  • Page 1 Item Brand Model Market 956001636 Electrolux ESE5300PD-VN VNE,IDH 956001637 Electrolux ESE5300PD-MY MYH,SGE 956001638 Electrolux ESE5300PD-TH Electrolux Thailand Co.,Ltd. 1910 Electrolux Building New Petchburi Rd. Bangkapi Publication-No. Huaykwang Bangkok , 10310 Tel : +662 725 9000 161122...

  • Page 2: Specifications

    SPECIFICATIONS 1.Product informations Items ESE5300P-VN ESE5300PD-MY ESE5300PD-TH Rated Voltage/Frequency 220-240V/50Hz 220-240V/50Hz 220-240V/50Hz Rated current 0.75A 0.75A 0.95A Rated input power 110W 110W 110W Defrost power 306W 258W 306W Climate class Insulation blowing gas Cyclopentane Cyclopentane Cyclopentane Lamp Refrigerator 320.0 320.0 320.0 Freezer 162.0...

  • Page 3: Electrical Components

    SPECIFICATIONS 2.Electrical components Part Type/Model Technical data Model: 168;Type: Plug for MYH&SGE AC250V,13A HEC-168 Plug for IDH&VNE XYP-02/TC04-10 AC250V,16A DT Ш-3P-11 Plug for THE AC250V,16A AC 250V,0.75A ,5E4,T55 Or Door Switch HC-056K Or P29 AC250V,2.5A ,50E3,T85 Compressor LJ118CY AC220-240V,50Hz,R600a Defrosting heater TCRGQ-02 AC 240V,280W (MYH&SGE)
  • Page 4 SPECIFICATIONS 3.Product Dimensions (mm) 4.Interior parts - 4 -...
  • Page 5 SPECIFICATIONS 5.Air flow diagram Return Air Return Air 6.Cooling cycle - 5 -...

  • Page 6: Starting Sequence

    SPECIFICATIONS 7.Starting sequence Remark: Blank box diagram for checking signal of Door in Door function according to this model not included this mode. - 6 -...
  • Page 7 SPECIFICATIONS 8.Sensor distribute location Temp. scope of sensors (C°) Name Location Open Wire break Normal circuit Left-middle side of More than (FS) F-sensor Less than -50 -50~80 F-compartment Left side of air- More than (R1) R-sensor 1 input rim in R Less than -50 -50~80 compartment...
  • Page 8 SPECIFICATIONS 9.Functions of sensor Name Location Functions To control temperature of freezer by Left-middle side of (FS) F-sensor compressor run/stop according to F-compartment setting temperature on UI Left side of air- To control temperature of fridge by (R1) R-sensor 1 input rim in R damper open/close according to compartment...
  • Page 9 PRODUCT INSTALLATION 1.Product installation 1. Allow a minimum of 10mm clearance on both sides. 2. Allow 30mm clearance at the back of the refrigerator. 3. Allow 10mm clearance above the hinge covers. 4. Allow a 349 or 427mm clearance on the hinge side of the doors, if you place the refrigerator next to the wall.
  • Page 10 PRODUCT INSTALLATION 4. Check the alignment of the refrigerator to the surrounding cupboards. The top of the refrigerator should be level from side to side (see diagram below). If you need to adjust the level, use the adjustable rollers as discussed in Step 3. 5.

  • Page 11: Control Panel

    FUNCTION 1.Control Panel ※ To select each mode press of the “Feature Button” ※ The display will turn off after 20 seconds of inactivity, to wake up the display before changing settings touch any button. - Holiday mode - the refrigerator room will operate at 6°c while the freezer room will operate at -15°c.

