Mazda MX-5 Owner's Manual

Mazda MX-5 Owner's Manual

Hide thumbs Also See for MX-5:

Workshop manual (743 pages)

,

Owner's manual (609 pages)

,

Workshop manual supplement (120 pages)

page of 570

/ 570
Bookmarks

Advertisement

Quick Links

Download this manual

Advertisement

Need help?

Need help?

Do you have a question about the MX-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mazda MX-5

Page 3 CAUTION NOTE A NOTE provides information and sometimes suggests how to make better use of your vehicle. WARNING...
Page 7 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫...
Page 8 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪...
Page 9 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩...
Page 10 ▼ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭...
Page 11 ▼ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬...
Page 12 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪...
Page 13 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫...
Page 14 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩...
Page 15 ▼ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬...
Page 16 ▼ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬...
Page 17 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨...
Page 18 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨...
Page 21 WARNING...
Page 23 CAUTION...
Page 24 ▼...
Page 25 WARNING Lock release lever...
Page 29 ▼...
Page 30 ▼ WARNING...
Page 31 High CAUTION WARNING NOTE Use the seat warmer when the engine is running. Leaving the seat warmer on for long periods with the engine not running could cause the battery power to be depleted. If the ignition is switched off while the seat warmer is operating (High, Mid or Low) and then switched ON again, the seat warmer will automatically operate...
Page 32 WARNING...
Page 34 CAUTION Seat belt guide ▼ ▼...
Page 35 ▼ WARNING Seat belt tongue Seat belt buckle Seat belt guide Keep low on Take up slack hip bone Too high Seat belt guide...
Page 36 ▼ Button NOTE If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting properly, have it inspected at an expert repairer (we recommend an Authorised Mazda Repairer).
Page 37 WARNING...
Page 38 NOTE The pretensioner system may not operate depending on the type of the collision. For details, refer to the SRS Air Bag Deployment Criteria (page 2-48). Some smoke (non-toxic gas) will be released when the air bags and pretensioners deploy. This does not indicate a fire.
Page 40 WARNING...
Page 41 (Europe and other countries (Taiwan only) (Except Taiwan))
Page 43 CAUTION NOTE (European models) Your Mazda is equipped with ISOFIX anchors for attachment of ISOFIX child-restraint systems. When using these anchors to secure a child-restraint system, refer to “Using ISOFIX Anchor” (page 2-35).
Page 44 ▼ NOTE When purchasing, ask the manufacturer of the child-restraint system which type of child-restraint system is appropriate for your child and vehicle. NOTE ▼ Installation position is determined by the type of child-restraint system. Always read the manufacturer's instructions and this owner's manual carefully.
Page 45 Due to variations in the design of child-restraint systems, vehicle seats and seat belts, all child-restraint systems may not fit all seating positions. Before purchasing a child-restraint system, it should be tested in the specific vehicle seating position (or positions) where it is intended to be used.
Page 46 ▼ WARNING...
Page 47 ▼ WARNING WARNING...
Page 53 ▼ CAUTION Anchor bracket WARNING NOTE Be careful not to lost the removed cover.
Page 54 ▼ WARNING ▼ CAUTION...
Page 55 CAUTION NOTE The markings above the ISOFIX anchors indicate the locations of the ISOFIX anchors for the attachment of a child-restraint system.
Page 56 WARNING...
Page 58 WARNING...
Page 62 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 65 ▼ ▼ ▼...
Page 66 ▼ ▼...
Page 67 NOTE In a frontal offset collision, the equipped air bags and pretensioners may all deploy depending on the direction, angle, and rate of impact.
Page 68 Frontal offset impact to the vehicle Impacts involving trees or poles Rear-ending or running under a truck's tail gate...
Page 69 Side impacts with two-wheeled vehicles Side impacts involving trees or poles Roll-over...
Page 70 ▼...
Page 71 WARNING...
Page 73 If the passenger air bag deactivation OFF indicator light remains turned on, slide the passenger seat as far back as possible. Consult an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible.
Page 75 Actuator Active bonnet warning light Actuator Sensor Electronic control unit WARNING...
Page 76 CAUTION ▼...
Page 77 ▼...
Page 79 WARNING NOTE The driver must carry the key to ensure the system functions properly. Transmitter Auxiliary key CAUTION...
Page 80 Key code number plate...
Page 81 CAUTION NOTE The keyless entry system operation may vary due to local conditions. The keyless entry system is fully operational (door/boot lid/fuel-filler flap lock/unlock) when the ignition is switched off. The system does not operate if the ignition is switched to any position other than off.
Page 82 Additional keys can be obtained at an The hazard warning lights flash when expert repairer (we recommend an the theft-deterrent system is armed or Authorised Mazda Repairer). Up to 6 turned off. keys can be used with the keyless Refer to Theft-Deterrent System on page functions per vehicle.
Page 83 The volume of the beep sound can also be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. NOTE Use the following procedure to change the The doors and the boot lid, fuel-filler setting.
Page 84 The time required for the doors to lock automatically can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. A door or the boot lid is opened. The ignition is switched to any position other than off.
Page 86 ▼ Interior aerial NOTE Starting the engine may be possible even if the key is outside of the vehicle and extremely close to a door and window, Operational range however, always start the engine from NOTE the driver's seat. The engine may not start if the key is If the vehicle is started and the key is not placed in the following areas: in the vehicle, the vehicle will not restart...
Page 87 Consult an expert repairer (we recommend an Authorised Mazda Repairer) for details. If the advanced keyless entry system has been deactivated, you can start the engine by following the procedure indicated when the key battery goes dead.
Page 88 NOTE The system may not operate if you are too close to the windows or door handles. If the key is left in the following areas and you leave the vehicle, the doors may NOTE be locked depending on the radio wave When the battery power is low, or in conditions even if the key is left in the places where there are high-intensity radio...
Page 89 WARNING CAUTION NOTE Always stop the engine and lock the doors. In addition, to prevent theft of valuables, do not leave them inside the cabin. If the key is left in the following areas and you leave the vehicle, the doors may be locked depending on the radio wave conditions even if the key is left in the vehicle.
Page 90 Around the instrument panel When opening a door, the power In the storage compartments such as windows open a little automatically. the console box When closing the door, the power Next to a communication device such windows close automatically. This is a as a mobile phone function for improving the sealability, The vehicle lock-out prevention feature...
Page 91 ▼ WARNING Centre position Lock position...
Page 92 NOTE ▼ You can also activate the system by pressing the lock button on the transmitter twice within 3 seconds. (With the advanced keyless function) You can also activate the system by pressing the request switch twice within 3 seconds. Request switch NOTE The system cannot be activated when...
Page 93 The volume of the beep sound can also be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. Use the following procedure to change the setting. 1. Switch the ignition off and close both of the doors and the boot lid.
Page 94 The time required for the doors and the Refer to the Settings section in the boot lid, fuel-filler flap to lock Mazda Connect Owner's Manual. automatically can be changed. (Walk-away auto lock function) Refer to the Settings section in the A beep sound is heard when both doors Mazda Connect Owner's Manual.
Page 95 ▼ ▼ WARNING Lock Unlock NOTE The doors and the boot lid, fuel-filler flap cannot be locked while any other door is open.
Page 96 ▼ Door-lock knob Unlocked: Red indicator Lock NOTE When locking the door this way: Be careful not to leave the key inside the Unlock vehicle. The driver's door lock knob cannot be used while the driver's door is open.
Page 97 WARNING ▼ CAUTION NOTE The remote release button cannot be disabled by locking the doors using the door-lock switch/door-lock knob. Refer to Locking, Unlocking with Door-Lock Switch on page 3-18. Refer to Locking, Unlocking with Door-Lock Knob on page 3-19.
Page 98 The boot lid can be closed when the doors are locked with the key left in the vehicle. However, to prevent locking the key in the vehicle, the boot lid can be opened by pressing the electric boot lid opener. If the boot lid cannot be opened despite doing this procedure, first push the boot lid completely closed, then press the electric boot lid opener to fully...
Page 99 ▼ CAUTION...
Page 100 ▼ CAUTION NOTE Infusing the deposit cleaner when the fuel tank is full provides the concentration of cleaner within the range effective for removing the deposits and the best cleaning results can be obtained by the full tank of fuel with the infused deposit cleaner contacting the deposits for a long period of time until the full tank of fuel is nearly used up.
