Evolution Digital HD uDTA Quick Start Manual page 2

Pair your remote control with your HD STB
to install it out of sight
Your remote control can be paired directly with your HD STB,
allowing you to place the device out of sight (in an entertain-
ment center or behind your TV, for example). Once your
remote is paired to a specific HD STB, it will not control any
other set-top box in your home.
3. Press and hold Setup
LED Indicator turns green.
4. Press the Menu button.
Please allow a few seconds for the menu to display
TO REMOVE REMOTE CONTROL PAIRING (FORCE UNPAIR)
If you would like to use your remote control for a different set-top box, you must first un-pair the remote control from
the current device. Follow the steps below to remove the pairing.
1 Press and hold the Setup button for 3 seconds until the LED Indicator turns green.
2 Enter 9-8-7 on the remote control.
3 The LED Indicator will blink green twice.
TO RESET THE TV IR CODE
1 Press and hold the Setup button for 3 seconds until the LED Indicator turns green.
2 Enter 9-8-6 on the remote control.
3 The LED Indicator will blink green twice.
TO FACTORY RESET THE REMOTE CONTROL UNIT
1 Press and hold the Setup button for 3 seconds until the LED Indicator turns green.
2 Enter 9-8-1 on the remote control.
3 The LED Indicator will blink green twice.
HD uDTA Remote Pairing
button until the
1. Press the Menu button.
2. Select Remote Control and then select
Remote Control Pairing.
5. Proceed by entering the pairing code
displayed in blue on the pairing code
pop-up screen.
Note: If you don't see a pairing code screen, repeat steps 1 and 2.
