LDPI LEXF Installation, Operation And Maintenance Instructions

LEXF LED EXPLOSION PROOF
1. TO PREVENT THE RISK OF ELECTRICAL SHOCK DEACTIVATE/DISCONNECT
THE POWER SUPPLY BEFORE INSTALLING THE FIXTURE.
2. THE DRIVER IN THIS FIXTURE IS DESIGNED TO OPERATE ON GROUNDED
NEUTRAL SYSTEMS ONLY.
3. THIS FIXTURE SHOULD BE INSTALLED BY QUALIFIED TECHNICIANS IN STRICT
ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND ANY LOCAL
REQUIREMENTS.
Operational Data
1. Operate this fixture at its rated voltage. Do not install
where the marked operating temperature exceeds
the ignition temperature of the hazardous
atmospheres. See fixture label for data.
2. This fixture is intended to be connected to a properly
installed and grounded UL listed junction box.
Note
: 3' wire whip comes out of the top hub
General Wiring Diagram
CAUTION: Turn off electrical power at
fuse or circuit breaker box before
wiring fixture to the power supply.
Connecting panels to the AC source
supply:
All units must be individually connect-
ed to the AC supply.
Black = Line
White = Neutral
Green = Ground
LDPI, Inc. 1-800-854-0021 Web: www.ldpi-inc.com E-mail: sales@ldpi-inc.com
INSTALLATION, OPERATION AND
MAINTENANCE INSTRUCTIONS
LIGHTING FIXTURES
WARNING!
AC INPUT
Housing
Heavy-duty anodized die cast aluminum
Long lasting and durable powder coat finish
Over-voltage, and over-heat protection
Exposed fasteners with quality stainless steel
Excellent anti-corrosive property
BLACK (LINE)
GREEN (GROUND)
Terminal
Block
WHITE (NEUTRAL)
LED Driver
（-） （+）
（LEAD WIRES
TO LED LOAD）
Page: 1
REV: 09.14.20