Page 101 ▼ WARNING CAUTION...
Page 102 ▼ WARNING...
Page 103 CAUTION WARNING ▼ NOTE The fuel-filler flap operates in conjunction with the door locking/ unlocking mechanism.
Page 104 Fuel-filler flap Fuel-filler cap NOTE Lock the doors after closing the fuel-filler flap. If the fuel-filler flap is closed after locking the doors, the fuel-filler flap cannot be locked.
Page 105 The perceived distance of objects in the outer and inner regions of the wide angle mirror is different. Objects appearing in the outer region are actually further away than they are in ▼ the inner region. WARNING Centre position NOTE (Driver's Side Wide Angle Mirror Mirror switch The wide angle mirror has two...
Page 106 WARNING NOTE For the manual antidazzle mirror, perform the adjustment with the antidazzle lever in the day position. ▼ WARNING Antidazzle lever Night...
Page 107 Indicator light ON/OFF button NOTE Do not use glass cleaner or suspend objects on or around the light sensor. Otherwise, light sensor sensitivity will be affected and may not operate normally. Light sensor The auto-dimming function is cancelled when the ignition is switched ON and the shift/selector lever is in reverse (R).
Page 108 WARNING...
Page 109 ▼ Master control switches Passenger's window Without door-lock switch switch Unlocked Locked Power window position position lock switch Close Close With door-lock switch Open Open Locked Unlocked position position Passenger's window Driver's window NOTE A power window may no longer open/close if you continue to press the switch after opening/closing the power window.
Page 110 6. Make sure that the power windows ▼ operate correctly using the door switches. After the system has been re-initialized, passenger window can be fully opened automatically using the master control switches. If the automatic power window operation does not operate normally NOTE while the doors or convertible top/ The power window cannot be fully...
Page 111 Top latch assembly Convertible top's handles Convertible top ▼ WARNING...
Page 112 CAUTION NOTE The power windows go down automatically in conjunction with the convertible top opening/closing. However, this is a function for improving the operability, and it does not mean there is a problem. If the vehicle battery is disconnected for vehicle maintenance or other reasons, the power windows will not go down automatically.
Page 113 ▼ CAUTION Anchor Striker NOTE If the power windows do not go down automatically, fully open the windows or open the doors. Front edge Lock release button Top latch...
Page 114 NOTE ▼ To lower the convertible top from inside the vehicle, use the convertible top's handles. Unlock Lever Convertible top's handles Front edge NOTE If the power windows do not go down automatically, fully open the windows or open the doors.
Page 115 Make sure the convertible top is securely locked by pushing up on it. If it still sounds loose (rattles) after being locked by the top latch, have it inspected at an expert repairer (we recommend an Authorised Mazda Repairer).
Page 116 Middle roof Front roof Rear roof ▼ WARNING CAUTION...
Page 117 ▼...
Page 118 NOTE If the operation indicator light flashes quickly, there may be a system malfunction. Consult an expert repairer (we recommend an Authorised Mazda Repairer). ▼...
Page 119 NOTE If the retractable hardtop switch is pressed in the open direction, a warning beep sounds. When pressing the retractable hardtop switch while the windows are closed, the windows open slightly. If the switch is continuously pressed in the open direction until the roof opening operation is completed, the windows return to their original positions.
Page 120 ▼ If the roof cannot be closed even after the operation conditions are all met, have it checked at an expert repairer (we recommend an Authorised Mazda Repairer). The roof can be closed manually as an emergency measure. Refer to When the Roof Cannot be Closed on page 7-58.
Page 121 CAUTION CAUTION...
Page 122 (we recommend an Authorised Signals from a TV or radio station, or Mazda Repairer), and have it checked. If from a transceiver or mobile telephone the engine is shut off while the indicator could interfere with your immobilizer light is flashing, you will not be able to system.
Page 123 Because the electronic codes are reset when the immobilizer system is repaired, the keys are needed. Make sure to bring all the keys to an expert repairer (we recommend an Authorised Mazda Repairer), so that they can be programmed. CAUTION...
Page 124 NOTE Intrusion sensor and The boot lid does not open while the intrusion sensor bezel theft-deterrent system is operating. If the battery goes dead while the theft-deterrent system is armed, the siren/horn will activate and the hazard warning lights will flash when the battery is charged or replaced.
Page 125 ▼ NOTE The theft-deterrent system can also be armed by activating the auto relock function with all the doors, the boot lid and the bonnet closed. Refer to Transmitter on page 3-5. The system will disarm if one of the following operations takes place within 20 seconds after pressing the lock button:...
Page 126 ▼ NOTE To reactivate the intrusion sensor, turn off the armed theft-deterrent system and then rearm it. The intrusion sensor is operational when the theft-deterrent system is armed. To cancel the intrusion sensor, press the intrusion sensor cancel button each time the theft-deterrent system is armed.
Page 127 WARNING...
Page 128 WARNING WARNING NOTE Use snow chains only on the rear wheels.
Page 129 WARNING CAUTION...
Page 130 Do not apply excessive force to a window scraper when removing ice or frozen snow on the mirror glass and windscreen. Never use warm or hot water for removing snow or ice from windows and mirrors as it could result in the glass cracking.
Page 131 ▼ CAUTION NOTE Although Mazda recommends hexagon type steel ring chains, all chains within the installation specifications may be used. NOTE If your vehicle is equipped with the tyre pressure monitoring system, the system may not function correctly when using tyre chains.
Page 132 WARNING CAUTION...
Page 137 ▼ WARNING Indicator light NOTE The engine starts by pressing the push button start while depressing the clutch pedal (manual transmission) or the brake pedal (automatic transmission). To switch the ignition position, press the push button start without depressing the pedal.
Page 138 This does not indicate an abnormality. unable to start the engine by carrying the key. Consult an expert repairer (we recommend an Authorised Mazda Repairer) for details. If the push button start system functions have been deactivated, you can start the engine by following the procedure indicated when the key battery goes dead.
Page 139 After starting a cold engine, the engine speed increases and a whining sound from the engine compartment can be heard. This is for improved exhaust gas purification and does not indicate any KEY indicator light parts defect. (green)/ KEY warning light (red) Indicator light NOTE (Manual transmission)
Page 140 Have your vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. If this occurs, the engine can be force-started. Press and hold the push button start until the engine starts.
Page 141 (we recommend an operation sound of the fuel pump Authorised Mazda Repairer) (page motor from near the fuel tank can be 7-23). heard, however, this does not (Manual transmission vehicle with indicate a malfunction.
Page 142 ▼ CAUTION Indicator light Emblem Push button start...
Page 143 (amber) flashes. In this case, the engine may start, however, have the vehicle checked at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. If the push button start indicator light (green) does not illuminate, perform the operation from the beginning again.
Page 144 If the system detects that the remaining battery power of the key is low when the ignition is switched from ON to ACC or WARNING OFF, the following is indicated. Replace with a new battery before the key becomes unusable. Refer to Key Battery Replacement on page 6-35.
Page 145 NOTE The i-stop indicator light (green) turns on under the following conditions: When engine idling is stopped. The i-stop indicator light (green) turns off when the engine is restarted.
Page 147 NOTE Under the following conditions, a period of time is required to stop engine idling The battery power is depleted for some reasons such as the vehicle has not been driven for a long period. The ambient temperature is high or low. After the battery terminals are disconnected for some reasons such as for battery replacement.
Page 148 Engine does not restart If the following operations are performed while the idling is stopped, the engine will not restart for safety reasons. In such cases, start the engine using the normal method. (European model) The bonnet is opened. The driver's seat belt is unfastened and the driver's door is opened. Engine-stop period is short or time until next engine idle stop is long The ambient temperature is high or low.
Page 149 Battery terminals are disconnected Engine idling may not stop right after the battery terminals are disconnected. In addition, if the battery is replaced, the i-stop functions must be verified. Consult an expert repairer (we recommend an Authorised Mazda Repairer).
