InTemp CX1000 Series Manual

InTemp® CX1000 Series Temperature Logger Manual
InTemp CX1000 Temperature
Loggers
Models:
• CX1002, single-use cellular
logger
• CX1003, multi-use cellular logger
Included Items:
• Power cord
• Quick Start Guide
• NIST Certificate of Calibration
Required Items:
• InTempConnect Cloud platform
27059-A
1.800.561.8187
The InTemp CX1002 (single use) and CX1003 (multi use) are cellular data loggers that monitor
the location and temperature of your critical, sensitive, in-transit shipments in near real time.
The InTemp CX1002 logger is perfect for one-way shipments; the InTemp CX1003 is ideal for
return logistics applications where the same logger can be used multiple times. Location,
temperature, light, and shock data is transmitted to the InTempConnect cloud platform in near
real time to enable maximum shipment visibility and control. Cellular data usage is included
with the cost of the logger so there are no additional fees for a data plan.
View near real-time temperature data in the InTempConnect dashboard, as well as logger
shipment details, current temperature, any critical alerts, and a near real-time map that shows
the route, current location of your assets, and data upload points – so you can always check on
the status of your shipment and access important data for analysis.
Generate on-demand reports in InTempConnect during or after the conclusion of a shipment so
you can make informed decisions that help prevent product waste and increase supply chain
efficiency.
Receive SMS and email notifications for temperature excursions, low battery alarms, and light
and shock sensor alerts
A 3-Point 17025 accredited calibration certificate, valid for one year from date of purchase,
provides assurance that the data can be trusted when making important product-disposition
decisions.
Note: The InTemp CX1002 and CX1003 are not compatible with the InTemp mobile app or the
CX5000 gateway. You can manage these loggers only with the InTempConnect cloud platform.

Specifications

Recording Options CX1002: Single use
CX1003: Multi use
-20°C to +60°C
Temperature Range
Temperature Accuracy ±0.5°C from -20°C to 60°C;
±0.9°F from -4°F to 140°F
Temperature Resolution ±0.1°C
CX1002 and CX1003: 31,200 readings with memory wrap
Memory
Network Connectivity CAT M1 (4G) with 2G Global Roaming
Location/Accuracy WiFi SSID / Cell-ID 100m
Battery Life 30 days at room temperature with 60 minute data upload intervals. Note:
Off schedule cellular uploads triggered by temp excursions, light, shock,
(Rec Duration)
and low battery events may affect total runtime.
Min. 5 Minutes up to max. 8 hours (Configurable)
Data Recording Interval
Sending Interval Min. 30 Minutes Or More (Configurable)
Record-Delay Interval 30 Minutes Or More (Configurable)
Start-up mode Press the button for 3 seconds.
Stop mode Press the button for 3 Seconds.
Protection Class IP64
Weight 111g
Dimensions 101 mm x 50 mm x 18.8 mm (LxWxD)
Certifications According To EN 12830, CE, BIS, FCC
Report File Output PDF or CSV file downloadable from InTempConnect
Connection Interface 5V DC - USB Type C
Wi-Fi 2.4 GHz
LCD Display Indications Current Temperature Reading in Celsius
Trip Status - REC/END
Temperature Violation Indication (X Icon)
