INSTALLATION GUIDE
SV10
Wastewater Sampling Port
Contents
Getting to Know the SV 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
On The Floor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Buried Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Part #: 8065-001-01
Find these instructions online at: schierproducts.com/sv10
© Copyright 2020 Schier, 03/01/2020
Advertisement
Table of Contents
Related Manuals for Schier SV10
Summary of Contents for Schier SV10
- Page 1 Buried Installation ........5-8 Part #: 8065-001-01 Find these instructions online at: schierproducts.com/sv10 © Copyright 2020 Schier, 03/01/2020...
- Page 2 GETTING TO KNOW THE SV10 Polyethylene Cover with Gasket 5. 4" Plain End Inlet Connection 9. Riser Cut Line 2. Quarter-Turn Camlock 6. 6" Plain End Inlet Connection 10. 6" Plain End Outlet Connection Cover Bolts (x2) 7. 6" Connection Cut Line (x2) 11.
- Page 3 Inspect unit and connections for leaks. Check water level at specific time intervals per local code. Have a Leak? SIDE VIEW Call customer care at 913-951-3300 Hours 8am-5pm CST, M-F Fill Line SV10 Installation Guide page 3 of 8...
- Page 4 FLOOR BELOW INSTALLATION DETAIL Connect Piping vent per local code 4" Plain End INLET The SV10 sampling port comes from the factory ready to connect to 4" drain lines. OUTLET 6" Connections Only Cut off the 4" connections at the...
- Page 5 Inspect unit and connections for leaks. Check water level at specific time intervals per local code. Have a Leak? SIDE VIEW Call customer care at 913-951-3300 Hours 8am-5pm CST, M-F Fill Line SV10 Installation Guide page 5 of 8...
- Page 6 6" deeper than port bottom. in the base of hole. Connect Piping INLET OUTLET 4" Plain End The SV10 sampling port comes from the factory ready to connect to 4" drain lines. 6" Connections Only Flexible PVC Couplings Cut off the 4" Drainage Lines connections at the premarked cut lines.
- Page 7 BURIED INSTALLATION Bring Cover Flush-to-Grade The SV10 is ready for burial depth of 14-1/2" from finished grade to bottom of unit (or 10-1/4" to centerline of inlet, 12-1/4" to centerline of outlet). Deeper burials will require adding a risers. Measure dimension X to determine riser height needed.
- Page 8 Rebar to be 2-1/2" from edge of concrete and spaced in a 12" grid with 4" spacing around access openings. 45º 18" Pedestrian Traffic or Greenspace Areas: Minimum 4" thick concrete slab with rebar required. SV10 Installation Guide page 8 of 8...