Page 150 On vehicles equipped with the centre display, the i-stop operation status is displayed in the fuel monitor control status display. Refer to the Control Status Display in the Mazda Connect Owner's Manual. NOTE A problem in the system may be indicated under the following conditions. Have your vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer).
Page 151 The light continues to remain on even though the i-stop OFF switch has been pressed while the engine is running.
Page 152 ▼ NOTE If the engine is stopped with the i-stop function cancelled, the i-stop function becomes operational when the engine is started the next time.
Page 153 ▼ Release foot from brake pedal Vehicle brake force maintained Engine restarted Acceleration...
Page 154 WARNING NOTE When the vehicle is stopped on a steep grade, the vehicle roll prevention function does not operate because engine idling is not stopped. The brake pedal response may change, sound may occur from the brakes, or the brake pedal could vibrate from the operation of the vehicle roll prevention function.
Page 155 Instrument Cluster Type A (With Multi-information Display) Type B (Without Multi-information Display) Steering Switch ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩...
Page 156 ⑪ NOTE ▼ When the ignition is switched to ACC or off, the odometer or trip meters cannot be displayed, however, pressing the instrument panel illumination knob can ▼ inadvertently switch the trip meters or reset them during an approximate ten-minute period in the following cases: After the ignition is switched to off from After the driver's door is opened.
Page 157 TRIP A. before entering the RED ZONE. Refer to the Fuel Economy Monitor ▼ section in the Mazda Connect Owner's Manual. Only the trip meters record tenths of kilometres (miles). The trip record will be erased when:...
Page 158 NOTE During normal driving, the engine coolant temperature stabilizes at 100 °C (210 °F) or less, and the gauge indicates a range lower than 100 °C (210 °F). If the engine load increases and the engine coolant temperature exceeds 100 °C (210 °F), the gauge indicates the engine coolant temperature.
Page 159 NOTE (With auto-light control) When the ignition is switched ON in the early evening or at dusk, the instrument panel illumination is dimmed for several NOTE seconds until the light sensor detects the When the illumination dimmer is brightness of the surrounding area, cancelled, the instrument cluster cannot however, the dimmer may cancel after be dimmed even if the position lights are...
Page 160 ▼ NOTE When the temperature unit indicated in the outside temperature display is changed, the temperature unit indicated in the engine coolant gauge display changes in conjunction with it. NOTE If the outside temperature is lower than 20 °C ( 4 °F), the beep sound does not operate.
Page 161 The display may not change unless you ▼ add more than approximately 9 L (2.3 US gal, 1.9 Imp gal) of fuel. The distance-to-empty is the approximate remaining distance the vehicle can be driven until all the graduation marks in the fuel gauge (indicating the remaining fuel supply) disappear.
Page 162 NOTE (Vehicles with type B audio) If TRIP A is reset using the trip meter when the function which synchronizes (resets) the fuel economy monitor and the trip meter (TRIP A) is on, the displayed past data is reset. NOTE The vehicle speed alarm display is activated at the same time the beep sound is heard.
Page 164 Multi-information Display INFO switch...
Page 165 Engine Coolant Temperature Gauge, Trip Meter A, Average Fuel Economy, Current Press the INFO switch Fuel Economy, Outside Temperature, Odometer, Fuel Gauge Warning message, Outside Press the INFO switch Temperature, Odometer, Fuel Engine Coolant Gauge Temperature Gauge, Trip Meter B, Average Fuel Economy, Current Press the INFO switch Fuel Economy, Outside...
Page 166 ▼ INFO switch Trip meter A, Odometer Press the INFO switch NOTE Only the trip meters record tenths of Trip meter B, kilometres (miles). Odometer The trip record will be erased when: The power supply is interrupted (blown fuse or the battery is disconnected).
Page 167 After refuelling, it may require some Refer to the Settings section in the time for the indicator to stabilize. In Mazda Connect Owner's Manual. addition, the indicator may deviate while driving on a slope or curve since the fuel moves in the tank.
Page 168 The display indicating a quarter or less NOTE When the temperature unit indicated in the remaining fuel has more segments to outside temperature display is changed, show the remaining fuel level in greater the temperature unit indicated in the detail. engine coolant gauge display changes in The direction of the arrow ( ) indicates conjunction with it.
Page 169 The display will not change unless you ▼ add more than approximately 9 L (2.3 US gal, 1.9 Imp gal) of fuel. The distance-to-empty is the approximate remaining distance the vehicle can be driven until all the graduation marks in the fuel gauge indicating the remaining fuel supply disappear.
Page 170 ▼ NOTE The vehicle speed alarm display is activated at the same time the beep sound is heard. The set vehicle speed flashes several times. NOTE If any of the INFO switch is pressed while a message is displayed, it will no longer be displayed the next time the ignition is switched ON.
Page 171 ▼ ▼ ▼ ▼ ▼...
Page 172 Instrument Cluster Type B Type A (With Multi-information Display) (Without Multi-information Display) Centre of Instrument panel Warning/Indicator lights will appear in any of the highlighted areas ▼...
Page 175 ▼...
Page 178 ▼ ▼...
Page 179 WARNING Neutral position CAUTION...
Page 180 NOTE Refer to Parking Sensor System on page 4-165. A natural driving posture can be realized by lightly gripping the shift ▼ lever from the side without having to rest your elbow on the centre console box. If shifting to R is difficult, shift back into Selected gear position Suitable gear position neutral, release the clutch pedal, and try again.
Page 181 NOTE The GSI turns off when the following operations are performed. The vehicle is stopped. The vehicle is put in neutral. The vehicle is driven in reverse. The clutch is not fully engaged when accelerating from a stop. The clutch pedal remains depressed for 2 seconds or longer while driving.
Page 182 Lock-release button Various Lockouts: Indicates that you must depress the brake pedal and hold in the lock-release button to shift (The ignition must be switched ON). Indicates the selector lever can be shifted freely into any position. Indicates that you must hold in the lock-release button to shift. NOTE The Sport AT has an option that is not included in the traditional automatic transmission that gives the driver the option of selecting each gear instead of leaving it to the...
Page 183 Lock-release button NOTE When the ignition is switched to ACC or the ignition is switched off, the selector lever cannot be shifted from P position. button The ignition cannot be switched to OFF if the selector lever is not in P position. ▼...
Page 184 NOTE (With parking sensor system) When the selector lever is shifted to the R position with the ignition switched ON, the parking sensor system is activated and a beep sound is heard. Refer to Parking Sensor System on page 4-165. WARNING WARNING CAUTION...
Page 185 NOTE ▼ Apply the parking brake or depress the brake pedal before moving the selector lever from N position to prevent the vehicle from moving unexpectedly. ▼ NOTE If one of the following actions is performed, the selector position is displayed for 5 minutes even if the ignition switch is in a position other than ON.
Page 186 Manual shift mode indication Gear position indication NOTE If the gears cannot be shifted down when driving at higher speeds, the gear position indication will flash twice to signal that the gears cannot be shifted NOTE down (to protect the transmission). Changing to manual shift mode while ▼...
Page 187 CAUTION UP switch (+/OFF) NOTE WARNING The GSI turns off when the following operations are performed. The vehicle is stopped. Manual shift mode is cancelled. ▼ NOTE When driving slowly, the gears may not shift up. Do not drive the vehicle with the tachometer needle in the RED ZONE while in manual shift mode.
Page 188 This function is cancelled while the DSC is turned off. However, if the vehicle is continuously driven at a high rpm, the gears may automatically shift up to protect the engine. The steering shift switch can be used temporarily even if the selector lever is in the D position while driving.
Page 189 NOTE ▼ When driving at high speeds, the gear may not shift down. During deceleration, the gear may automatically shift down depending on vehicle speed. When depressing the accelerator fully, the transmission will shift to a lower gear, depending on vehicle speed. However, the gears do not kickdown while the DSC is turned off.
Page 190 ▼ NOTE The gear also shifts down using kickdown while in the second gear fixed mode. NOTE If the vehicle comes to a stop while in the second gear fixed mode, the gear remains in second.
Page 191 NOTE Shifting up and down while in direct mode may not be possible depending on the vehicle speed. In addition, because direct mode is cancelled (released) depending on the rate of acceleration or if the accelerator is fully depressed, use of the manual shift mode is recommended if you need to drive the vehicle in a particular gear for long periods.
