Philips HD3033 Service Manual

Hide thumbs Also See for HD3033:

Advertisement

Quick Links

Download this manual
Product Features
1
Model
Product
2
Control
3
Mode
Rated
4
Voltage
Rated
5
Power
6
Capacity
Thickness of
7
inner pot
Color of
8
plastc parts
Published by Philips Consumer Lifestyle
1
HD3033
Electronic
Control
220V~50H
z
980W
4.0L
2.0mm
Porcelain
white
Printed in China
df
Technical Info.
Copy Right Reserved
Rice Cooker
HD3033
Subject to modifcaton

Advertisement

loading
Need help?

Need help?

Do you have a question about the HD3033 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Philips HD3033

Summary of Contents for Philips HD3033

  • Page 1 HD3033 Product Picture Control Electronic Mode Control Rated 220V~50H Voltage Rated 980W Power Capacity 4.0L Thickness of 2.0mm inner pot Color of Porcelain plastc parts white Published by Philips Consumer Lifestyle Printed in China Copy Right Reserved Subject to modifcaton...

  • Page 2: Circuit Diagram

    Circuit Diagram HD3033 FUSE( AC250V/ 10A 152℃) （ ） Side Heater 220V/71.9W AC220V/ 50H z （ ） Top Heater 220V/50W Main Heater （ ） 220V/860W Bottom sensor FUSE(AC250V/ 10A 192℃) Top sensor...
  • Page 3 Exploding View HD3033...
  • Page 4 HD3033 Part List: Description Description 12NC (Chinese) (English) 蒸汽阀盖 steam valve cover 620202110174 蒸汽阀座 steam valve base 620202110173 面盖装饰片 Cover ornament 620202100088 面盖 top cover 620202050171 上盖发热组件 Top heating asy. 610201520001 蒸汽阀密封圈 steam valve seal ring 610206010039 保温座板 keep warm board 620203020016 内锅密封圈...
  • Page 5 Illustraton of Main Parts Heating Elements Name Picture Main Functions To heat the inner pot by making it closely contacted with the aluminum plate in which a electric heatng tube coil is placed; Power of 1 、 Heating the heatng plate will infuence the heatng Plate speed of rice cooker;...

  • Page 6: Disassembling Procedures

    Disassembling Procedures ： 1 、 Remove the lid-opening button with a 2 、 Remove the 2 screws with a screw-driver screw driver inserting from the side of it. 3 、 Separate the top cover and inner lid with 4 、 Remove the 6 screws on the keep-warm a spatula inserting between them board with a screw-driver, separate the keep- warm board with sealing ring...
  • Page 7 7 、 Remove the gemel and springs 8 、 Remove the screws on the base with a screw driver 。 9 、 Remove the socket 。 10 、 Remove screws with a screw-driver 11 、 Remove the two screws on the main 12 、...
  • Page 8 13 、 Cut off the binder with forceps 14 、 Pull out the connector on the PCB and remove the 4 screws on the PCB holder 15 、 Remove the two screws on the control 16 、 Remove the two screws on the power board with a screw-driver board with a screw-driver...
  • Page 9 Malfunctons 2 、 No heating while on power 1 、 To test if the heating plate works properly 2 If problems found, test if the bottom sensor with a multi-function meter works properly with a multi-function meter To connect both sides of the bottom sensor To put wires on both sides of the heating plate with red and black wire.
  • Page 10 Malfunctons 3 、 Repair for spilling （ 1) First, to check out the parameters of top sensor （ 2 ） Check whether the sensor on keep-warm board slacks of （ 3 ） Finally, check whether the display board is normal Procedures ：...
  • Page 11 Malfunctons 3 、 Repair for spilling G 、 Picture below shows the glue used to H 、 If the thin paper doesn’t shed of, fasten the thin paper please check the parameters of top sensor by loosing the screws R 、 The connector for top sensor is of black J 、...

  • Page 12: Troubleshootng

    Troubleshootng Fault Reason Solution 1.No power supply is outputted from the Check the power supply of the socket by having socket another appliance connected 2.Power cord being open circuit Check the power cord by replacing it with the a same one 3.The plug isn’t fully connected Insert the plug completely to ensure a fully connecting...
  • Page 13 Troubleshootng Fault Reason Solution Cook with right rice & water proportion 1.Inner pot is overloaded referring to the instruction manual 2.Difference in rice quality Change for another type of rice 4. Spilled rice or porridge 3.Rice isn’t well rinsed Rinse the rice 4.Top sensor malfunctions Repalce top sensor 5.Top sensor is losened...
