- Page 1 Signal Converter AW-EX500N Before attempting to connect, operate or adjust this product, please read these instructions completely. Printed in Japan F0404S0 VQTB0001...
- Page 2 CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
-
Page 3: Table Of Contents
Contents Introduction... 4 Precautions for use... 4 Major operating controls and their functions... 6 Connections... 12 $ Analog signal input... 13 $ SDI signal input ... 14 Attaching the rubber feet ... 15 Standard accessories ... 15 Appearance ... 16 Specifications ... -
Page 4: Introduction
Introduction The AW-EX500 signal converter can convert analog composite, analog Y/C, analog component and SDI (complying with SMPTE259M standard, 270Mbps) input signals into analog composite, analog Y/C, analog component and analog RGB signals. However, the analog composite and analog Y/C output signals cannot be used by externally synchronized systems (since color frame synchronization cannot be provided). - Page 5 For this reason, it cannot output normal signals if no signals are supplied. To use this signal converter, therefore, signals must be supplied to it. • The AW-EX500 does not come with a cable compensation circuit for the input signals.
-
Page 6: Major Operating Controls And Their Functions
Major operating controls and their functions <Rear View> VIDEO/RGB/COMPONENT/YC OUT OPTION CARD Y/Y/VIDEO IN R-Y/C DC12V IN AUDIO IN <Side View> RS232C - 6 - > <... - Page 7 1Analog video output connector [VIDEO/RGB/COMPONENT/YC OUT] The analog video signals are output from this D-sub 9-pin connector. The video signal is always output from pin #6. Depending on the position of function setting switch 2 =, RGB, COMPONENT or YC analog video signals are output from pins #3, #4 and #5.
- Page 8 Major operating controls and their functions 4 Audio input connector [AUDIO IN] The audio signals are supplied to this connector. Input signals with a level of –20dBV. This is a stereo mini plug jack. The audio signals of the AW-PB310 can be supplied to it. This connector cannot be used by AW-PB302, AW-PB304, AW-PB307, AW-PB309 or AW-PB504.
- Page 9 < Function setting switch 1 This is used to select the operations of the AW-EX500. Before changing a setting, the power must be turned off. The setting items are shown below. PB302 PB310 PB302 PB310 YR-YB-Y YR-YB-Y ADDITIONAL IF OPTION IF 756mV 525mV 714mV...
- Page 10 RS-232C connector 2 on the rear panel of the signal converter. At the <OPTION IF> setting, the connector is connected to the optional card which has been plugged into the optional card slot.
- Page 11 =Function setting switch 2 This is used to select the operations of the AW-EX500. Before changing a setting, the power must be turned off. The setting items are shown below. —— —— SYNC ON SYNC OFF YR-YB-Y RGB, YR-YB-Y 1: Output signal setting 1 [D-SUB OUT SEL1] <YC/RGB, YR-YB-Y>...
-
Page 12: Connections
Connections • Before proceeding with the connections, turn off the power. • Use the AW-PS505 AC adaptor to supply the power. Use the AW-CA4T1 power cable. • For further details on connecting the devices, refer to the operating instructions accompanying the devices concerned. -
Page 13: Analog Signal Input
$ Analog signal input VIDEO OUT Zoom Lens Camera E600 Convertible Camera AW — for Y/C, Component signal AW-CA50T6 When the AW-E800A, AW-E600, AW-E300A or AW-E300 is used as the camera, the AW-PB302 card must be plugged into the camera in order for the AW-CA50T6 to be used. Optional card* AW-PB302 PB304... -
Page 14: Sdi Signal Input
Connections $ SDI signal input Zoom Lens Camera + SDI Card SDI OUT E600 Convertible Camera AW — Optional card* AW-PB302 PB304 PB307 PB309 PB310 PB504* Microphone* Amplifier DC Power Cable AW-CA4T1 Coaxial cable (BELDEN 8281 or equivalent) Max. 200 m WV-CA9T5 VIDEO/RGB/COMPONENT/YC OUT OPTION CARD... -
Page 15: Attaching The Rubber Feet
Attaching the rubber feet • Adhere the accessory rubber feet to the bottom panel when the AW-EX500 is to be placed on the floor for use. Rubber feet Standard accessories O Rubber feet ... 4 - 15 -... -
Page 16: Appearance
Appearance 5-11/16” 3/8” (145 mm) (10 mm) Dimensions: 3-5/16” (W) ~ 3-3/4” (H) ~ 6-1/8” (D) 84 ~ 96 ~ 155 mm Weight: Approx. 1.98 lbs (0.9 kg) VIDEO/RGB/COMPONENT/YC OUT OPTION CARD Y/Y/VIDEO IN RS232C R-Y/C DC12V IN AUDIO IN 3-5/16”... -
Page 17: Specifications
Specifications Power requirements: 12 V DC Power consumption: 6.85 W indicates safety information. Input DC 12V power input connector 270Mbps SDI (BNC) (SMPTE259M standard-compliant) Only video data supported Analog composite (BNC) 1.0Vp-p (0% setup level) Analog Y/C (BNC) Y: 1.0Vp-p (0% setup level) (BNC) C: 0.286Vp-p Analog component... - Page 18 Specifications Input/output interface: RS-232C Operating temperature: 14°F to 113°F (–10°C to +45°C) Operating humidity: 30 % to 90 % (without condensation) Dimensions (W!H!D): 3-5/16”!3-3/4”!6-1/8” [84!96!155 mm] Weight: Approx. 1.98 lbs (0.9 kg) Switch/control functions: • INPUT SEL1 • INPUT SEL2 •...
- Page 19 - 19 -...