Page 192 WARNING NOTE The accelerator pedal may initially feel heavy as it is being depressed, then feel lighter as it is depressed further. This change in pedal force aids the engine control system in determining how much the accelerator pedal has been depressed for performing kickdown, and functions to control whether or not kickdown should be performed.
Page 193 ▼ NOTE To prevent discharging the battery, do not leave the lights on while the engine is off unless safety requires them. Headlights do not blind drivers approaching in the opposite direction no matter what side of the road you must drive your vehicle (left-hand or right-hand traffic). Therefore, it is not necessary to adjust the optical axis of the headlights when switching temporarily to driving on the opposite side of the road (left-hand or right-hand traffic).
Page 196 In this case, the lights turn off if the light switch is turned to the OFF position. The sensitivity of the auto-light control may be changed. Refer to Settings section in the Mazda Connect Owner's Manual.
Page 197 ▼ ▼ High beam Low beam Headlight flashing...
Page 198 Operation of the leaving home light can Refer to the Settings section in the be turned on or off. Mazda Connect Owner's Manual. Refer to the Settings section in the If no operations are done for 3 minutes Mazda Connect Owner's Manual.
Page 199 ▼ ▼ Fog light switch NOTE (Except countries prohibited by law) The running lights can be deactivated. Refer to Settings section in the Mazda Connect Owner's Manual.
Page 200 NOTE (With auto-light control) When the headlight switch is in the AUTO ▼ position and the headlights, exterior lights and instrument panel illuminated, the rear fog light turns on when the rear fog light switch is turned on. Right turn Right lane change Left lane change Left turn...
Page 201 Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ ▼ NOTE The three-flash turn signal function can be switched to operable/inoperable using the personalisation function. CAUTION Refer to the Settings section in the Mazda Connect Owner's Manual.
Page 202 If the wipers do not operate even though the wiper switch is turned to a position other than OFF, consult an expert repairer (we recommend an Authorised Mazda Repairer) as soon as INT ring possible. ▼...
Page 203 CAUTION Less sensitivity Switch Centre position Higher sensitivity...
Page 204 Switching the auto-wiper lever from the Refer to the Settings section in the OFF to the AUTO position while driving Mazda Connect Owner's Manual. activates the windscreen wipers once, after which they operate according to ▼ the rainfall amount.
Page 205 Washer NOTE When the windscreen washer is operated for the first time after turning on the headlights, the headlight washers Indicator light operate automatically. If air enters the headlight washer fluid pipe under conditions such as when the vehicle is brand-new or after an empty washer tank is replenished with washer fluid, washer fluid will not spray even when the wiper lever is operated.
Page 206 ▼ Indicator light Indicator light CAUTION Indicator light NOTE This defogger is not designed for melting snow. If there is an accumulation of snow on the rear window, remove it before using the defogger.
Page 207 NOTE The direction indicators do not work when the hazard warning lights are on. Check local regulations about the use of hazard warning lights while the vehicle is being towed to verify that it is not in violation of the law.
Page 208 If the brake pedal is depressed while driving on slippery roads, the emergency stop signal system could operate causing all the turn and lane change signals to flash. Refer to Emergency Stop Signal System on page 4-79. While the emergency stop signal system is operating, all the direction indicators automatically flash rapidly to caution the driver of a vehicle following behind...
Page 209 ▼ CAUTION WARNING...
Page 210 ▼ Button CAUTION NOTE For parking in snow, refer to Winter Driving (page 3-53) regarding parking brake use. ▼...
Page 211 ▼ ▼ NOTE When the brake pedal is depressed hard or depressed more quickly, the pedal will feel softer but the brakes will apply more firmly. This is a normal effect of the brake assist operation and does not indicate a malfunction. When the brake pedal is depressed hard or depressed more quickly, a motor/ WARNING...
Page 212 NOTE Flashing When you bring your vehicle to a complete stop while all the direction indicator lights are flashing rapidly, the rapid flashing of all the direction indicator lights changes back to the normal flashing pattern. When the hazard warning light switch is pressed, all of the direction indicator lights turn off.
Page 213 HLA does not operate while the TCS/DSC indicator light is illuminated. Contact an expert repairer (we recommend an Authorised Mazda Repairer) and Have Vehicle Inspected on page 7-33. HLA does not turn off even if the DSC OFF switch is pressed to turn off the TCS/DSC.
Page 214 NOTE Braking distances may be longer on loose surfaces (snow or gravel, for example) which usually have a hard foundation. A vehicle with a normal braking system may require less distance to stop under these conditions because the tyres will build up a wedge of surface layer when the wheels skid.
Page 215 NOTE To turn off the TCS, press the DSC OFF switch (page 4-84). ▼ WARNING NOTE In addition to the indicator light flashing, a slight labouring sound will come from the engine. This indicates that the TCS/DSC is operating properly. On slippery surfaces, such as fresh snow, it will be impossible to achieve high rpm when the TCS is on.
Page 216 CAUTION ▼ WARNING...
Page 217 ▼ NOTE When DSC is on and you attempt to free the vehicle when it is stuck, or drive it out of freshly fallen snow, the TCS (part of the DSC system) will activate. Depressing the accelerator will not increase engine power and freeing the vehicle may be difficult.
Page 218 DC-DC converter Variable voltage alternator Capacitor CAUTION...
Page 219 ▼...
Page 220 CAUTION NOTE When sport mode is selected, driving at higher engine speeds may increase fuel consumption. Mazda recommends that you cancel sport mode for normal driving. Drive mode cannot be switched in the following conditions: ABS/TCS/DSC is operating Cruise control is operating.
Page 221 ▼ NOTE If the drive selection cannot be switched to sport mode, the select mode indication flashes to notify the driver.
Page 222 CAUTION...
Page 223 ▼...
Page 224 ▼ ▼...
Page 226 (left-hand or right-hand traffic). The Adaptive Front Lighting System (AFS) function can be switched to operable/ inoperable using the personalisation function. Refer to the Settings section in the Mazda Connect Owner's Manual.
Page 227 CAUTION NOTE The headlight high-beam indicator light turns on while the high beams are on.
Page 228 The system can be changed so that the passenger seats are occupied. ALH do not operate. When visibility is reduced due to a Refer to the Settings section in the Mazda vehicle ahead spraying water from its Connect Owner's Manual. tyres onto your windscreen.
Page 229 ▼...
Page 230 Forward Sensing Camera (FSC) WARNING...
Page 231 CAUTION NOTE If your vehicle deviates from its traffic lane, the LDWS operates (warning sound and indicator light). Steer the vehicle adequately to drive the vehicle to the centre of the lane. When the direction indicator lever is operated for a lane change, the LDWS warning is automatically cancelled.
Page 232 A misleading line is picked up on the road such as a temporary line for construction, or because of shade, lingering snow, or grooves filled with water. The surrounding brightness suddenly changes such as when entering or exiting a tunnel. The illumination of the headlights is weakened because of dirt or the optical axis is deviated.
Page 233 LDWS warning may operate if the Refer to the Settings section in the vehicle is close to a white or yellow line. Mazda Connect Owner's Manual. ▼ NOTE When the ignition is switched OFF, the system status before it was turned off is maintained.
Page 234 The volume of the LDWS warning sound can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. The type of warning sound (rumble beep) on the LDWS can be changed. Refer to the Settings section in the...
Page 235 Your vehicle Detection areas WARNING NOTE The BSM will operate when all of the following conditions are met: The ignition is switched ON.
Page 236 If the BSM OFF indicator light remains illuminated, have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. Some problem with the system including the BSM warning lights is detected.
Page 237 If the road width is extremely narrow, vehicles two lanes over may be detected. The detection area of the radar sensors (rear) is set according to the road width of expressways. The BSM warning lights may turn on in reaction to stationary objects on the road or the roadside such as guardrails, tunnels, sidewalls, and parked vehicles.
Page 239 ▼ NOTE When the ignition is switched OFF, the system status before it was turned off is maintained. For example, if the ignition is switched OFF while the BSM and Rear Cross Traffic Alert (RCTA) systems are operational, the BSM and Rear Cross Traffic Alert (RCTA) systems remain operational the next time the ignition is switched ON.
Page 240 (we recommend an Authorised Mazda Repairer). The TSR operates only if the navigation system SD card (Mazda genuine) is inserted in the SD card slot. Consult an expert repairer (we recommend an Authorised Mazda Repairer) for details.
Page 241 WARNING NOTE The TSR does not operate if there is a malfunction in the Forward Sensing Camera (FSC). Under the following conditions, the TSR may not operate normally. An object placed on the instrument panel is reflected in the windscreen and picked up by the camera.
