elsner elektronik KNX WS1000 Color Brief Instruction

Brief Instruction
Warning, mains voltage! National legal regulations are to be
observed. Installation, inspection, commissioning and
troubleshooting of the device must only be carried out by a
competent electrician.

Preparing the installation location

The device must only be installed and used in dry, interior
spaces. Avoid condensation.
Cut-out dimensions for concealed box (approx.): W=229 mm | H=163 mm | D=62 mm:
An external antenna can be connected in order to improve wireless communications.
During installation, a conduit 50 cm in length should be placed beneath the reces-
sed housing, in which the external antenna can be mounted (antenna dimensions
approx. 565 x 8 x 5, L × W × H in mm):
Elsner Elektronik GmbH • Sohlengrund 16 • D-75395 Ostelsheim • Germany
Status: 16.08.2012 • Errors excepted. Subject to technical changes.
Mounting KNX WS1000 Color
