  • Page 1 Customer Service Hotline. Made in China FERREX is a registered trademark of ALDI Stores ® DISTRIBUTED BY: ALDI STORES 1 SARGENTS ROAD MINCHINBURY NSW 2770 www.aldi.com.au AFTER SALES SUPPORT 708115 1300 855 831 support@scheppach.com.au YEAR MODEL: WARRANTY CSP5300 04/2023...
  • Page 2 User Manual PETROL CHAINSAW CSP5300...

  • Page 4: Table Of Contents

    Contents Overview Package content/part list Explanation of the symbols on the device Introduction Device description Scope of delivery Proper use Safety information Technical data Before starting up Operation Cleaning Maintenance, Servicing Storage Transport Disposal and recycling Troubleshooting Warranty Details Repair and Refurbished Goods or Parts Notice...

  • Page 7: Package Content/Part List

    Package contents/part list Chainsaw Saw chain Guide bar Guide-bar cover Spark plug wrench Allen key 4 mm Fuel mixing tank Saw chain round file Screwdriver Operating manual Warranty card...
  • Page 9 CHOKE CHOKE...
  • Page 11 Abschließender Schnitt hier. 5 cm über der Keilmitte. Pos.4 5 cm Pos.1 Erster Pos.4 Pos.1 Schnitt Pos.1 Pos.1 Fluchtweg Pos.2 Keil Pos.2 5 cm Pos.2 Fallrichtung Pos.2 Zweiter Pos.3 Pos.3 Schnitt Pos.1 Fluchtweg Pos.1 “Scharnier” hält den Baum auf seinem Stumpf und steuert die Fallrichtung Fallschnitt öffnet sich...
  • Page 12 Pos.1 Pos.2 Oberschnitt Unterschnitt Erster Schnitt auf belasteter Pos.1 Pos.2 Pos.1 Pos.1 Stammseite Zweiter Schnitt Mit Stammseite Pos.2 Schnitt Pos.2 Pos.2 Pos.2 Zweiter Schnitt Erster Schnitt auf der belasteten Mit Stützbock Schnitt Pos.1 Pos.2 Stammseite Schnitt Pos.2 Pos.1 Pos.1 Pos.2 Schnitt Pos.1 Pos.2...

  • Page 13: Explanation Of The Symbols On The Device

    Explanation of the symbols on the device Bedienung 1. Explanation of the symbols on the device Warning! When working with the chainsaw particular safety measures are required. Read and observe all warning information! Warning! Risk of kickback. Protect yourself from kickback from the chainsaw and avoid all contact with the bar tip.
  • Page 14 Symbole Explanation of the symbols on the device Wear non-slip safety shoes! Wear close-fitting protective clothing with a cut protection insert. Fuel filler cap. Never work without chain lubrication! Always check chain lubrication before starting work. Choke knob CHOKE Press the fuel pump primer 10x Adjustments for carburettor: ( L ) Low Speed ( H ) High Speed...
  • Page 15 Explanation of the symbols on the device Bedienung Running direction of the chain Guaranteed sound power level of the device Warning - Hot surfaces! On-/Off Switch - “ON“ On-/Off Switch - “STOP“ Weight Fuel mixing ratio Avoid contact with the bar tip. Naked flames or smoking near the device is strictly prohibited!
  • Page 16 Explanation of the symbols on the device Symbole Warranty class. Complies with the Australian norms and standards.

  • Page 17: Introduction

    2. Introduction Congratulations on choosing to buy a FERREX® product. All products brought to you by FERREX® are manufactured to the highest standards of per- formance and safety, and as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 3 Year Warranty.

  • Page 18: Device Description

    Device description 3. Device description (Fig. 1, 2) Saw chain Guide bar Front hand guard / Chain brake Front handle Housing cover air filter Mounting nut housing cover air filter Choke Throttle trigger lock Rear handle 10. Throttle trigger ON/OFF switch 12.

  • Page 19: Scope Of Delivery

    Scope of delivery/Proper use 4. Scope of delivery • Chainsaw (1x) • Saw chain (1x) • Guide bar (1x) • Guide-bar cover (1x) • Spark plug wrench (1x) • Allen key 4 mm (1x) • Fuel mixing tank (1x) • Saw chain round file (1x) •...

