InTemp® CX500 Series Temperature Logger Manual
(CX501 model shown)
InTemp CX500 Series
Loggers
Models:
• CX501, 15-day logger,
single use
• CX502, 90-day logger,
single use
• CX503, 365-day logger,
multiple use
Required Items:
• InTemp app
• Device with iOS or
Android™ and Bluetooth
19998-H
InTemp CX500 series loggers measure temperature in transportation monitoring applications.
These Bluetooth® Low Energy-enabled loggers are designed for wireless communication with a
mobile device and can be configured to monitor temperatures in Cold Chain, CRT, and Frozen
shipments. CX500 series loggers, the InTemp app, and InTempConnect® web-based software work
together to form the InTemp temperature monitoring solution. Using the InTemp app on your
phone or tablet, you can configure CX series loggers and then download them to share and view
logger reports, which include logged data, excursions, and alarm information. Or, you can use
InTempConnect to configure and download CX series loggers via the CX5000 Gateway. Once
logged data is uploaded to InTempConnect, you can view logger configurations, build custom
reports, monitor trip information, and more. The CX500 series logger is available in a single-use
15- or 90-day model (CX501 and CX502) or a multiple-use 365-day model (CX503).
Specifications
Temperature Sensor
Sensor Range
Accuracy
Resolution
Drift
Logger
Logger Operating Range
Radio Power
Transmission Range
Wireless Data Standard
Type
Duration
Shelf Life
Logging Rate
Time Accuracy
Battery
Memory
Full Memory Download
Time
Dimensions
Weight
Environmental Rating
Passed RTCA DO160G, part 21H
CX501 CX502
-10° to 70°C (14° to -30° to 70°C (-22° to
158°F) 158°F)
±1.0°C from -10° to ±1.0°C from -30° to
-5°C (±1.8°F from -5°C (±1.8°F from
14° to 23°F) -22° to 23°F)
±0.5°C from -5° to ±0.5°C from -5° to
50°C (±0.9°F from 50°C (±0.9°F from
23° to 122°F) 23° to 122°F)
±1.0°C from 50° to ±1.0°C from 50° to
70°C (±1.8°F from 70°C (±1.8°F from
122° to 158°F) 122° to 158°F)
0.04°C (0.072°F)
<0.01°C (0.018°F) per year
-10° to 70°C (-14° to -30° to 70°C (-22° to
158°F) 158°F)
1 mW (0 dBm)
Approximately 30.5 m (100 ft) line-of-sight
Bluetooth Low Energy (Bluetooth Smart)
Single use Single use
15 days 90 days
Up to 1 year
1 second to 18 hours
±1 minute per month at 25°C (77°F)
CR2032 (CX501) or CR2450 (CX502 and CX503) 3V lithium, not
replaceable. Battery for CX501 and CX502 lasts for duration specified
when logger is used within the 1-year shelf life. Battery life for the
CX503 model is 1 year, typical with logging interval of 1 minute. Faster
logging intervals, remaining connected with the InTemp app, excessive
downloads, and paging may impact battery life.
8,800 measurements 14,000 measurements
Approximately 30 seconds; may take longer the farther the device is
from the logger
6.9 x 4.5 x 1.1 cm (2.71 x 1.76 x 0.42 inches)
22.1 g (0.78 oz) 25.5 g (0.90 oz)
IP67
The CE Marking identifies this product as complying with all relevant
directives in the European Union (EU).
See last page
CX503
-30° to 70°C (-22° to
158°F)
±1.0°C from -30° to
-5°C (±1.8°F from
-22° to 23°F)
±0.5°C from -5° to
50°C (±0.9°F from
23° to 122°F)
±1.0°C from 50° to
70°C (±1.8°F from
122° to 158°F)
-30° to 70°C (-22° to
158°F)
Multiple Use
Up to 1 year
14,000 measurements
25.5 g (0.90 oz)
