BEA PANTHER Series Manual

Push plate with integrated 900 mhz or 433 mhz wireless transmitter

Hide thumbs

DESCRIPTION

1. Hex Key

2. Housing Assembly

3. Faceplate

4. Locking Tab

5. Mounting Bracket

6. Battery Enclosure

7. Mounting Keys

8. Mounting Holes

6 INCH ROUND, 900 MHz:

10EMR61-900 - logo & text

10EMR6-900 - text only

10EMR6L-900 - logo only

6 INCH ROUND, 433 MHz:

10EMR61 - logo & text

10EMR6 - text only

10EMR6L - logo only

75.5172.08 PANTHER SERIES 20230420

PANTHER SERIES

Push plate with integrated

900 MHz or 433 MHz wireless

transmitter

(US version)

4.75 INCH ROUND, 900 MHz:

10EMR4751-900 - logo & text

10EMR475-900 - text only

10EMR475L-900 - logo only

4.75 INCH ROUND, 433 MHz:

10EMR4751 - logo & text

10EMR475 - text only

10EMR475L - logo only

4.75 INCH SQUARE, 900 MHz:

10EMS4751-900 - logo & text

10EMS475-900 - text only

10EMS475L-900 - logo only

4.75 INCH SQUARE, 433 MHz:

10EMS4751 - logo & text

10EMS475 - text only

10EMS475L - logo only

Page 1 of 4

Table of Contents

Need help?

Do you have a question about the PANTHER Series and is the answer not in the manual?

Questions and answers

Summary of Contents for BEA PANTHER Series

Page 1 10EMR6 - text only 10EMR475 - text only 10EMS475 - text only 10EMR6L - logo only 10EMR475L - logo only 10EMS475L - logo only 75.5172.08 PANTHER SERIES 20230420 75.5172.08 PANTHER SERIES 20230420 Page 1 of 4 Page 1 of 4...
Page 2 1. For added security, additional screws may be installed through Housing Assembly and Mounting Bracket during Step 2. 2. Ensure spring clips “click” during Faceplate installation. It may be necessary to rotate Faceplate for proper alignment. Page 2 of 4 Page 2 of 4 75.5172.08 PANTHER SERIES 20230420 75.5172.08 PANTHER SERIES 20230420...
Page 3 433 MHz - 75.5092 • 433 MHz EH - 75.5659 900 MHz Panther series must use a 900 MHz receiver and 433 MHz Panther series must use a 433 MHz receiver. BATTERY REPLACEMENT Remove four (4) screws on Battery Enclosure.
Page 4 BEA, Inc. does not guarantee any use of the sensor/device outside of its intended purpose. BEA, Inc. strongly recommends that installation and service technicians be AAADM-certifi ed for pedestrian doors, IDA-certifi ed for doors/ gates, and factory-trained for the type of door/gate system.