  • Page 20: Safety Information

    Safety information 5.1 Non-approved operators: People who are not familiar with this operating manual, children under the age of 16 and people under the influence of alcohol, drugs or medication are not permitted to operate the device. National regulations may restrict the use of the device! 6.
  • Page 21 Safety information 6. Do not start a chainsaw that is damaged, incorrectly set up or assembled incomplete- ly or loosely. Ensure that the chainsaw stops when the chain brake is activated. 7. Turn off the motor before putting the chainsaw down. 8.
  • Page 22 Safety information 7. If the tool becomes jammed during cutting, it has to be turned off immediately and freed carefully. Afterwards, the machine has to be checked for damage (e.g. bent chain bar) and a test run has to be carried out. To cut with the chainsaw, place the stop directly on the wood to be cut.
  • Page 23 Safety information 6.2 Personal safety • Never use only one hand when using the saw! Otherwise there is a risk that operating staff, helpers or onlookers may get injured. A chainsaw has been designed for use with both hands. • Wear your Personal Protective Equipment (PPE), consisting of: Cut-resistant shoes, cut-protection trousers, hi-vis vest or jacket in signal colours, gloves and a helmet with visor and hearing protection.
  • Page 24 Safety information Special safety regulations for the use of internal combustion motors m DANGER Internal combustion motors are a particular danger during operation and refuelling. Always read and follow the warnings. Non-compliance can lead to severe and even lethal injuries. 1.
  • Page 25 Safety information 6.4 Safety functions of the chainsaw (Fig. 1) 1 SAW-CHAIN WITH LOW KICKBACK helps you with specially developed safety devices to reduce kickback forces so you can absorb them better. 3 FRONT HAND GUARD protects the left hand of the operator if it slides off the front han- dle when the saw is running.
  • Page 26 Safety information Causes and prevention of kickback: • Kickback can occur when the tip of the guide bar touches an object or when the timber bends and the saw-chain becomes caught in the cut. • Contact with the guide bar tip can, in some cases, lead to an unexpected backwards reaction in which the guide bar is thrown up and in the direction of the operator.
  • Page 27 Safety information Storage 1. Never store the equipment with fuel in the tank inside buildings where the fumes can come into contact with open fire or sparks. 2. Before storing the chainsaw in a closed room, allow the motor to cool down. 3.
  • Page 28 Safety information 6.7 Operating instructions Important notices 1. Turn off the motor if the saw comes in contact with foreign objects. Check the saw and, if applicable, repair it. 2. Protect the chain from dirt and sand. Even small quantities of dirt can quickly make the chain blunt and increase the risk of kickback.
  • Page 29 Safety information Observe the following in order to avoid kickbacks: • Plunge work (directly plunging the tip of the bar into the wood) may only be per- formed by specially trained personnel! • Always watch the tip of the bar. Take care when continuing cuts which have already been started.
  • Page 30 Symbole Safety information Ensure you have a free escape route (Fig. A) Position 1: Escape route Position 2: Falling direction of the tree Felling of large trees - only with relevant training (from 15cm diameter) The undercutting method is used for felling large trees. For this, a wedge is cut out from the side of the tree according to the required falling direction.
  • Page 31 Safety information Bedienung Sawing a felled tree (log division) The term „log division“ describes the cutting up of a felled tree into logs of the desired length. m CAUTION Do not stand on the log you are currently cutting. The log could roll away and you may lose your footing and control of the device.
  • Page 32 Safety information Symbole Log division without supports (Fig. F) • Using topping (Pos. 1), saw 1/3 of the way into the tree. • Turn the log around and make a second top cut (Pos. 2). • When sawing on the compression side, make sure the saw does not get jammed. See Figure for cuts in logs on the compression side.
  • Page 33 Safety information Bedienung • Make sure that the tree is always between you and the saw. • Remove larger, supporting branches using the method from Section „Log division without support“. • Always remove small freely suspended parts of the tree with a top cut. They may fall into the saw or trap it if you use an undercut.
  • Page 34 Symbole Safety information NOISE HAZARDS Motor, gearbox and cutting system including the resonance of rigid machine parts can cause hearing damage (deafness) and other physiological disorders (e.g. loss of bal- ance, loss of consciousness), as well as acoustic signal disorders and language commu- nication disorders.

  • Page 35: Technical Data

    Safety information/Technical Data Bedienung 1. Location of accident 2. Type of accident 3. Number of injured people 4. Type of injuries Store all safety notices and instructions for the future. 6.9 Residual risks m DANGER RISK OF INJURY ! Contact with the saw chain can lead to fatal cuts. Never touch the saw chain with your hands while it is running.
  • Page 36 Symbole Technical Data Tooth pitch of drive sprocket 0.325" Chain brake Guide bar type BE20-76-5812P Saw chain speed max. 21,2 m/s Motor 1 cylinder 2 stroke air cooled Engine capacity 53 cm³ Maximum motor capacity 2,2 kW Idle speed 3100±300 min Maximum speed with cutting attachment 11000 min Fuel tank capacity...