  • Page 12: Temperature Setting

    FUNCTION Fridge compartment Shut down – Active this mode when no longer to use fridge compartment. Activate the mode by press “Fridge” button hold 3 second display will change to “- -” in fridge compartment. To restart fridge compartment by re procedure press and hold “Fridge’ button 3 second display will change to last setting.
  • Page 13 DIAGNOSTICS MODE 1.Fault checking program The Fault checking program run automatically during appliance operation. To check the Fault code can be checked by press buttons “Feature + Freezer” at the same time see as above figure. Appliance recorded the Fault code when press the buttons to check the fault code the display will appear the Fault code showing as above figure.
  • Page 14 DIAGNOSTICS MODE 2.Fault code definition & Trouble shooting Fault code displayed Freezer Temp Fridge Temp Item Fault code definition Trouble shooting Setting Setting displayed displayed Normal Normal displayed F-sensor break or F-sensor abnormal Check wire of sensors short circuit. RT-sensor break or RT-sensor abnormal Check wire of sensors short circuit.
  • Page 15 DISASEMBLY/ASSEMBLY PART 1.Assembly Assy Evap Lokring Joint Lokring joint Defrost Sensor Assy Evap Defrost heater Thermal Bimetal Heater thermal fuse 2.Compressor compartments Condenser coil Drain hose connect Condenser fan motor Lokring: Al+Cu Lokring: Steel+Steel Steel+Cu Cu+Cu Lokring: Steel+Steel Cu+Cu Cu+Cu Cu+Cu - 15 -...
  • Page 16 DISASEMBLY/ASSEMBLY PART 3.Cover Refrigerator Damper assy R1-Sensor LED wiring 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Door shelves To disassemble the door shelves, knock them upward at both side of bottom lightly by hands; To assemble them, press them downward on bulges of door inner liner. Glass shelves Step 1: Push up the shelves from liner hook.
  • Page 17 DISASEMBLY/ASSEMBLY PART 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Upper cover of Step 4: To pull the cover outward, the cover air channel in will be opened. freezer Step 5: To unlash the LED wire from fan bracket of freezer, pull out the terminal of the LED wire form cabinet.
  • Page 18 DISASEMBLY/ASSEMBLY PART 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Air channel Step 2: To remove 2 pieces of screw (like as complete of picture). cooler Step 3: To remove the component outward from cabinet. Step 4: To remove the component down ward from cabinet.
  • Page 19 DISASEMBLY/ASSEMBLY PART 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Fan complete of Step 3: To take out the fan motor from freezer bracket of fan. Door Gasket Step 1: To remove the gasket from 4 corners of door inner liner at first by hand. Step 2: And then, to remove the gasket from the 4 sides of door inner liner by hand directly.
  • Page 20 DISASEMBLY/ASSEMBLY PART 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Doors Step 4: To press the clip of switch disassemble downward for disconnection fastening of switch. Step 5: To push the switch outward for removing out the switch. Step 6: To remove 3 pieces of screw by Hex- socket;...
  • Page 21 DISASEMBLY/ASSEMBLY PART 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Power cord Step 1: To pull out the terminal of power wire from PCB. Step 2: To remove 2 pieces of screw, and then, the power wire can be taken out. User Interface Step 1: To take a sucker (like as picture) and board...
  • Page 22 DISASEMBLY/ASSEMBLY PART 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Step 5: To press the 2 pieces of clip of dew-water-box to separate it with the bracket of fan by the aid of screwdriver. Step 6: To press the clip of sealing-part for condenser inward from its rear at first , and then ,to pull it outward for separating it with the bracket of fan.
  • Page 23 DISASEMBLY/ASSEMBLY PART 4.Disassembly/Assembly parts Parts name Pictures Disassemble/assemble method Step 3: To lift the evaporator upward slowly , so that to make the evaporator hooks and cabinet separate completely. NOTE: THE STEP SHOULD OPERATE SLOWLY TO AVOID TUBES DAMAGE! Sub-step: To remove the sensor of defrost Step 4: To remove the sensor of defrost like as picture.
  • Page 24 GAS LEAK REPAIR INSTRUCTION 1.Tooling preparation Picture Tool Detail Piercing Pliers For discharge R600A. Tube cutter For cutting pipe. Capillary tube For cutting specific cutter capillary tube. Pinch-off pliers For pinch off the gas system. Tube expander kit For pipe expansion. - 24 -...
  • Page 25 GAS LEAK REPAIR INSTRUCTION 1.Tooling preparation Picture Tool Detail Sandpaper For remove pipe coating and dirtiness. Service pipe For systems vacuum and gas charging. Dryer Copper tube connect For connect with assy evap joint. Welding wire To solder of welding joint.
  • Page 26 GAS LEAK REPAIR INSTRUCTION 1.Tooling preparation Picture Tool Detail Vacuum pump For system vacuum. Mainflod & hose For system vacuum use together with vacuum pump. R600A refrigerant R600A refrigerant for refrigerator system quantity use depend on model see detail at rating label.
  • Page 27 GAS LEAK REPAIR INSTRUCTION 1.Tooling preparation Picture Tool Detail Leak detector For refrigerant leak detection. Steel pate For prevent machine room , bottom and other compartment from burnt during gas welding. - 27 -...
  • Page 28 GAS LEAK REPAIR INSTRUCTION 2.Welding joints Compressor room welding joints 8.Lokring: Al+Cu 3.Lokring: Steel+Steel 4.Steel+Cu 1.Cu+Cu 11.Cu 2.Lokring: Steel+Steel 10.Cu+Cu 9.Cu+Cu 5.Cu+Cu Evap welding joints 6.Lokring: Cu+Al 7.Lokring: Al+Al - 28 -...
