Summary of Contents for Sunsystem BURNIT CALOR-NOVATION Series
- Page 1 Pellet Stove series BURNIT CALOR-NOVATION 13 kW, 18 kW TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL FOR AUTHORIZED INSTALLER / SERVICE SHOP Version i 0.5...
-
Page 2: Table Of Contents
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL CONTENT EXPLANATION OF SYMBOLS AND SAFETY INSTRUCTIONS ..............3 PRODUCT DESCRIPTION .........................4 FUELS...............................5 TRANSPOTATION OF THE STOVE......................5 DELIVERY OF THE STOVE.........................6 SETUP OF THE HEATING PELLET STOVE ....................6 INSTALLATION OF THE HEATING STOVE ....................7 FILLING THE HEATING INSTALLATION .................... -
Page 3: Explanation Of Symbols And Safety Instructions
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 1. EXPLANATION OF SYMBOLS DANGER of intoxication, suffocation. AND SAFETY INSTRUCTIONS Inadequate inflow of fresh air to the stove room may result in dangerous leak of 1.1. Explanation of symbols exhaust gases during stove operation. -
Page 4: Product Description
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 1.2.3. Minimum clearances for installation and CAUTION! Risk of injury/damage to flammability of construction materials equipment due to incorrect operation. - Pellet stoves may be operated only by persons who are familiar with the The applicable minimum clearances in your country instructions of use. -
Page 5: Fuels
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 3. FUELS 4. TRANSPOTATION OF THE STOVE When purchasing pellets, ask for conformity declaration and certificate issued by an We recommend to transport the heating boiler to accredited laboratory and make sure the the installation site in its packaging placed on the fuel meets the requirements indicated in pallet. -
Page 6: Delivery Of The Stove
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 6. SETUP OF THE HEATING PELLET STOVE The assembly, installation and set- up of the boiler must be performed by a technician authorized for such operations. Installer must indicate to the user of the installation the minimum clearances from flammable materials and liquids. -
Page 7: Installation Of The Heating Stove
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL installation by a qualified professional. The required distance between the boiler and the chimney is 300-600 mm. Do not connect the exhaust gas system to a chimney in which already is connected another stove, boiler or ventilation system! 7. - Page 8 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL We recommend that the stove be installed as close 7.4. Connecting the pellet stove to the mains power as possible to the system’s exhaust gas extraction supply system (the flue). Such connection must be performed by a The maximum permitted length of duct pipe technician / service shop authorized for between the stove and the flue is 3 m, whereas no...
- Page 9 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 7.5.4. Required components when connecting the pellet stove to the heating installation. Pressure gauge Air vent ❷ ❶ Filter Return valve Three way mixing valve-45 (RECOMMENDED! - NOT REQUIRED) Safety valve ❻...
- Page 10 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 7.6.2. Connecting exhausted gases pipe with outside chimney (Pic.3) The stovepipe inside the house is getting connected with outside of the house chimney. Protection from rain Insulated chimney Inside stovepipe don’t need Smoke duct: isolation.
- Page 11 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 7.6.4. Connection between stovepipe and stovepipe that is placed inside the chimney. Covering sheet Protection from rain (Pic.5) This type of installation Air-tight steel don’t need isolated stove- sheet metal pipe, because the stovepipe is placed in...
- Page 12 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL Table 6. TROUBLE-SHOOTING TABLE Installation damage Cause Solution Due to unsealed connections Install the connecting piping strain-free to the stove connections. If the heating installation, including the piping network, has not been built frost-proof, we recommend that you fill the heating Due to freezing installation with a liquid which has low freezing point and corrosion protection and antifreeze agent.
-
Page 13: Filling The Heating Installation
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 8. FILLING THE HEATING INSTALLATION Table 7 Problem Prevention Possible installation damage due Fill the heating installation only in cold conditions to strains in the material caused by (inlet temperature must not exceed 40°C). - Page 14 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL - It‘s mandatory to clean stove totally for burned pellet amount of 800 kg to 1000 kg or once per year. When making routine check the authorized service must do as following: • Cleaning the fan; •...
- Page 15 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL Scheme 6. Dismount the cover of exhaust system. Scheme 10. Cleaning the Ash from the combustion chamber collected in the ash container After cleaning, close the system. When using of low quality pellets, it`s recommend that cleaning be done once a month.
-
Page 16: Microproccesor Controller
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10. MICROPROCCESOR CONTROLLER 10.1. CONTROLER Wiring controller... - Page 17 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL FUNCTION CHARACTERISTICS Power Supply 230 V±10% 50/60 Hz F1=Fuse T 5A Exhaust gases Fan El. Relay - maximum load 0.9А Igniter El. Relay - maximum load 1.6А Auger El.
- Page 18 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.2. Control panel. Functions. 12:18 Wed 7 March 2020 in the water mantle condition max t in the water mantle 1. Display - drop-down menu (touch screen) Date and time, temperature of the local room in use, Local room thermostat in use, signalling error tool Ignition and unblock of the system Access to Information Menu...