  • Page 37: Before Starting Up

    Technical Data/Before starting up Bedienung Vibration Measured sound pressure level L 93 dB(A) Uncertainty K 3 dB Guaranteed sound power level L 114 dB(A) Measured sound power level L 108,7 dB(A) Uncertainty K 3 dB Vibration Front handle 10 m/s² Vibration Rear handle 9 m/s²...
  • Page 38 Symbole Before starting up 3. Tighten the mounting nut (B) for the bar with the key (12-15 Nm). 4. Check with your hand that the chain runs smoothly on the rail and has the proper voltage. 5. Where necessary, set up the chain tension. If the chain has to be re-tensioned.
  • Page 39 Before starting up Bedienung m CAUTION!: Special 2-stroke oil must be used for air-cooled 2-stroke engines with a 40:1 ratio. Insufficient oil will damage the engine and, in this case, void the warranty for the motor. FUEL MIXING TABLE Mixing ratio: 40 parts petrol to 1 part 2-stroke oil. Petrol 2-stroke oil 1 litre...
  • Page 40 Symbole Before starting up/Operation Chain Brake (Fig.14) m NOTE Before each use always check that the chain brake is functioning. • Hold the chain saw by the front handle (4). • Press the front hand guard (3) forward to position (3b). Press the pedal, the chain should not move.

  • Page 41: Operation

    Operation Bedienung 9. Operation m CAUTION! Please pay attention to the statutory provisions in the relevant noise protection regula- tions. Before starting the appliance, always check that: • The fuel system is not leaking. • The protective equipment and cutting equipment is complete and in perfect working order.
  • Page 42 Operation/Cleaning Symbole m CAUTION! Always pull the starter pull cord (13) straight out. Hold the handle of the starter pull cord (13) firmly when the starter pull cord (13) retracts. Do not allow the starter pull cord (13) to whip back. NOTE At very high outdoor temperatures it is possible that even a cold engine has to be started without using the choke!

  • Page 43: Cleaning

    Maintenance, Servicing Bedienung m NOTE To stop the engine in an emergency, activate the chain brake and set the ON / OFF switch to „Stop“. 10. Cleaning m WARNING Disconnect the spark plug boot before doing any cleaning and maintenance work. (Fig. Cleaning •...
  • Page 44 Symbole Maintenance, Servicing Guide bar (Fig.23-24) • Clean the bar after each use. • Remove the bar from the machine. • Remove sawdust from the bar and the oil channel (Fig.23/Pos.1). • Lubricate the teeth (Fig.24/Pos.2/3) through the oiling hole with an oil syringe. Cylinder fins (Fig.20) •...
  • Page 45 Maintenance, Servicing Bedienung Spark plug (Fig.17-19,22) m NOTE!: In order for the saw motor to remain powerful, the spark plug (G) must be clean and properly gapped (0.6-0.7 mm). Spark plugs should be cleaned or replaced every 20 hours. • Set the ON/OFF switch (11) to „Stop“. •...
  • Page 46 Symbole Maintenance, Servicing Breaking in a new saw chain A new chain and bar will need chain readjustment after as few as 5 cuts. This is normal during the breaking period, and the interval between future adjustments will begin to lengthen quickly.
  • Page 47 Maintenance, Servicing Bedienung • The saw cut is not straight. • The vibration increases. • Fuel consumption increases. m NOTE We recommend that a professional sharpen the chain. Instructions for sharpening a saw chain: Upper tilt File Standard Upper angle lower angle angle diameter...
  • Page 48 Maintenance, Servicing Symbole Important hint in case of sending the equipment to a service station: Due to security reasons please see to it that the equipment is sent back free of oil and gas! Instructions for periodic maintenance To ensure long life, prevent damage and ensure the full functioning of the safety features the fol- lowing maintenance must be performed regularly.

  • Page 49: Storage

    Maintenance, Servicing/Storage Bedienung Every 3 Fuel filter Replace months Fuel, oil tank Clean Storage Chain saw Clean exterior, check for damage. In case of damage, have repaired by a qualified service center immediately Guide bar/ chain Demount, clean and oil slightly Clean the guide groove of the guide bar Fuel, oil tank Empty and clean...

  • Page 50: Transport

    Symbole Storage/Transport/Disposal and recycling Putting the saw back into operation • Remove spark plug. • Pull starter rope briskly to clear excess oil from combustion chamber. • Clean the spark plug and check that the electrode gap is correct. • Prepare unit for operation. •...

  • Page 51: Troubleshooting

    Troubleshooting Bedienung 15. Troubleshooting Problem Probable cause Corrective Action Follow instructions in the Incorrect starting procedures. User Manual. Have carburetor adjusted Incorrect carburetor mixture by an Authorized Service Unit won´t start or adjustment setting. Center. starts but will not run. Clean / gap or replace Fouled spark plug.
  • Page 52 Troubleshooting Symbole Top up the oil tank for the Empty oil tank for the chain chain Insufficient chain lubri- Clean the oil lubrication cation (the cutter rail hole in the cutter bar and chain get hot) Oil lubrication openings moved Clean the groove in the cutter bar...
  • Page 53 Bedienung...
  • Page 54 Symbole...

  • Page 55: Warranty Details

    Petrol Chainsaw Warranty Details TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION The product is guaranteed to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion.

  • Page 56: Repair And Refurbished Goods Or Parts Notice

    Petrol Chainsaw Repair and Refurbished Goods or Parts Notice TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION Unfortunately, from time to time, faulty products are manufactured which need to be returned to the Supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. ...
