open the battery cover, press the button shortly. Open the battery cover, press the button shortly. When the numeric touch plate is on, When the Numeric touch plate is on, enter the enter the registered PIN-code registered PIN-code with the [ ] button and... -
Page 8: Remote Controllers Activation/Deactivation
Remote Controllers Activation/Deactivation ● Remote Controllers Activation ㆍRemote controllers are not provided with a standard package. H1200 / H1300 / H1310 / H1320 Open the battery cover, press the button shortly. Open the battery cover, press the button shortly. When the numeric touch plate is on, When the Numeric touch plate is on, enter the enter the registered PIN-code registered PIN-code with the [ ] button and... -
Page 9: Fingerprints Activation/Deactivation
Fingerprints Activation/Deactivation only for Fingerprint models ● Fingerprint Activation ㆍFingerprint recognition may not be possible if the fingerprint is damaged. ㆍFingerprint recognition may not be possible if sweat or moisture is on the fingerprint or the fingerprint reading panel. ㆍTo raise the recognition rate, we highly recommend you to add same fingerprints in different conditions. -
Page 10: Double Authorization Mode
_ 10 Double Authorization Mode Only for models with more than one authorization ● Double Authorization Mode Activation ㆍDouble Authorization Mode requires two different authentications registered to activate. ( e.g. [PIN-code] + [Fingerprint], [PIN-code] + [Card Key] ) Touch the numeric touch plate gently, then the touch plate turns on. -
Page 11: Pre Authentication Mode
_ 11 Pre Authentication Mode ● Pre Authentication Mode Activation ㆍPre Authentication mode is default mode. Please enter the PIN-code first to enter the setting mode. Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code. Press the [#] button twice then press number [8]. -
Page 12: Opening Door
_ 12 Opening Door ● Opening the door from outside Using PIN-codes Touch the numeric touch plate gently, then the touch plate turns on. Enter the registered PIN-code and then [ ] button. The door will open with a verification sound. -
Page 13: Opening The Door From Inside
_ 13 Opening Door / Locking Door ● Opening the door from inside Using Handle Using [Thumb turn] button Turn the [Thumb Turn] button of the ▶ ▶ Pull down the handle of the inner body when the door is locked, then the door inner body clockwise when the door is will open. -
Page 14: Safety Lock Mode [Outdoors/Indoors]
_ 14 Safety Lock Mode ● Outdoors ㆍ It is a function to prevent intruders from opening doors by manipulating an internal handle or button. Warning Alarm goes OFF for once. Warning Alarm will be released when the door is opened using the authentication method registered from outside. Activating Safety Lock Mode When the door is locked, touch the numeric touch plate gently, then the touch plate turns on. -
Page 15: Automatic / Manual Lock Mode
_ 15 Automatic / Manual Lock Mode ● Automatic Lock Mode Automatic Lock Mode is the default mode. The door is automatically locked when it closes. However, make sure that the door is completely closed when going outside. Press the [OPEN/CLOSE] button to make the dead bolt come out when the door is open. -
Page 16: Volume Setting
_ 16 Volume Setting ● Silent Mode ㆍThis is a temporary function not to disturb the neighborhood. Touch the numeric touch plate gently, then the touch plate turns on. Press the [#] button. No sound Enter the registered PIN-code with the [ ] button to open doors. ●... -
Page 17: Warning Alarms
_ 17 Warning Alarms ● Fire Detection Alarm When the sensor detects high temperature (60℃±5℃), the door will be automatically unlocked with a loud alarm. Fire Detection Alarm Off To deactivate the alarm, remove the battery, enter the registered PIN-codes, place the Card keys to the Card Key touch plate or put the registered Fingerprint. -
Page 18: Low Battery Alarm
_ 18 Warning Alarms ● Low Battery If the red battery icon is ON with an alarm, please replace all batteries. Please do not mix old and new batteries. Make sure batteries are placed in correct poles. Emergency Power Use The product will not operate if the batteries are fully discharged, please follow the steps bellow. -
Page 19: Trouble Shooting
_ 19 Trouble Shooting ● Trouble Shooting When the product is not working properly, check the items below. If you can’t solve the problem, please contact the service center for further assistance. Problem Trouble Shooting ㆍ Make sure the batteries are placed in correct poles(+/-). Door Lock not ㆍ... - Page 20 Scan to play video channel Operation Guide Lever Handle Lock Neurosys Co., Ltd. made in Korea NE v.2.2...