Page 242 There is an object similar to the traffic sign being read (such as another traffic sign or other signs resembling it). The TSR can be set to inoperable. Refer to Settings section in the Mazda Connect Owner's Manual. ▼ Speed limit signs...
Page 243 NOTE Speed limit signs (including auxiliary signs) When the vehicle speed is about 1 km/h (0.6 mph) or faster, the speed limit sign is displayed when any one of the following conditions are met. The Forward Sensing Camera (FSC) recognises a speed limit sign as a sign targeted for your vehicle and the vehicle passes it.
Page 244 Passing prohibited sign A passing prohibited sign is displayed when all of the following conditions are met. The vehicle speed is about 1 km/h (0.6 mph) or more. The Forward Sensing Camera (FSC) recognises a passing prohibited sign as a sign targeted for your vehicle and the vehicle passes it.
Page 245 NOTE In the following cases, the excessive speed warning stops operating. The vehicle speed is less than the speed of the displayed speed limit sign. (If the activation timing for the excessive speed warning is changed in the personalisation features, the excessive speed warning stops operating when the vehicle speed is less than the changed vehicle speed.
Page 246 WARNING...
Page 247 NOTE The DAA operates when all of the following conditions are met. The vehicle speed is about 65 to 140 km/h (40 to 87 mph). The system detects white (yellow) lane lines. The system has completed learning of the driver’s driving data. The DAA does not operate under the following conditions.
Page 248 Your vehicle Detection areas...
Page 249 If the Blind Spot Monitoring (BSM) OFF Indicator Light remains illuminated, have the vehicle inspected at an expert repairer (we recommend an Authorised Mazda Repairer) as soon as possible. Some problem with the system including the Blind Spot Monitoring (BSM) warning indicator lights has occurred.
Page 250 The battery voltage has decreased. Under the following conditions, the radar sensors (rear) cannot detect target objects or it may be difficult to detect them. The vehicle speed when reversing is about 10 km/h (6.3 mph) or faster. The radar sensor (rear) detection area is obstructed by a nearby wall or parked vehicle. (Reverse the vehicle to a position where the radar sensor detection area is no longer obstructed.) Your vehicle...
Page 251 WARNING Instrument Cluster Type A (With Multi-information Display) Instrument Cluster Type B (Without Multi-information Display) MODE switch RESUME/+ switch SET/- switch OFF/CANCEL switch...
Page 252 ▼ ▼ Instrument Cluster Type A Instrument Cluster Type B (With Multi-information Display) (Without Multi-information Display)
Page 253 Instrument Cluster Type A Instrument Cluster Type B (With Multi-information Display) (Without Multi-information Display) Instrument Cluster Type A Instrument Cluster Type B (With Multi-information Display) (Without Multi-information Display) ▼...
Page 254 Instrument Cluster Type A Instrument Cluster Type B (With Multi-information Display) (Without Multi-information Display) CAUTION NOTE When the system is temporarily cancelled by depressing the accelerator pedal fully, the ASL display shows the cancel display. If the vehicle speed exceeds the set speed by about 3 km/h (2 mph) or more while the cancel display is displayed, the set speed display flashes but the warning sound is not operated.
Page 255 NOTE When the MODE switch is pressed during ASL operation, the system switches to the cruise control. NOTE When the MODE switch is pressed during ASL operation, the system switches to the cruise control.
Page 256 ▼ WARNING NOTE When the vehicle set speed is displayed in the instrument cluster, press the RESUME/ switch to set the displayed vehicle speed. The system is temporarily cancelled when the vehicle is accelerated by depressing the accelerator pedal strongly, however, it resumes when the vehicle speed decreases to the set speed or less.
Page 257 ▼ NOTE The set speed can be set by pressing the SET switch while the system is in stand-by status. The ASL is not cancelled by depressing the brake pedal.
Page 258 Forward Sensing Camera (FSC) WARNING...
Page 259 CAUTION NOTE The Advanced SCBS system will operate under the following conditions. The engine is running. The Smart City Brake Support (SCBS) warning light/warning indication (amber) does not illuminate. (Object is vehicle ahead) The vehicle speed is between about 4 to 80 km/h (2 to 50 mph). (Object is a pedestrian) The vehicle speed is between about 10 to 80 km/h (6.2 to 50 mph).
Page 260 1 time after about 2 seconds and the Advanced SCBS brake is automatically released. ▼ ▼ NOTE The operation distance and volume of the collision warning can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼...
Page 262 Forward Sensing Camera (FSC) WARNING...
Page 263 CAUTION NOTE The SCBS F system will operate under the following conditions. The engine is running. The Smart City Brake Support (SCBS) system warning indication/warning light (amber) does not illuminate. (Rear-end collision warning) The vehicle speed is about 4 to 80 km/h (2 to 50 mph). (Brake control (Smart City Brake Support (SCBS) brake)) The vehicle speed is about 4 to 30 km/h (2 to 18 mph).
Page 264 2 seconds and the SCBS F brake is automatically released. ▼ ▼ NOTE The operation distance and volume of the collision warning can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼...
Page 266 Ultrasonic sensor (rear) Reverse WARNING...
Page 267 CAUTION NOTE The vehicle posture changes depending on the accelerator pedal, brake pedal and steering wheel operations, which could make it difficult for the system to recognise an obstruction, or it could facilitate unnecessary detection. In such cases, the SCBS R may or may not operate.
Page 268 The height of the obstruction is low such as low walls or trucks with low loading platforms. The height of the obstruction is high such as trucks with high loading platforms. The obstruction is small. The obstruction is thin such as a signpost. The obstruction is positioned away from the centre of the vehicle.
Page 269 When the system operates, the user is notified by the multi-information display. The Smart City Brake Support (SCBS) warning indication (amber) turns on when the system has a malfunction. Refer to Warning Indication/Warning Lights on page 4-39. ▼ ▼ ▼ NOTE The collision warning beep sounds intermittently while the Smart City...
Page 271 Forward Sensing Camera (FSC) WARNING CAUTION...
Page 273 NOTE In the following cases, the Forward Sensing Camera (FSC) cannot detect target objects correctly, and each system may be unable to operate normally. The height of the vehicle ahead is low. You drive your vehicle at the same speed as the vehicle ahead. Headlights are not turned on during the night or when going through a tunnel.
Page 274 Exhaust gas from the vehicle in front, sand, snow, and water vapour rising from manholes and grating, and water splashed into the air. When towing a malfunctioning vehicle. The vehicle is driven with tyres having significantly different wear. The vehicle is driven on down slopes or bumpy roads. There are water puddles on the road.
Page 275 If there are recognizable cracks or damage caused by flying gravel or debris on the windscreen, always have the windscreen replaced. Consult an expert repairer (we recommend an Authorised Mazda Repairer) for replacement. (With Advanced Smart City Brake Support (Advanced SCBS))
Page 276 Radar sensors (rear) CAUTION NOTE The detection ability of the radar sensors (rear) has limitations. In the following cases, the detection ability may lower and the system may not operate normally. The rear bumper near the radar sensors (rear) has become deformed. Snow, ice or mud adheres to the radar sensors (rear) on the rear bumper.
Page 277 For repairs or replacement of the radar sensors (rear), or bumper repairs, paintwork, and replacement near the radar sensors, consult an expert repairer (we recommend an Authorised Mazda Repairer). Turn off the system while pulling a trailer or while an accessory such as a bicycle carrier is installed to the rear of the vehicle.
Page 278 Rear sensor...
Page 279 WARNING ▼ With Adjustable Speed Without Adjustable Speed Limiter (ASL) Limiter (ASL) MODE switch ON switch RESUME/+ switch RESUME/+ switch SET/- switch SET/- switch OFF/CANCEL OFF/CANCEL switch switch...
Page 280 ▼ ▼ WARNING NOTE When the ignition is switched off, the system status before it was turned off is maintained. For example, if the ignition is switched off while the cruise control is operating, the system will be operable when the ignition is switched ON the next time.
Page 281 ▼ NOTE When the MODE switch is pressed during cruise control system operation, the system switches to the Adjustable Speed Limiter (ASL).
Page 282 NOTE The cruise control speed setting cannot be performed under the following conditions: Type A Instrument Cluster (Automatic transmission) The selector lever is in the P or N position. (Manual transmission) The shift lever is in the neutral position. The parking brake is applied. Type B Instrument Cluster (Vehicles with Adjustable Speed European model...
Page 283 ▼ NOTE ▼ Accelerate if you want to speed up temporarily when the cruise control is on. Greater speed will not interfere with or change the set speed. Take your foot off the accelerator to return to the set speed. ▼...
