- Page 1 NLS-EM1300 Series 1D Barcode Scanning Engine Quick Start V1.0...
- Page 2 Newland Auto-ID Tech Inc.(“Newland Auto-ID”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult Newland Auto-ID to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of Newland Auto-ID.
- Page 3 Quick Start Introduction EM1300 is an embedded barcode reading engine. Its gray scale CCD image capturer and the Newland patented , a Computerized Image Recognition System, ensure the fast scanning and decoding accuracy on different barcode media such as paper, plastic card, and metal surface. It can be easily integrated into OEM equipments or systems (hand-held, portable, and mounted) to provide solutions for image capture, bar code reading, and barcode message processing.
- Page 4 Quick Start Hardware Overview Interface Socket Camera Lens Illumination LED NLS-EM1300 Outline 12 Pin Flexible Cable nlscan.com Page 3...
- Page 5 Yaw (αas below) between 0°and 45°(0 is the best); Pitch (γas below) between 0°and 30°(5-20 is the best); Roll (β as below) 45°. For more information about EM1300 reading engine, please visit Newland Auto- ID website. www.nlscan.com nlscan.com...
- Page 6 Quick Start Supports & Service If you have a problem with your equipment, contact the Newland Support Center in your region. Before calling, have the model number, serial number, and several of your barcodes at hand. Call the support Center from a phone near the scanning equipment so that the service person can try to talk you through your problem.
- Page 7 Quick Start Revisions Version Data Source Description Date Approved 20090826 V1.0 nlscan.com Page 6...