- Page 19 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 12:18 Wed 7 March 2020 3. System Functioning Led When we touch an icon button on the screen, it changes color. This means that the function is active. Touch the icons on the screen to perform the following operations: Auger On Exterior Chrono reached ЗIgniter On...
- Page 20 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.3. User Menu /1/.. 10.4. User Menu /2/. Activated by touching a button 10.3.1. Ignition / Extinguishing. The Customize with functions menu appears: - Setup - System menu - Menu on the display Ignition and Extinguish are activated by pressing and holding a button After ignition by touching a button we enter...
- Page 21 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.5.1 System menu. 10.5.3. Information menu. Touching the button-icon System menu we enter the installer menu. In order to access the menu functions, an installation access code is required, which we enter.
- Page 22 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.6.1. Auger menu. /ТР 01/ If a value is set = 0 the Auger is disabled for the corresponding Power/Phase If a value is set ≥ P05 the Auger works continuously for corresponding Power/Phase The TimeON regulation is settable as steps of 0.1 seconds The set or calculated values are automatically limited in the threshold P05 and P27.
- Page 23 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.6.2. Primary Air Flow Code Description Regulation management; 0 - deactivated; 1- adjustment of a chimney fan; 2 - fan and auger A 24 Adjustment control error; The 0-system does nothing;...
- Page 24 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.6.3. Combustion Fan Menu. /ТР 02/ Setting of the Combustion fan speed for The fan of pellet stove has an integrated encoder. In this case, parameter P25 must each power/phase of functioning. be set as “1”. To adjust the fan power P25=1: Encoder version >values are in must adjust the fan speed.
- Page 25 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL Standby speed Volt 2800 1300 1300 Speed in preheat mode Volt 2800 1100 1200 Combustion Fan Minimum Volt Speed 2800 Р16 Correction Step Value of the Combustion Fan Speed Не...
- Page 26 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL С] Th19 Enable Pump Thermostat stove С] Ih19 Enable Pump Thermostat Hysteresis stove Is not used Th20 Is not used Th21 ih21 Is not used С] Ih24 Stove Thermostat Hysteresis stove С] Th25 Stove Safety Thermostat stove С] Th26...
- Page 27 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL С] Increasing Delta Temperature exhaust gases Stabilization С] Delta Water Temperature in the boiler stove Combustion Power Automatic Regulation [A] С] Added value to the thermostat of stove the water jacket for switching from modulation to standby С]...
- Page 28 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL Т29 Waiting for preload on ignition Is not used Т32 Т33 Is not used Т34 Backfire auger operation 3600 Т40 Delay when starting the auger Work time of Pump 3600 Maximum time of inactivity of Pump 1500 Time, after which the stove goes from Modulation to Standby if Water Temperature>...
- Page 29 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.6.6. Enable’s Menu ТР 08 Code Description Unit Reached the Room Thermostat the stove goes in Extinguishing Reached the Room Thermostat the stove goes in Modulation [nr] Reached the Room Thermostat the stove goes in P26=0 Standby Reached the Room Thermostat the system blocks the...
- Page 30 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL Fan and auger correctoin OFF А64 Fan and auger correction ON [nr] Correction ON in ignition and stabilizer mode for fan and auger Р02 Maximum number of ignition attempts [nr] Р03 Operation modes [nr] Р04 Is not used Is not used...
- Page 31 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.7. Functions with the delay time as the timer T18. The other manual or automatic power changes are 10.7.1. Supply Voltage Lack Management. managed and actuated with the delay time as timer In case of Supply Voltage lack, the system saves the T17.
- Page 32 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 10.7.7. Speed combustion fan management. The parameter P25 sets the regulation modality of the Exhausting Fan Speed. P25=0 Exhausting Fan without Encoder: the speed is defined by the set voltage value [Volt]. The Regulation Step is of 5 Volt. Exhausting Fan with Encoder: the speed is defined by the set number of turns [RPM] P25=1 In case of signal presence but regulation failed, the system goes in BLOCK with Er08...
-
Page 33: Technical Parameters Of Pellet Stove
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 11. TECHNICAL PARAMETERS OF PELLET STOVE 11.1. Elements of pellet stove Controller Power supply Cover of pellet hopper Decorative side panels Pellet hopper Chimney Heat-resistant glass Incoming-air tube Door handle Tube Cold water Ash container... - Page 34 TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 11.2. Technical parameters of pellet stove CALOR-NOVATION CALOR- CALOR- NOVATION NOVATION Nominal Power 13 kW 18 kW Heat power /reduced power/ 5.5 kW Heat power water mantle 15.5 Height H 1005 1055 Width L/ Depth D 475/580 475/580 Volume of water jacket...
-
Page 35: Warranty Terms
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL 12. WARRANTY TERMS 13. RECYCLINING AND DISPOSAL 12.1. Warranty Terms. Submit all packaging material for recycling according to the local regulations and requirements. The warranty terms are described in the Service At the end of life cycle of each product its booklet included in the supply components are due to be disposed of in conformity... - Page 36 ISO 9001:2008 BUREAU VERITAS Certification tel.: +359 700 17 343 www.burnit.bg...