Page 284 When the cruise control system is temporarily cancelled by even one of the applicable cancel conditions, the speed cannot be re-set. (Automatic transmission) The cruise control cannot be cancelled while driving in manual mode (selector lever shifted from D to M position). Therefore, engine braking will not be applied even if the transmission is shifted down to a lower gear.
Page 285 Tyre pressure sensors NOTE When the ambient temperature is low due to seasonal changes, tyre temperatures are also lower. When the tyre temperature decreases, the air pressure decreases as well. The TPMS warning light may illuminate more frequently. Visually inspect the tyres daily before driving, and check tyre pressures monthly with a tyre pressure gauge.
Page 286 CAUTION...
Page 287 The signal code must be registered with the TPMS before it can work. The easiest way to do it is to have an expert repairer (we recommend an Authorised Mazda Repairer), change your tyre and complete ID signal code registration.
Page 288 ID signal code, consult an expert minutes, after which the sensor ID signal repairer (we recommend an Authorised code will register upon driving the vehicle Mazda Repairer). for 10 minutes. When reinstalling a previously removed tyre pressure sensor to a wheel, replace...
Page 289 If the camera temperature changes rapidly (Hot to cold, cold to hot), the rear view monitor may not operate correctly. When replacing the tyres, consult an expert repairer (we recommend an Authorised Mazda Repairer). Replacing the tyres could result in deviation of the guide lines which appear on the display.
Page 290 If the vehicle's front, side, or rear has been involved in a collision, the alignment of the rear view parking camera (location, installation angle) may have deviated. Always consult an expert repairer (we recommend an Authorised Mazda Repairer) to have the vehicle inspected.
Page 291 ▼ (Screen display) Obstruction detection indication in parking sensor system Bumper (Actual view) Object NOTE The displayable range varies depending on the vehicle and road conditions. The displayable range is limited. Objects under the bumper or around the bumper ends cannot be displayed.
Page 292 ▼ CAUTION...
Page 293 ▼ NOTE Images displayed on the monitor from the rear view parking camera are reversed images (mirror images). (Display condition) (Vehicle condition)
Page 294 (Display condition) (Vehicle condition) NOTE If the parking space has division lines, straighten the wheels when the vehicle width guide lines are parallel to them. Because there may be a difference between the displayed image, such as indicated below, and the actual conditions when parking, always verify the safety at the rear of the vehicle and the surrounding area directly with your eyes.
Page 295 When parking in a space with a division line on only one side of the parking space, the division line and the vehicle width guide line appear aligned in the monitor, but they may not actually be aligned on the ground. ▼...
Page 296 Appears Appears closer than farther than actual actual distance distance Object on screen Object at actual position Object on screen A: Distance between the vehicle and object displayed on the screen. Object at actual B: Actual distance between the vehicle and object. position (Screen display) (Actual condition)
Page 297 ▼ WARNING...
Page 298 Rear sensor Rear corner sensor WARNING NOTE Do not install any accessories within the detection ranges of the sensors. It may affect the system operation. Depending on the type of obstruction and the surrounding conditions, the detection range of a sensor may narrow, or the sensors may not be able to detect obstructions. The system may not operate normally under the following conditions: Mud, ice, or snow is adhering to the sensor area (Returns to normal operation when removed).
Page 299 Small, short objects Always have the system inspected at an expert repairer (we recommend an Authorised Mazda Repairer) if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions.
Page 300 B: About 150 cm (About 59.0 in) Rear sensor detection range ▼ ▼ Left corner Right corner sensor gauge sensor gauge Rear sensor gauge NOTE The detection indicator can switch between display and non-display. Refer to the Mazda Connect Owner's Manual.
Page 302 ▼...
Page 303 NOTE If an obstruction is detected in a zone for 6 seconds or more, the beep sound is stopped (except for the close-distance zone). If the same obstruction is detected in another zone, the corresponding beep sound is heard. ▼...
Page 305 Label...
Page 306 ▼ NOTE Knob When using the air conditioner under humid ambient temperature conditions, the system may blow fog from the vents. This is not a sign of trouble but a result Close Open of humid air being suddenly cooled. Knob NOTE The air vents can be fully opened and closed by operating the knob.
Page 307 ▼ Instrument panel Vents Defroster and Floor Vents Instrument panel and Floor Vents Defroster Vents Floor Vents NOTE The location airflow exits the air vents and the airflow amount may change depending on the open or close status of the air vents.
Page 308 Type A Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch Type B Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch...
Page 309 ▼ NOTE (Type A) When the mode is set to , or a NOTE position in between them with the fan The air conditioner may not function when control dial in a position other than 0 and the outside temperature approaches 0 °C the temperature control dial in the (32 °F).
Page 310 ▼ WARNING CAUTION ▼ NOTE When maximum cooling is desired, set NOTE the temperature control dial to the If the windscreen fogs up easily, set the extreme cold position and set the air mode selector dial to the position. intake selector to the recirculated air If cooler air is desired at face level, set position, then turn the fan control dial the mode selector dial at the...
Page 311 The air to the floor is warmer than air NOTE to the face (except when the temperature For maximum defrosting, turn on the air control dial is set at the extreme hot or conditioner, set the temperature control cold position). dial to the extreme hot position, and turn the fan control dial fully clockwise.
Page 312 Type A Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch Type B Temperature control dial Fan control dial Mode selector dial A/C switch Air intake selector switch Rear window defogger switch...
Page 313 NOTE ▼ With the airflow mode set to the position and the temperature control dial set at a medium temperature, heated air is directed to the feet and air at a comparably lower temperature will flow through the central, left and right vents.
Page 314 NOTE Setting the temperature to maximum hot or cold will not provide the desired temperature at a faster rate. WARNING When selecting heat, the system will restrict airflow until it has warmed to prevent cold air from blowing out of the vents.
Page 315 ▼ Sunlight sensor Interior temperature sensor...
Page 316 ▼...
Page 317 WARNING...
Page 318 CAUTION NOTE Do not use Mazda Connect for a long time with the engine stopped. Otherwise, the battery power could be depleted. If a mobile phone or CB radio is used in or near the vehicle, it could cause noise to occur...
Page 319 ▼ NOTE The explanation of functions described in this manual may differ from the actual operation, and the shapes of screens and buttons and the letters and characters displayed may also differ from the actual appearance. Additionally, depending on future software updates, the content may successively change without notice.
Page 321 ▼ NOTE For safety reasons, some operations are disabled while the vehicle is being driven. Volume dial...
Page 322 NOTE Long-press operation of the commander knob is also possible for some functions.
Page 323 ▼...
Page 325 ▼ Talk button Hang-up button...
Page 327 NOTE Some commands cannot be used depending on the vehicle specifications. Some commands cannot be used depending on the device connection conditions and the use conditions. The commands indicated in this manual are some examples of usable voice commands. Some commands cannot be used depending on the vehicle specifications.
Page 328 ▼...
Page 329 NOTE ® Gracenote can be downloaded from the Mazda Hands-free Website.
Page 330 CAUTION NOTE ® Apple CarPlay is provided by Apple and its use is subject to your agreement to the Apple CarPlay terms of use, which are included as part of the Apple iOS terms of use.
Page 331 When using Apple CarPlay, location, speed, and other vehicle data is transferred to your ® ® iPhone . For further details, refer to Apple ’s Privacy Policy. CAUTION...
Page 332 NOTE Android Auto™ is provided by Google and its use is subject to your agreement to the Android Auto™ terms of use. When using Android Auto™, location, speed, and other vehicle data is transferred to your smart phone. For further details, refer to Google’s Privacy Policy.
Page 334 NOTE Do not leave the lights on for long periods while the engine is turned off. Otherwise the battery power could be depleted. ▼...
Page 335 If an interior light is left on with the CAUTION ignition switched OFF, the light is turned off automatically after about 30 minutes to prevent battery depletion. The operation of the illuminated entry system can be changed. Refer to the Settings section in the Mazda Connect Owner's Manual.
Page 336 NOTE To prevent discharging of the battery, do not use the socket for long periods with the engine off or idling.
Page 337 WARNING CAUTION Rear cup holder Front cup holder Some models.
Page 338 Rear cup holder Front cup holder Some models. Left-hand drive model Right-hand drive model CAUTION...