  • Page 29 GAS LEAK REPAIR INSTRUCTION 3.Work with R600A Working condition The main disadvantage discussed in connection with R 600a use is the risk based in its flammability. This leads to necessity for very careful handling and safety precautions. Because of the flammability of isobutane in a wide concentration range safety precautions are necessary, on the appliance itself and in the manufacturing factory.
  • Page 30 GAS LEAK REPAIR INSTRUCTION 4.Work instruction (Gas welding) (a)To remove the gas use the piercing pliers and discharge the gas straight from the dryer. (b) Use an extended hose connect to pliers to transfer the gas outside, preferably to an outside location. Ensure there are no gas heaters, fan heaters or pilot lights in the vicinity of the point of discharge.
  • Page 31 GAS LEAK REPAIR INSTRUCTION 4.Work instruction (Gas welding) (g) Evacuate the system from both sides using the vacuum pump for at least 25 minutes. Please ensure to look at the mainflod gauge both gauge pressure must below 0 In.Hg. (h) Charge the R600A refrigerant by use charger including digital refrigerant balance.
  • Page 32 GAS LEAK REPAIR INSTRUCTION 4.Work instruction (Gas welding) (j) Run the machine for gas leak inspection. Gas leak inspection by use leak detector and soap bubble at repair joint. If found gas leak repeat welding process again. Addition part. (k) How to remove coating and dirtiness ? using sandpaper the method see in the (k) figure.
  • Page 33 GAS LEAK REPAIR INSTRUCTION 4.Work instruction (Gas welding) (m) How to pipe expanding ? Use the tube expander select pivot suitable for insert male pipe type by calculate from male pipe type outer diameter .Use the hammer press pivot until pipe expanded. The expanded dimension at lest 15mm.
  • Page 34 GAS LEAK REPAIR INSTRUCTION 4.Work instruction (Gas welding) Joint Work instruction (1) Release R600A gas and please ensure all of gas has been removed before next step. (2) Remove coating and dirtiness at joint both side of compressor tube and discharge pipe by sandpaper.
  • Page 35 GAS LEAK REPAIR INSTRUCTION 4.Work instruction (Gas welding) Joint Work instruction (1) Release R600A gas and ensure that all of gas has been removed before next step. (2) Remove coating and dirtiness at hot pipe side. (3) Cut joint by tube cutter. (4) Replace the new dryer.
  • Page 36 GAS LEAK REPAIR INSTRUCTION 4.Work instruction (Gas welding) Joint Work instruction (1) Release R600A gas and ensure that all of gas has been removed before next step. (2) Remove lokring joint by tube cutter. (3) Use copper pipe connect. (4) Insert assy evap pipe & suction pipe into copper pipe connect.
  • Page 37 GAS LEAK REPAIR INSTRUCTION 5.Lokring Tooling preparation Picture Tool Detail Lokring (See To connect the joint. Lokring spec in tool listed table) Lokprep To solder lokring & pipe. Article name: LOKprep 65G Article no: L14000878 Hand tool To press the lokring at joint. Article name: LOKtool HMRK-V Article no:...
  • Page 38 GAS LEAK REPAIR INSTRUCTION 6.Lokring joints Compressor room Lokring joints 5.Lokring: Al+Cu 2.Lokring: Steel+Steel 1.Lokring: Steel+Steel Evap lokring joints 3.Lokring: Cu+Al 4.Lokring: Al+Al - 38 -...
  • Page 39 GAS LEAK REPAIR INSTRUCTION 7.Lokring Tooling preparation Joint Position Lokring specification Remark specification LOKRING 5 NK Ms 00 Type: MB x See lokring Article No. L13000587 Article No. number at the L20000200 end of the Article name. lokring .Here is LOKtool MB 8 “Lokring 5NK”...
  • Page 40 GAS LEAK REPAIR INSTRUCTION 7.Lokring work instruction (a) Use sandpaper to remove the pipe coating and dirtiness before pipe cutting. The purpose of remove for maintain lokpre efficacy. (b) Use small tube cutter to cut the joint due to limited work space at compressor room. Fix tube cutter to tight and rotate it until pipe separated.
  • Page 41 GAS LEAK REPAIR INSTRUCTION 7.Lokring work instruction (d) Put the lokpre onto both pipe for cover all pipe round. (e) Insert the lokring and turn it around for merge with the lokpre. (f) Arrange pipe with the same alignment to avoid leakage cause form pipe bend when pressing .
  • Page 42 GAS LEAK REPAIR INSTRUCTION 7.Lokring work instruction (g) Use hand assembly tool insert jaw support to lokring both top and bottom then press it until lokring Top side and bottom side are converged as same as the figure (h). (h) The lokring good condition is must be in the figure (h). The lokring joint must be overlab 5 mm from the lokring Both sides and at the center point lokring top &...
  • Page 43 GAS LEAK REPAIR INSTRUCTION 7.Lokring work instruction Joint Work Instruction (1) Remove coating & dirtiness by sand paper. (2) Cut joint by tube cutter. (3) Select the lokring follow the tool listed table. (4) Insert the lokring into both side. (5) Put lokpre onto the both pipe and must cover all pipe side.
  • Page 44 GAS LEAK REPAIR INSTRUCTION 7.Lokring work instruction Joint Work Instruction (1) Remove coating & dirtiness by sand paper. (2) Cut joint by tube cutter. (3) Select the lokring follow the tool listed table. (4) Insert the lokring into both side. (5) Put lokpre onto the both pipe and must cover all pipe side.

  • Page 45: Wiring Diagram

    Wiring Diagram - 45 -...

  • Page 46: Schematic Diagram

    Schematic Diagram - 46 -...
