VIEWEG DC 200 Series User Manual
Liquid dispenser
Hide thumbs
Also See for DC 200 Series:
- Operating instructions manual (22 pages) ,
- Operating manual (12 pages)
Related Manuals for VIEWEG DC 200 Series
Summary of Contents for VIEWEG DC 200 Series
- Page 1 VIEWEG Dosier- und Mischtechnik LIQUID DISPENSER DC 200 series USER MANUAL Made in Germany V2.0EN OCT 2014 © Vieweg GmbH...
-
Page 2: Table Of Contents
VIEWEG USER MANUAL LIQUID DISPENSER DC200 series 1. TABLE OF CONTENTS 1. Table of contents . . 02 2. Designated use . . 03 3. For your safety . . 03 4. Technical data . . 04 4. 1 parts & description . -
Page 3: Designated Use
Use the DC200 controller only to the functions, which are explained in this user manual. VIEWEG GmbH is not responsible for per- sonal or material damages, which happen because of incorrect using and no desig- nated use. -
Page 4: Technical Data
VIEWEG USER MANUAL LIQUID DISPENSER DC200 series 4. TECHNICAL DATA Measurements 235 x 225 x 75mm Weight ca. 1,25 kg Power supply: 85 – 264V AC 50/60Hz Internal voltage 24V DC Air inlet 0 ... 7 bar Air outlet Cartridge = working pressure DC215: 0 ... -
Page 5: Parts & Description
VIEWEG USER MANUAL LIQUID DISPENSER DC200 series 4.1 PARTS & DESCRIPTION [Front side] Setting vacuum Pressure gage for Pressure regulator: suck back air outlet 0 – 7 bar Power LED Air outlet Timer Adjustable ON/OFF Dispense time [Back Side] Connector for foot... -
Page 6: Parts Of Delivery
VIEWEG USER MANUAL LIQUID DISPENSER DC200 series 5. Parts of Delivery: • DC200 Liquid Dispenser • Power Inlet Cable • Tube for Air Inlet • User Manual • Cartridge holder • Accessories (see following list) • Tip assortment - small Qty. Description Part.-no. Reorder Qty. per pkg. Power cable – 230V C-0043 Cartridge holder... -
Page 7: Start And Operation
VIEWEG USER MANUAL LIQUID DISPENSER DC200 series 6. Start & Operation • Connect the power inlet cable to the Power inlet connector on the backside. • Connect the Air Inlet tube from the compressor to the Air Inlet at the backside of the DC200. • Connect the Foot switch (opt.: – C-0040) or the dispense cable of the dispense robot to the foot switch connector in the backside of the DC200. • Switch ON the liquid dispenser. The green POWER-LED lights. The device is now ready for work. • Connect the cartridge to the adapter like following diagram: • Connect the air tube of the cartridge adapter to the air pressure output of the DC200 and adjust the pressure fur the cartridge on the front side with the pres- sure controller. - Page 8 VIEWEG USER MANUAL LIQUID DISPENSER DC200 series • Select MODE on the switch on the front side: Timer OFF: The DC200 dispenses as long as the foot switch is applied. Timer ON: The DC200 dispenses as long as the timer is adjusted. A short apply on the foot switch is enough.
- Page 9 VIEWEG USER MANUAL LIQUID DISPENSER DC200 series Connections After you have done all connections, it should look like follows: COMPRESSED AIR 70-100 PSI DC200 Serie...
-
Page 10: Electrical Connections
VIEWEG USER MANUAL LIQUID DISPENSER DC200 series 7. Electrical Connections 7.1 Foot switch: pins: connection between Pin 1 + 3 starts dispensing Foot switch: The Foot switch input gets activated if the input is set to GND. It is NOT Allowed to input a Voltage. -
Page 11: Declaration Of Conformity
Folgende harmonisierte europäische Normen wurden angewandt: Folgende harmonisierte europäische Normen wurden angewandt: Folgende harmonisierte europäische Normen wurden angewandt: Folgende harmonisierte europäische Normen wurden angewandt: • DIN EN ISO 61000-6-3 Störaussendungen • DIN EN ISO 61000-6-2 Störfestigkeit Kranzberg, 07.07.2011 Till Vieweg, Geschäftsführer... - Page 12 VIEWEG Vieweg GmbH Dosier- und Mischtechnik Gewerbepark 13 85402 Kranzberg Tel. +49 (0) 81 66 / 67 84 - 0 Fax +49 (0) 81 66 / 67 84 - 20 info@dosieren.de www.dosieren.de...