Page 339 NOTE The front cup holder can be removed and installed to the rear console.
Page 340 Left-hand drive model Right-hand drive model The rear cup holder is designed for use on the rear console and cannot be installed to the front side.
Page 341 Left-hand drive model Right-hand drive model...
Page 342 ▼ WARNING ▼ CAUTION CAUTION...
Page 343 ▼ Unlock Lock...
Page 344 WARNING CAUTION CAUTION...
Page 345 Windblocker Windblocker...
Page 347 Malfunction diagnosis connector...
Page 348 NOTE After the prescribed period, continue to follow the described maintenance at the recommended intervals.
Page 349 ▼...
Page 350 ▼...
Page 353 ▼...
Page 355 ▼...
Page 357 ▼...
Page 360 ▼...
Page 362 WARNING...
Page 364 WARNING Release handle ▼ WARNING Lever...
Page 365 ▼ Support rod Clip Clip CAUTION...
Page 366 Brake/Clutch fluid reservoir Windscreen washer fluid reservoir Engine oil dipstick Engine oil-filler cap Cooling system cap Battery Fuse block Engine coolant reservoir...
Page 367 Temperature Range SAE Viscosity Numbers –40 –30 –20 –10 Grade –20 –40 Recommended oils Mazda Original Oil Supra-X 0W-20 Mazda Original Oil Ultra 5W-30 Alternative Oil Quality 0W-20 API SN or higher, or ACEA A5/B5 5W-30 Except Europe and Taiwan Temperature Range SAE Viscosity Numbers –40...
Page 368 CAUTION NOTE It is normal for all engines to consume engine oil under normal driving conditions. Engine oil consumption may be as high as 0.8 L/1,000 km (1 L/800 miles). This may be as a result of evaporation, internal ventilation or burning of the lubricating oil in the working engine.
Page 369 2. Switch the ignition ON with the selector pressed and continue pressing the selector for about 5 seconds until the master warning light flashes. Selector 3. After the master warning light flashes for several seconds, the initialization is completed. ▼ CAUTION...
Page 370 NOTE Changing the coolant should be done by an expert repairer (we recommend an ▼ Authorised Mazda Repairer). WARNING Cooling system cap Coolant reservoir Cooling fan...
Page 371 CAUTION ▼ WARNING...
Page 372 ▼ WARNING...
Page 373 CAUTION...
Page 374 ▼ CAUTION NOTE When raising both windscreen wiper arms, CAUTION raise the driver's side wiper arm first. When lowering the wiper arms, slowly lower the wiper arm from the passenger's side first while supporting it with your hand. Forcefully lowering the wiper arms could damage the wiper arm and blade, and may scratch or crack the windscreen.
Page 375 CAUTION CAUTION Metal support CAUTION Plastic locking clip...
Page 376 NOTE Install the blade so that the tabs are toward the bottom of the wiper arm.
Page 377 WARNING...
Page 378 NOTE Before performing battery maintenance, remove the battery cover. ▼...
Page 379 ▼ ▼ Upper level Lower level ▼ NOTE Before performing maintenance or recharging the battery, turn off all accessories and stop the engine. To disconnect the battery, remove the negative lead first. Install it last when connecting the battery. Be sure to remove the caps before recharging the battery.
Page 380 CAUTION...
Page 382 WARNING ▼ WARNING...
Page 383 NOTE vehicle. Have an expert repairer (we Always check tyre pressure when tyres recommend an Authorised Mazda are cold. Repairer) perform tyre rotation. Warm tyres normally exceed recommended pressures. Do not release air from warm tyres to adjust the pressure.
Page 384 ▼ WARNING CAUTION Tread wear indicator New tread Worn tread...
Page 385 ▼ WARNING CAUTION NOTE When replacing a wheel, make sure the new one is the same as the original factory wheel in diameter, rim width, and offset (inset/outset). For details, contact an expert repairer (we recommend an Authorised Mazda Repairer).
Page 386 10 11 10 12...
Page 387 CAUTION Removal NOTE To replace the bulb, contact an expert repairer (we recommend an Authorised Mazda Repairer). Use the protective cover and carton for Installation the replacement bulb to dispose of the old bulb promptly and out of the reach of children.
Page 388 Removal Installation...
Page 389 Removal Removal Installation Installation...
Page 390 Protective tape Rear combination lamp unit Grommet Area specifically in need Rear combination lamp of protection unit CAUTION Body Grommet...
Page 391 Rear combination Clip lamp unit Hook Grommet installation hole CAUTION Grommet installation hole Hook Rear combination lamp unit...
Page 392 ▼...
Page 393 ▼...
Page 394 NOTE If the lock is forcefully opened, the fuse block cover may come in contact with the frame when it is removed and become scratched. When removing the cover, remove it slowly according to the following procedure. Blown Normal 1. Disengage the rear lock by pressing down on the front tab with your fingers.
Page 395 3. Remove the cover while lifting it WARNING and sliding it to the rear. Normal Blown...
Page 396 ▼...
Page 401 Chipped paint can lead to rust forming on your Mazda. Before this happens, repair the damage by using Mazda touch-up paint according to the instructions in this section. Failure to repair the affected area could lead to serious rusting and expensive repairs.
Page 402 NOTE Mazda is not responsible for scratches caused by automatic car washes or improper washing. Scratches are more noticeable on vehicles with darker paint finishes. CAUTION...
Page 403 NOTE A spot remover to remove oil, tar, and similar materials will usually also take off the wax. Rewax these areas even if the rest of the vehicle does not need it. WARNING ▼...
Page 404 ▼ ▼ ▼ ▼ CAUTION CAUTION NOTE Do not use a wire brush or any abrasive cleaner, polishing compound, or solvent on aluminium wheels. They may damage the coating. Always use a sponge or soft cloth to clean the wheels. Rinse the wheels thoroughly with lukewarm or cold water.
Page 405 ▼ CAUTION...
Page 406 Drain filterA Drain filterB NOTE If leaves or other matter block the drain filter, water may enter the vehicle. Clean the drain filter at least once a year. CAUTION Drain filterA...
Page 407 NOTE ▼ A spot remover to remove oil, tar, and similar materials will usually also take off the wax. Rewax these areas. Drainage Rear roof outlet Rear window CAUTION NOTE If leaves or other foreign matter block the drainage outlets, water may enter the cabin.
Page 408 CAUTION Rear roof Drainage outlet Roof links Rear roof links WARNING...
Page 409 ▼ CAUTION...
Page 410 ▼ WARNING NOTE Do not wipe the interior using alcohol, WARNING chlorine bleach, or organic solvents such as thinner, benzene, and petrol. Otherwise, it may cause discolouration or stains. Rubbing hard with a stiff brush or cloth may cause damage. NOTE Clean seat belts diligently if they get dirty.
Page 411 ▼ NOTE ▼ Because genuine leather is a natural material, its surface is not uniform and it may have natural scars, scratches, and wrinkles. To maintain the quality for as long as possible, periodical maintenance, about twice a year, is recommended. If the leather upholstery comes into contact with any of the following, clean it immediately.
Page 412 ▼ ▼ CAUTION CAUTION ▼ ▼ NOTE Be particularly careful when cleaning shiny surface panels and metallic parts such as plating as they can be scratched easily.
Page 415 Strap NOTE The direction indicators do not work when the hazard warning lights are on. Check local regulations about the use of hazard warning lights while the vehicle is being towed to verify that it is not in violation of the law.
Page 416 ▼ WARNING ▼ and/or NOTE Until the flat tyre is changed, the beep sound is heard for about 30 seconds every time the ignition is switched ON.
Page 417 CAUTION NOTE A spare tyre or emergency flat tyre repair kit is not equipped on vehicles with run-flat tyres as standard. Replacing a punctured run-flat tyre with a new run-flat tyre is recommended. Do not use run-flat tyres and conventional tyres on the same vehicle. ▼...
Page 418 NOTE Your vehicle may or may not be equipped with a spare tyre, jack, and wheel brace. For details, consult an expert repairer (we recommend an Authorised Mazda Repairer). Emergency flat tyre repair kit Soft top model Wheel brace Jack lever...
Page 419 ▼ Wing bolt Tabs Jack screw NOTE If the jack is not completely secured, it could rattle while driving. Make sure the jack screw is sufficiently tightened. Wing bolt NOTE Verify that the cover is securely installed. Jack screw...
Page 420 If an emergency repair was performed on a flat tyre using the emergency flat tyre repair kit, have an expert repairer (we Speed restriction sticker Instructions recommend an Authorised Mazda WARNING Repairer), repair or replace the tyre as soon as possible.
Page 421 Mazda Repairer). The emergency flat tyre repair kit cannot be used in the following cases. Consult an expert repairer (we recommend an Authorised Mazda Repairer). The period of effective use for the tyre sealant has expired. (The period of effectiveness is indicated on the bottle Retractable fastback model label.)
Page 422 CAUTION Valve Valve cap NOTE The sealant hardens easily and injecting it will be difficult under cold Valve core tool weather conditions (0 °C (32 °F) or below). Warm the sealant inside the vehicle to facilitate injection. CAUTION Injection hose Tyre sealant Valve Valve core...
Page 423 Return the empty tyre sealant bottle to an expert repairer (we recommend an Authorised Mazda Repairer) when replacing the tyre. The empty tyre sealant bottle will need to be used to extract and dispose of the used sealant from the tyre.
Page 424 Valve Compressor hose WARNING Compressor hose...
Page 425 Compressor plug successful. Contact an expert repairer (we recommend an Authorised Mazda Repairer). Compressor If the tyre has been over-inflated, loosen the screw cap on the air compressor and bleed some of the air out.
Page 426 WARNING NOTE If an emergency flat tyre repair has been performed using the emergency flat tyre repair kit, Mazda recommends that the tyre be replaced with a new one as soon as possible. If the tyre is to be repaired...
Page 427 Check the period of effective use indicated on the bottle label and do not use it if it has expired. Have the tyre sealant replaced at an expert repairer (we recommend an Authorised Mazda Repairer) before the period of effective use has expired. NOTE Make sure the jack is well lubricated before using it.
Page 428 NOTE When blocking a tyre, use rocks or wood blocks of sufficient size if possible to hold the tyre in place. ▼ WARNING Jack head...
Page 429 WARNING Jacking position Tyre blocks Jacking position...
Page 430 NOTE WARNING When raising the jack head into the jacking position and aligning the groove in the jack head with the rail under the vehicle body, the top of the jack head contacts the vehicle's underbody without the rail contacting the bottom of the groove.
Page 431 ▼ WARNING WARNING...
Page 432 WARNING WARNING NOTE To prevent the jack and tool from rattling, store them properly.
Page 433 WARNING...
Page 434 CAUTION NOTE Do not use vehicles with i-ELOOP as a booster vehicle.
Page 435 Jumper leads Discharged battery Booster battery...
Page 436 WARNING CAUTION NOTE You cannot start a vehicle with an automatic transmission by pushing it.
Page 437 WARNING CAUTION...
Page 438 Cooling system cap Coolant reservoir Cooling fan CAUTION...
Page 439 Emergency release lever...
Page 440 CAUTION Wheel dollies...
Page 441 CAUTION CAUTION NOTE When towing with chain or lead, wrap the chain or lead with a soft cloth near the bumper to prevent damage to the bumper. ▼...
Page 442 Wheel brace Towing eyelet CAUTION CAUTION NOTE Remove the cap completely and store it so as not to lose it. Wheel brace Towing eyelet...
Page 443 ▼ WARNING CAUTION...
Page 444 WARNING CAUTION CAUTION CAUTION...
Page 445 CAUTION NOTE If the message is displayed, the power steering will not operate normally. In this case, the steering wheel can still be operated, however, the operation may feel heavy compared to normal, or the steering wheel could vibrate when turning. Repeatedly jerking the steering wheel left and right while the vehicle is stopped or moving extremely slowly will cause the power steering system to go into protective mode which will make the steering feel heavy, but this does not indicate a problem.
Page 446 ▼...
Page 447 NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light may illuminate. If this occurs, it is the result of the weak battery and does not indicate an ABS malfunction. Recharge the battery. The brake assist system does not operate while the ABS warning light is illuminat...
Page 448 CAUTION WARNING WARNING...
Page 449 WARNING WARNING...
Page 450 CAUTION CAUTION...
Page 451 CAUTION NOTE If the windscreen area in front of the Forward Sensing Camera (FSC) is fogged or obstructed, the light turns on temporarily. If the light remains turned on, there may be a problem with the system. NOTE If the Forward Sensing Camera (FSC) field of view is impaired during bad weather conditions (such as rain, fog, and snow) and when the windscreen is dirty, the warn ing indication/warning light for the Adaptive LED Headlights (ALH) may display/ turn on.
Page 452 NOTE If the vehicle is driven on a road with less traffic and few vehicles that the radar sen sors can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF indi cator light in the instrument cluster illuminates). However, it does not indicate a mal function.
Page 453 NOTE If the driver or passenger's seat belt is unfastened after the warning light turns on, and the vehicle speed exceeds 20 km/h (12 mph), the warning light flashes again. (With passenger occupant classification system) To allow the passenger occupant classifi cation sensor to function properly, do not place and sit on an additional seat cush ion on the passenger's seat.
Page 454 NOTE The light illumination timing may vary be cause fuel inside the fuel tank moves around according to the driving conditions and the vehicle posture.
Page 455 (we recommend an Authorised Mazda Repairer) which has all the equipment to fix tyres, TPMS systems and order the best replacement tyre for your vehicle.
Page 457 (Display example)
Page 458 (Display example) ▼...
Page 459 ▼...
Page 460 “Ignition Not Switched Off (STOP) Warning Beep” (page 7-48) overrides the lights-on reminder. ▼ A personalised function is available to change the sound volume for the lights-on reminder. Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ WARNING...
Page 461 ▼ ▼ NOTE Placing heavy items on the front passenger seat may cause the front passenger seat belt warning function to operate depending on the weight of the item. To allow the front passenger seat weight sensor to function properly, do not place and sit on an additional seat cushion on the front passenger seat.
Page 462 ▼ ▼ ▼ NOTE Because the key utilizes low-intensity radio waves, the Key Removed From Vehicle Warning may activate if the key is carried together with a metal object or it is placed in a poor signal reception area. ▼...
Page 463 ▼ ▼ ▼ ▼ ▼ ▼...
Page 464 Refer to the Settings section in the Mazda Connect Owner's Manual. ▼ NOTE A personalised function is available to change the Blind Spot Monitoring (BSM) warning beep sound volume. Refer to the Settings section in the Mazda Connect Owner's Manual.
Page 465 ▼ CAUTION NOTE When the system is temporarily cancelled by depressing the accelerator pedal fully, the ASL display shows the cancel display. Even if the vehicle speed exceeds the set speed by about 3 km/h (2 mph) or more while the cancel display is displayed, the warning sound is not operated.
Page 466 Windblocker...
Page 467 Multi-information display indication NOTE Stop operating the switch before the front roof opens. If the switch is CAUTION continuously pressed, the front roof opens and the following procedures cannot be performed. CAUTION...
Page 468 NOTE At this point, do not pull out the cap. If the cap is pulled out, the boot lock will release but the rear roof will not operate electrically. Cover Multi-information Stopper Rubber display indication Windblocker...
Page 469 Cover CAUTION Stopper Rubber...
Page 470 CAUTION...
Page 471 Rear roof Front roof Rear roof link CAUTION...
Page 472 This procedure is for manually closing the roof as an emergency measure. After closing the roof manually, electric operation is not possible until the system is restored by an expert repairer (we recommend an Authorised Mazda Repairer). Using a flashlight will facilitate the procedure.
Page 473 Refer to Adjusting the Driver's Seat on page 2-5. Refer to Adjusting the Passenger's Seat on page 2-10. Bolt NOTE The tip of the long end of the L-shaped NOTE hexagonal wrench can be used at an If it is difficult to see the bolt, remove angle.
Page 474 NOTE CAUTION The bolt cannot be removed completely. If it is hard to turn the bolt, repeat Step 3 a few times. Wire Link Pin Lock Unlock CAUTION...
Page 475 Link cover NOTE The next step cannot be done if the front roof is closed completely.
Page 476 Gear (tool kit) L-shaped hexagonal wrench (Small) Lock Lock Unlock Unlock Top lock motor gear NOTE Turning the gear (tool kit) requires some effort due to motor resistance. Slowly operate the hexagonal wrench. Gear (tool kit) CAUTION Hook Headliner...
Page 477 NOTE The top lock lever completely engages with the vehicle body (locked condition) at the position where the teeth of the gear (tool kit) contact the bracket. Bracket Gear (tool kit)
Page 478 The fasteners in the five locations at the front of the headliner are not fastened. Do not lose the fasteners because they are needed for the required servicing at the expert repairer (we recommend an Authorised Rope Link pin Mazda Repairer). Link cover CAUTION CAUTION...
Page 479 NOTE The rear roof is locked completely if the position where the rope is hooked is at the rear end of the bracket groove in the direction of the vehicle rear, as shown in the figure, when viewed from the vehicle interior.
Page 480 WARNING...
Page 484 WARNING...
Page 485 WARNING...
Page 486 ▼...
Page 490 ▼...
Page 499 ▼...
Page 500 ▼ Type A...
Page 510 ▼...
Page 524 CAUTION Aerial positions: : left of boot lid...
Page 525 NOTE After the installation of RF transmitters, check for disturbances from and to all electrical equipment in the vehicle, both in the standby and transmit modes. Check all electrical equipment: with the ignition ON with the engine running during a road test at various speeds.
Page 526 ▼ NOTE The bottom two letters might be used in combination with the crossed-out wheeled bin symbol. In this case it complies with the requirement established by the Directive for the chemical involved. “Pb” and “Cd” mean lead and cadmium respectively.
Page 527 ▼...
Page 529 ▼ ▼ ▼...
Page 530 ▼ ▼ ▼ Forward...
Page 531 ▼...
Page 532 ▼ ▼ CAUTION...
Page 533 ▼ ▼...
Page 534 ▼ ▼...
Page 535 ▼...
Page 536 The tyres have been optimally matched with the chassis of your vehicle. When replacing tyres, Mazda recommends that you replace tyres of the same type originally fitted to your vehicle. For details, contact an expert repairer (we recommend an Authorised...
Page 537 ▼ ▼...
Page 561 （）...
Page 570 8KQ1-EE-21K+L_2 Printed in Europe...

This manual is also suitable for:

Mx-5 2018
